- Page 1 Professional Headend Solutions Device manual SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) A-QAMOS-4CI Part N : 5102.81...
-
Page 2: Table Of Contents
7.3.12 Menu “LCN“ ....................... 27 7.3.13 Menu “Program table“ ..................27 8. Factory settings ............................28 9. Conversion tool to produce a compliant TS file for A-QAMOS-4CI ............29 9.1 Functional scope ........................29 9.2 Installation requirements ....................... 29 9.3 Installation and integration of the conversion tool on a Windows (XP) system ....29 9.4 Error prevention ........................ -
Page 3: Safety And Operating Instructions
The A-QAMOS-4CI converts digital satellite signals into QAM signals to transmit it in cable networks. In this case, up to 8 QAM channels from the available satellite IF signals are generated, which are attached via two inputs. Two Common Interface slots enab- les the use of up to 4 CA modules for the reception of scrambled satellite signals/ programms. -
Page 4: Explanation Of The Operating Elements
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 6. Explanation of the operating elements 6.1 Front view CAS port Status LED “POWER“ Status LED‘s channel 2, 4, 6, 8... -
Page 5: Meaning Of The Led's On Rear
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE 6.4 Meaning of the LED‘s on rear 6.4.1 LED’s at the satellite ports Colour Status Meaning of display green permanently on... -
Page 6: Adjusting By Web Server
Setup the connection: The A-QAMOS-4CI has to connected to PC network using an Ethernet cable. The IP address of the device is 192.168.1.100 on delive- ry. If several A-LINE-SBL devices should be controlled or adjusted via an Ethernet switch, each device must first be converted indivi- dually to its provided IP address within the network. -
Page 7: Initial Installation Using The Wizard
7.2 Initial installation using the wizard The easiest way to set the A-QAMOS-4CI is to use the wizard. By pressing the “Wizard“ menu in the navigation tree you get to the home page of the wizard. As with any other browser page at the top right hand it can also change the language. - Page 8 In this way, now up to 8 transponders per A-QAMOS-4CI can be selected to be transferred. First, as the output channel the next hig- her channel to the last selected program package is offered.
-
Page 9: Setting Of Individual Parameters
: 5102.81 LINE Clicking on the “OK“ button, the selection is accepted and set in A-QAMOS-4CI. The browser will be redirected to the home page (see chapter 7.3.1). By a reopening of the wizards left in the navigation tree you can always do a complete reinitialization of the device. The changes will be accepted and set only by pressing the “OK“... -
Page 10: Menu "Overview
Settings with the selection box or input fields are taken over by pressing the “send“ button and stored permanently, and the A-QAMOS-4CI is set on these values after a restart too. Settings with the check box are usually performed immediately but not stored in memory, so they would be lost on a possible restart of the device. -
Page 11: Menu "Sat Selection
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE 7.3.2 Menu ”SAT selection” In this menu you can make the choice of the satellites and the input configuration of the device. In the left part of the user interface there is the configuration menu of the input part. - Page 12 A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE If the point “unicable“ is selected for one or both satellite ports, the input mask is expanded by the unicable settings. If only one satellite port is set to unicable, the settings for the other port is disabled and grayed out.
-
Page 13: Menu "Ci Setup
7.3.3 Menu ”CI setup” In this menu there is the configuration of the Common Interfaces of the device. The A-QAMOS-4CI has 2 double-CI slots for a maxi- mum of 4 CA modules. The modules can be cascaded, i.e. a transport stream can be routed through one up to a maximum of every 4 modules for decryption of services. - Page 14 A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE In this menu all services of the adjusted transponder and their CA status are listed. If you want to make adjustments or changes first the “Refresh“...
-
Page 15: Menu "Transponders
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE 7.3.4 Menu ”Transponders” In this menu, the transponder selection, and so the program selection too, is done for all output channels. The user interface is divi- ded into three tables. -
Page 16: Menu "Adjustment
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 7.3.5 Menu ”Adjustment” In this menu, the settings of the device are made. Each channel can be adjusted individually according to individual requirements. -
Page 17: Menu "Language
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE CAT processing selection: on, on with CA filter, off CA system ID adjustment range: 0...65535 Operator ID adjustment range: 0...65535... -
Page 18: Menu "Service
7.3.7 Menu ”Service” In this menu you will find all information about the service for the A-QAMOS-4CI in particular the BLANKOM service hotline and the service email address. In addition, the implemented operating instructions may be downloaded or viewed as PDF. If there is an in- ternet connection the BLANKOM homepage can be started, offering the latest software release or descriptions. - Page 19 A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE Specifically, the following can be configured: GUI settings Help information within the status line of the browser By default, the online help is displayed in an orange text box at the bottom of the page.
- Page 20 Status). Thus, it is possible, for example to copy the system files from an A-QAMOS-4CI to another. If under “GUI setup“ “Display all system files“ is selec- ted, the system files can also be loaded or saved separately (see figure below).
- Page 21 Clicking the “Set“ button, the date and time will be set to that of the PC. Enabling of In this field, possible software options for the A-QAMOS-4CI can be enabled. The registration code must be entered in the input field and by pressing the “Send“...
- Page 22 Details may be found in the help text for each event. The critical priorities are each covered with fixed values that can not be changed. If the web site of A-QAMOS-4CI is open, no changes are possible via SNMP .
- Page 23 To produce a transport stream file in the appropriate format, the company BLANKOM provides a corresponding conversion tool. This may generate a corresponding file in the transport stream format, which the A-QAMOS-4CI can handle. A detailed description of the conversion tool can be found in chapter 9.
-
Page 24: Menu "Level
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 7.3.9 Menu ”Level” With the top box, the loop through output (loop) is enabled or disabled. If enabled, the underlying selection of the nominal level for all 8 channels may be set in the range from 62 ... -
Page 25: Menu "Nit
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE 7.3.11 Menu ”NIT” The NIT processing for all to a head end associated devices of the A-QAMOS- and QAMOS product group can be done in 2 ways: as an automatic or manual NIT processing. -
Page 26: Manual Nit Processing
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 7.3.11.2 Manual NIT processing After the preparation or initializing of the NIT, described in 7.3.10, first it must be called the edit mode of the NIT in each device of the A-QAMOS and QAMOS product group of the head end, read the NIT of the device and stored on the PC by clicking the “Export“... -
Page 27: Menu "Lcn
7.3.13 Menu ”Program table” The program table gives an overview of the channel allocation of the A-QAMOS-4CI. The overview begins with the output frequency and output channel identifier for each transmission channel. Under them all TV and radio programs are listed, which are transmitted in... -
Page 28: Factory Settings
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 8. Factory settings A short pressing of the reset button on the rear of the device causes a reboot, i.e. it will restart the device and all stored values are adjusted. -
Page 29: Conversion Tool To Produce A Compliant Ts File For A-Qamos-4Ci
9. Conversion tool to produce a compliant TS file for A-QAMOS-4CI With the media player option of A-QAMOS-4CI it offers the opportunity to install a TS file from a PC connected via network with the A-LINE-SBL device. The file must be present in a transport stream format conforming to the DVB standard. - Page 30 A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE In order to perform post processing, you have to link the path to “tsmux.exe“ in the converter. Then, click the button “path to post- processing“...
-
Page 31: Error Prevention
However, the resulting files are not compatible with conventional software programs. These compressed files are used only by the A-QAMOS-4CI or compatible devices of BLANKOM company.. This switch activates a function which suppresses the conversion resulting from the continue count errors due to the different buffer models. It is stron-... -
Page 32: Block Diagram
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE 10. Block diagram Demod. Tuner 2x LNB-Power 8x TS Stratix IV FPGA Control Eth. NIOS Proc. 12 V SDRAM DDR 2... -
Page 33: Technical Data
A-QAMOS-4CI SAT-TV Transmodulator DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) Part N : 5102.81 LINE 12. Technical data SAT IF input Test signals: Frequency range 950...2150 MHz QAM test signal according adjustment symbol Frequency step 1 MHz rate &... -
Page 34: Bibliography
A-QAMOS-4CI SAT-TV Transmodulator Part N : 5102.81 DVB-S/ -S2 (8x QPSK/ 8PSK) → 4x CI → DVB-C (8x QAM) LINE FPGA Field Programmable Gate Array Global System for Mobile Communications Graphical User Interface HD TV High Definition Television HTTP Hypertext Transfer Protocol... -
Page 35: Notes On The Device Software
15. Notes on the device software Device Software of the A-QAMOS-4CI Copyright (C) BLANKOM Antennentechnik GmbH Bad Blankenburg This device software based on top of Linux 3.6.8 is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation, either version 2 of the License, or (at your option) any later version. -
Page 36: Declaration Of Conformity
Type Name: A-QAMOS-4CI Type N 5102.81 BLANKOM Antennentechnik GmbH confirms that the mentioned product meets the guideline(s) of the Council for the approximation of legislation of the member states. Electromagnetic compatibility (2004/ 108/ EC) The following standards are met: DIN EN 50083-2: 2007-04 (EN 50083-2:2006-06)
