V. Fixing Accessories
Clip Accessories
Gasman is supplied with a simple pocket clip, other clip options are:
Hard hat clip
Allows Gasman to be clipped to a hard hat, a method of wearing a port-
able gas detector preferred by many users.
Alligator clip
A strong alligator clip allowing the user to wear Gasman on a belt, sleave,
jacket lapel etc.
Universal harness plate
Crowcon provide a universal harness plate which can be used with either
a chest harness or a shoulder strap.
How to wear your Gasman unit
Chest harness
Use the M3 fixing on the back
of your Gasman unit to attach
the chest harness plate. Create
a chest harness by attaching one
strap to the top connectors, to go
around the neck, and the other
to link around the waist using
the side connectors. Adjust the
lengths until the Gasman unit is in
a comfortable working position.
Shoulder strap
With the universal harness plate in place on the belt clip, attach the
shoulder strap accessory onto the top connectors. Adjust to a comfortable
working position.
See accessories, section XI, for full list.
Chest harness plate
Fixing Accessories
Shoulder/neck
connectors
M3 nut
Waist
connectors
