Philips QUASAR HQ9100 Service Manual
Hide thumbs
Also See for QUASAR HQ9100:
- User manual (136 pages) ,
- Specification sheet (2 pages) ,
- User manual (76 pages)
Table of Contents
Advertisement
Quick Links
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
General:
- Mains operation only
- World-wide automatic voltage selection
- Electronic on/off button
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Shaving Performance:
If customers complain about poor shaving performance
of the triple-track shaving heads, replacing the driving
unit is recommended.
Published by Philips Domestic Appliances and Personal Care
06/07
TECHNICAL INFORMATION
- Voltage
- Motor voltage
- Shaving heads
- SAP coding
Printed in the Netherlands
© Copyright reserved
Shaver
HQ9100
QUASAR
: 100 - 240 Volt / 50- 60 Hz
: 9 Volt
: HQ9 - 4222 036 11150
: HQ9100
Subject to modification
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Philips QUASAR HQ9100
Summary of Contents for Philips QUASAR HQ9100
- Page 1 Shaving Performance: If customers complain about poor shaving performance of the triple-track shaving heads, replacing the driving unit is recommended. Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification 06/07...
- Page 2 DISASSEMBLY- AND RE-ASSEMBLY ADVICE HQ9100 Disassembly: - Remove shaving unit, to prevent damaging during repairing. - Remove the two screws (A) on the backside of the shaver. - Remove the three screws (B) from the innerhousing. - Remove the mains from the motor by turning and pulling the wires out of the motor.
- Page 3 EXPLODED VIEW HQ9100...
