V2.1 Power Draw - Multitech Conduit Series Getting Started Manual

1
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
2
TX Pulse: The average peak current during a GSM850 transmission burst period or HSDPA connection. The
transmission burst duration for GSM850 can vary, depending on what transmission scheme is being
deployed.
3
Inrush Charge: The total inrush charge at power on.

V2.1 Power Draw

Power draw for model MTCDTIP-LAT1-275L-915:
Voltage Radio Protocol Sleep Mode
56.0 Volts LTE
42.0 Volts LTE
(Safety Testing
Limit)
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA connection. The
transmission burst duration for GSM850 can vary depending on what transmission scheme is being deployed (GPRS
Class 8, Class 10, GSM, etc.).
Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power.
Inrush Charge: The total inrush charge at power on.
®
Conduit Base Station IP67 Getting Started Guide for Versions 1.5 and 2.1
Cellular Call
Current (If Box
Applicable Connection No
Data
NA 154 mA
NA 207 mA
SPECIFICATIONS AND RELATED INFORMATION
IP Connection TX Pulse
to Cellular Call (AVG)
Box with Data: Amplitude
(AVG) Current for
Measure GSM850 or
Current at Peak Current
Max Power for HSDPA
246 mA 312 mA
332 mA 404 mA
Total Inrush
Charge
Measured in
Millicoulombs
4.93 mC
4.4 mC
19
