- Page 1 Gas-Pro www.acornfiresecurity.com User & Operator Manual Click here Gas-Pro for navigation Multi-gas monitor instructions Click here fo contents list M07995/Eng www.acornfiresecurity.com Issue 11 Dec 2016...
- Page 2 www.acornfiresecurity.com NAVIGATION INSTRUCTIONS Contents The symbols in the left-hand margin of each page of the manual will enable you to carry out the following functions: Contents Click on this button to display the Contents page. Click on this button to display the previous page. Click on this button to display the next page.
- Page 3 www.acornfiresecurity.com CONTENTS PROLOGUE ..........7 Gas-Pro Overview .
- Page 4 www.acornfiresecurity.com 2.5.5 Sensor types ......... . .25 2.5.5.1 Oxygen sensors .
- Page 5 www.acornfiresecurity.com 2.9 Tank Check Mode ......... . .34 2.9.1 Dual-Range Operation .
- Page 6 www.acornfiresecurity.com 8. Specification ......... 47 9.
- Page 7 Contents Gas-Pro Overview Thank you for purchasing the new Gas-Pro. At Crowcon we recognise the need for reliable and robust personal monitors which are sized to be worn and simple to use. Gas-Pro is a portable monitor capable of detecting up to 5 gases in a compact and wearable design featuring an optional internal pump.
- Page 8 www.acornfiresecurity.com Safety Information Contents • Gas-Pro is a hazardous area certified gas detector and as such must be operated and maintained in strict accordance with the instructions, warnings and label information included in this manual. Gas-Pro must be operated within the limitations stated. •...
- Page 9 www.acornfiresecurity.com • Gas-Pro may be used in Zones 1 and 2, for Group llA, llB and llC gases and vapours and for Contents Temperature Classes T1, T2, T3 and T4. (see Certification labels below). • Certification labels The certification marking is as follows: Ex d ia IIC T4 Gb -20°C ≤...
- Page 10 www.acornfiresecurity.com ATEX Contents EN 60079-0: 2012 + A11: 2013 Explosive atmospheres – Part 0: Equipment - General requirements EN 60079-1:2007 Explosive atmospheres – Part 1: Equipment protection by flameproof enclosures “d” EN 60079-11: 2012 Explosive atmospheres - Part 11: Equipment protection by intrinsic safety “i” Prologue II 2 G Ex d ia IIC T4 Gb Tamb -20°C to +55°C Set-up...
- Page 11 www.acornfiresecurity.com Unpacking Contents Remove the Gas-Pro from the packaging. The standard accessories are under the supporting trays. The following items will be included as standard: Box contents • Gas-Pro • Quick Start Guide • CD Manual Prologue • Calibration report Set-up The following items are optional: Operation...
- Page 12 www.acornfiresecurity.com 1. Set-up Contents 1.1 Prior to use Before use, the Gas-Pro should always be checked for any signs of physical damage. Gas-Pro uses a Lithium Ion (Li-ion) battery pack and should arrive with sufficient charge to be used straight out the box. However, if this is the first time of use, you may need to charge the battery to attain the full operating time (see Charging page...
- Page 13 www.acornfiresecurity.com 1.3 Charging Contents Charging should only take place in non-hazardous (safe) areas. To charge, simply plug the cable into À the charging socket Á on the Gas-Pro and turn on the mains supply (see Figure 2 below). If a charging cradle or vehicle cradle is being used, ensure the Gas-Pro fits firmly on to the power connector.
- Page 14 www.acornfiresecurity.com 1.4 Fitting a flow plate Contents A flow plate can be used for a number of applications including pumped operation (remote sampling), manual gas test/calibration or for manual sampling. If the pumped flow plate is attached before turning the Gas-Pro on and the Gas-Pro includes a pump, a pump test will commence as part of the start up process (see Pump test page...
- Page 15 www.acornfiresecurity.com 1.5 Quick view Contents Even when the detector is off, users can display details about the configuration of the Gas-Pro by momentarily pressing the operator button for one audible blip. The LED to the left of the display will flash red once and the Quick view screen shown in Figure 6 below will be displayed for 10 seconds.
- Page 16 www.acornfiresecurity.com 2. Operation Contents 2.1 General Before turning the Gas-Pro on, ensure it is in ‘clean air’ (i.e. outside, in normal air, away from any plant process or suspected gas location). This will allow the Gas-Pro to be zeroed using clean air as the base point. If the Gas-Pro is zeroed in contaminated air a false gas reading can result, or the zero could fail.
- Page 17 www.acornfiresecurity.com If the Gas-Pro is configured for regular Gas Testing (Bump Test), the date of the last Gas Test will Contents also be shown (for more information on Gas Testing, see Gas testing and calibration page 37). Figure 8: Gas test due screen Prologue Set-up Operation...
- Page 18 www.acornfiresecurity.com The next screen (Figure 10) will display the current detector settings (for more information on these Contents settings, see Gas-Pro functions page 28). Figure 10: Current settings screen Prologue Set-up Operation The Autozero Confirm screen will be displayed next. Gas testing Figure 11: Autozero confirm screen Maintenance...
- Page 19 www.acornfiresecurity.com When the autozero has finished or been skipped, the next screen is the home screen (Figure Contents and displays the gas levels. The next screen on the Tank-Pro edition of Gas-Pro is the Tank Check screen. See the Tank Check Mode section (see Section 2.9 page...
- Page 20 www.acornfiresecurity.com 2.3 Pump test Contents In the default configuration, a pumped Gas-Pro with a flow plate attached (see Fitting a flow plate page 12) will run a pump test during the start up process. A pump test will also be run whenever a flow plate is attached during normal operation.
- Page 21 www.acornfiresecurity.com 2.4 Detecting gas Contents When sampling an area that may contain water, use the ball float probe to reduce the potential for water travelling up the sample line. 2.4.1 Diffusion monitoring If you wish to monitor gases in ambient air for dangerous levels, the Gas-Pro can be worn by either clipping the strong alligator clip to clothing/overalls in the breathing zone or through the use of a chest harness.
- Page 22 www.acornfiresecurity.com 2.4.2 Pumped mode Contents Pumped operation requires the use of the pumped flow plate which automatically activates the pump (see Bump/Pump functionality page 33). Gas-Pro can either be worn or used with hoses and probes to sample from spaces prior to entry. The pump capacity in the Gas-Pro is 0.5l/m and will draw a sample of gas from 30m within 80 seconds.
- Page 23 (ie if the sample being tested is 30ppm – the expected result onscreen will show 32ppm. PC software If Gas-Pro is being used regularly for sampling, Crowcon strongly recommend the use of the internal Accessories pumped option to reduce time and potential for error.
- Page 24 www.acornfiresecurity.com 2.5 Alarms Contents The Gas-Pro has the following types of alarm: • Low battery • Instantaneous • Time weighted average (TWA) 2.5.1 Low battery alarm When the Gas-Pro warns of a low battery, the sounder will emit an audible double blip every 5 seconds and, if configured to do so, the +ve Safety™...
- Page 25 www.acornfiresecurity.com 2.5.4 Accepting and clearing alarms Contents Setting Alarm 1 Alarm 2 Non-latched Alarms will not be latched returning Alarm can be turned off only when gas to non-alarm state without user has returned to acceptable levels acceptance Latch Accept Allows the user to silence alerts but Alarm can be turned off only when gas remains in alarm.
- Page 26 www.acornfiresecurity.com 2.5.5.4 Pellistor sensors Contents Pellistor sensors (or catalytic beads) are specifically designed to sense explosive gases. The detecting element consists of small “pellets” of catalyst loaded ceramic whose resistance changes in the presence of gas. 2.5.5.5 Pellistor saver mode While in saver mode and the subsequent stabilise time, the gas level displayed on the LCD screen will indicate over range.
- Page 27 The baseline is unstable or shifts when the sensor is moved Operation • Sensitivity of the sensor has dropped Please refer to Crowcon application note PID-AN-001 for further details on maintenance and Gas testing cleaning of the PID sensor. Maintenance...
- Page 28 www.acornfiresecurity.com 2.6 Gas-Pro functions Contents The following can be selected from the Gas-Pro user menu: Home screen Manual zero Time weighted average (TWA) review Pre-entry check Prologue Peak review Set-up Settings menu 2.6.1 Accessing the user menus Operation With the home screen displayed, double click the operator button to access the function menus.
- Page 29 www.acornfiresecurity.com 2.6.5 Pre-entry check (PEC) Contents This function is intended for sampling air of unknown quality before gaining access to it (e.g. going under ground through a manhole cover) thereby avoiding unnecessary exposure. The Gas-Pro (and any sampling probe) should be in a clean air when the PEC starts and finishes so the TWA accumulation should be insignificant.
- Page 30 www.acornfiresecurity.com 2.6.5.2 Carrying out a Pre-entry check Contents The Gas-Pro will remain in the sampling stage for a maximum of 5 minutes. Whilst the sampling screen is displayed, it will show the real time gas levels. The alarms will continue to function during this stage and a single click of the operator button will accept these.
- Page 31 www.acornfiresecurity.com Contents 2.6.6 Peak review Select this option from the Menu Screen to see the highest level of each gas detected during the session. The menu offers the choice to display the peak gas level since the Gas-Pro was powered , that occurred during the last 8 hours , or during the last 12 hours .
- Page 32 www.acornfiresecurity.com 2.7 Shut down Contents To turn the Gas-Pro off, press and hold the operator button. A 4 second countdown will start. Hold the button down until the countdown has finished and the Gas-Pro will shut down. If you release the button before the countdown has finished, the Gas-Pro will resume operation.
- Page 33 www.acornfiresecurity.com 2.8.2 Data and event logging Contents The data log records gas levels for all sensors and has capacity for 45,000 logs (125hrs @10 sec intervals). Threshold levels can be set using Portables Pro, extending log capabilities. The data log interval is set as part of the Gas-Pro configuration and can be adjusted using Portables Pro.
- Page 34 www.acornfiresecurity.com 2.9 Tank Check Mode Contents Tank Check Mode is unique to devices with a Dual-Range Flammable IR sensor fitted, or ‘Tank-Pro’ branded devices. The device should under no circumstances be used as personal protection equipment whilst in Tank Check Mode. These devices will always display Tank Check Mode after start up has completed rather than the Home Screen.
- Page 35 www.acornfiresecurity.com Tank Check Mode can be identified over the Home Screen as the text will be displayed in place Contents of the current user name, the tank check icon will be displayed in the bottom-right corner, and the alarms disabled icon will be displayed to the left of the tank check icon. Figure 18: Tank Check home page Prologue Set-up...
- Page 36 www.acornfiresecurity.com 2.9.2.4 Confidence Tone Contents The Tank Check Mode confidence tone is different to other operational modes to give an audible indication of the operating mode. The Tank Check Mode confidence tone is four short ‘pips’ which are low pitch while in LEL range, and high pitch in VOL range.
- Page 37 Contents 3.1 Introduction Crowcon recommends regular gas tests (also known as bump tests) to confirm sensor operation. This involves applying a known composition of the correct gas to each sensor to verify sensor response and alarm function. Organisational specific Health and Safety regulations should be adhered to, and a number of flexible and simple solutions are available.
- Page 38 www.acornfiresecurity.com Contents From the 1st November 2010, EN60079-29 part 1 has been harmonised under the ATEX directive 94/9/EC. Therefore to comply with the ATEX directive, portable apparatus sensing flammable gases should have a functional check with gas before each day of use. Other testing regimes may be employed depending on local circumstances.
- Page 39 www.acornfiresecurity.com 3.2.1 Speedy bump Contents A speedy bump tests the Gas-Pro to first alarm level. Gas is presented across/over the sensor for a designated time (dependent on sensor gas type) during which alarm level one should be activated. This is deemed a pass if the detector goes into alarm and the detector is functioning (sounder, LED’s and vibrator, verified by the user).
- Page 40 Appendices In addition calibration should be performed as required by local or organisational regulations. In Warranty the absence of suitable evidence, such as a field assessment by a competent person, Crowcon recommend regular service and calibration every 6 months. Exit...
- Page 41 www.acornfiresecurity.com 3.4 Gas test screen flow Contents The following sequence of screen shots should be viewed with reference to the sections on ‘Speedy Bump’, ‘Smart Bump’ & ‘Calibration after bump fail‘. The screen shots show the general flow of the gas test functionality dependant upon the actual test and the decisions made.
- Page 42 www.acornfiresecurity.com 4. Icon overview Contents The table below details the icons shown during regular operation as well as warning messages. This table is intended as a quick overview please refer to specific functional sections within this manual for further details. Icon Description Icon...
- Page 43 Ensure maintenance, service and calibration are carried out in accordance with the procedures in the manual and only by trained personnel. For further service or maintenance, contact your local Crowcon agent or regional office, for details reference the ‘Contacts’ section of the manual.
- Page 44 PC software As well as displaying real time gas level data and signalling instantaneous and time weighted average alarms, the Gas-Pro records events and gas levels. Using the I-test available from Crowcon, Accessories or by connecting the Gas-Pro to a computer (see...
- Page 45 www.acornfiresecurity.com 7. Accessories Contents Part Number Description CH0100 Multiregion power lead (includes CH0101 and CH0102) CH0101 Multiregion power supply CH0102 Charging lead CH0103 USB communications lead (not powered) CH0104 USB communication and power lead CH0105 Gas-Pro charger cradle (no power) Prologue CH0106 Vehicle charging adaptor (use with CH0102)
- Page 46 www.acornfiresecurity.com Contents Part Number Description AC0301 1m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0303 3m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0512 Ball float probe AC0103 Calibration flow plate for PC Calibration (no magnet) Prologue Set-up Operation...
- Page 47 www.acornfiresecurity.com 8. Specification Contents Detector type Multi-gas monitor Gases* S, CO, CO , FLAM Pellistor (CH ), SO , CL , NO, NO , NH , PID, FLAM IR (CH Size (d x l x w) 43 x 130 x 84 mm (1.7 x 5.1 x 3.3 inches) Weight 5 gas (pump) 362g (12.7oz) 5 gas (un pumped) 333g (11.7oz)
- Page 48 www.acornfiresecurity.com 9. Troubleshooting Contents 9.1 Pump test failure In the event of a pump test failure, check the following: • Ensure a pumped flow plate was used for the test • Remove the flow plate and check the gasket for damage (scratches, tears, etc.) •...
- Page 49 www.acornfiresecurity.com 9.2.1 Fault Descriptions Contents Fault Symtom/Error Icon Cause Action codes Message 0 or 9 Instrument won’t Flat Battery. Recharge battery. switch on. No confidence Function disabled. Reconfigure with PC beep/flash. software. 26 - 30, Gas Reading with Zero drifted. Zero the instrument in Prologue 58 - 62...
- Page 50 www.acornfiresecurity.com Contents Fault Symtom/Error Icon Cause Action codes Message 0 or 9 Display shows Battery depleted. Recharge battery. empty battery symbol during startup. Switched on and Unit full and on charge Remove Gas-Pro from fully charged. for over 12 hrs. charge.
- Page 51 www.acornfiresecurity.com Contents Fault Symtom/Error Icon Cause Action codes Message Bump Test Fail The monitor has not The monitor needs Lock. been gas tested in the calibration. defined period and the gas test lock function has been activated. Battery low Battery Low (about 20 Exit the hazardous area to 30 minutes before as soon as possible and...
- Page 52 www.acornfiresecurity.com 10. Appendices Contents 10.1 Sensors 10.1.1 Toxic Sensor part no Range CO/H SS0300 0-500/0-100PPM SS0306 0-100PPM SS0305 0-5PPM Prologue SS0308 0-1PPM Set-up SS0304 0-20PPM SS0309 0-1PPM Operation SS0301 0-500PPM SS0301 0-2000PPM Gas testing SS0302 0-2000PPM (H Filtered) SS0303 0-100PPM Maintenance SS0310 0-100PPM...
- Page 53 www.acornfiresecurity.com 10.1.2 Flammable Pellistor Sensors Contents Flammable sensors MUST only be used with the PCB P/N as detailed below in the ‘PCB P/N Suitability” Column. Failure to do so may impair intrinsic safety and invalidate safety certification. Sensor Part No. Range PCB P/N Suitability Methane...
- Page 54 Persistent exposure to high levels of toxic gas can shorten the life of toxic sensors. Toxic sensors may also be cross-sensitive to gases other than their specific target gas, and hence the presence of other gases may cause the sensor to respond. If unsure, contact Crowcon or your local agent. Prologue Use of high power radio transmitters in close proximity to the instrument may exceed RFI immunity levels and cause erroneous indications.
- Page 55 www.acornfiresecurity.com 10.3 Charging and run times Contents The table below indicates run times which can be expected following a full charge discharge cycle. Configuration Run Time ,CO/H S, Pellistor, CO (IR) 11 hrs Pumped 10 hrs ,CO/H S, Pellistor, CO (IR) O2,CO/H S, Pellistor...
- Page 56 Contents Prologue Set-up Operation Gas testing Maintenance PC software Accessories Specification Troubleshooting Appendices Warranty www.crowcon.com Exit www.acornfiresecurity.com...
- Page 57 www.acornfiresecurity.com Warranty Contents This equipment leaves our factory fully tested and calibrated. If within the warranty period of two years from despatch, the equipment which includes pump, battery and common sensors (see sensor chart below) is proved to be defective by reason of faulty workmanship or material, we undertake at our option either to repair or replace it free of charge, subject to the conditions below.
