SPECIFICATIONS AND RELATED INFORMATION
Pin Name
P12
P13
P14
P15
P16
P17
Outputs are active-low.
22
Signal Name
Direction
FPGA_EXT_RSTn
Output
EXT_SPI_PROG
NA
EXT_CONF_DONE
Input
Conduit
Comments
Input to FPGA on 48-
channel extension board
Not used (test point on 48-
channel extension board
only
Goes high to indicate the
FPGA configuration is
complete (48-channel
extension board)
®
Base Station IP67 Getting Started Guide for Versions 1.5 and 2.1
Where Used
48-Channel
extension
board
