- Page 1 AIR NIBBLER MODEL NO: CAT213 PART NO: 3120530 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1119 -ISS 1...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE air tool. The Air Nibbler is ideal for fast, accurate sheet metal cutting of curved or intricate shapes using its 4-way adjustable punch head. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
-
Page 3: Specification
0.84 kg Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 4: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. THE WORK ENVIRONMENT 1. ALWAYS keep the work area clean and tidy. 2. ALWAYS dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 5 • The tool will be left unattended. • Moving to another work area. 14. DO NOT use the tool if it is defective or operating abnormally. 15. DO NOT damage the tool by applying excessive force. 16. ALWAYS maintain the tool with care for the best and safest performance. 17.
-
Page 6: Compressed Air Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND A COMPRESSED AIR SUPPLY. A typical air line layout is shown below. If an automatic in-line filter/regulator is used, it will keep the air tool in good condition, but should be regularly checked and topped up with oil. - Page 7 (5 to 50 metres) etc. Contact your CLARKE dealer for further information or CLARKE International Service Department on 01992 565333. CLARKE Air Line Oil (part no. 3050825) is available from your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 8: Before Use
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR COMPRESSORS AND A COMPRESSED AIR SUPPLY. When opening the carton, check that all the items are present. Any damage or deficiency should be reported to your CLARKE dealer immediately. The carton should contain: • Air Nibbler tool •... -
Page 9: Operation
OPERATION The punch and die can be rotated through 360 to aid access and obtain maximum consumable life. 1. To do this, loosen the locknut with a 22 mm spanner and rotate the die on the blade until it is in the right position for the job in hand. -
Page 10: Disconnecting The Air Supply
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of CLARKE air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 11: Maintenance
4. Failing this, the tool should be disassembled, thoroughly cleaned, dried and reassembled. You may prefer to take the tool to your CLARKE dealer if internal maintenance is required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 12: Troubleshooting
2. Motor parts worn. 2. Return to CLARKE dealer for repair. 3. Worn or sticking 3. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Parts List
PARTS LIST Description No Description Screw nut Gear sleeve O-ring Spring Gear O-ring Bolt Bolt Gear bracket Air inlet E-clip Trigger pin Bearing Trigger Cushion Main housing Camshaft Bearing Rotating rod Rear plate Front housing Rotor Lubrication cover Rotor blade Bushing Bolt Sliding shaft...
