SAJ R5-5K-T2 User Manual page 15

AC Short Circuit Current Protection
AC Grounding Detection
DC Surge Protection
AC Surge Protection
Thermal Protection
String Current Detection
Anti-island Protection Monitoring
Interface
AC Connection
DC Connection
Human machine interface
Communication port
Communication Mode
General Data
Topology
Consumption at Night [W]
Consumption at Standby [W]
Operating Temperature Range
Cooling Method
Ambient Humidity
Altitude
Noise[dBA]
Ingress Protection
Mounting
Dimensions[H*W*D][mm]
Weight [kg]
Standard Warranty [Year]
Certificates
LED+(bluetooth/Wi-Fi+APP)
RS232(USB joints)+RS485(RJ45 crystal joints)
Wi-Fi/GPRS/4G(Optional)
-40℃～+60℃ [running in reduced load condition when the
temperature is above 45°C]
Natural Convection
0%～100% Non-condensing
4000m（>3000m power derating）
IP65 [Indoor & Outdoor Installation]
5 (standard)/10/15/20/25 (Optional)
CQC NB/T 32004,EN 62109-1/2,EN 61000-6-1/2/3/4
EN50438,C10/C11,IEC 62116,IEC 61727,RD 1699,UNE
206006,UNE 206007-1,CEI 0-21,CEI0-16,G98,G99
- 14 -
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
AFD
Plug-in connector
MC4
Transformerless
<0.6
<10
<29
Rear Panel
429*418*177
19
R5
Series
