- Page 1 BBI-14.4 Industrial Modem Installation, Operation and Diagnostics 0049-0001-000 Rev.B BBI-14.4 Industrial Modem: Installation, Operation, Diagnostics...
-
Page 2: Table Of Contents
TABLE of CONTENTS 1. PRODUCT OVERVIEW..................Page 1 2. PRODUCT DESCRIPTION ................Page 1 3. MODEM SPECIFICATIONS................Page 2 4. SERIAL CONNECTOR SPECIFICATIONS...........Page 3 5. TELEPHONE INTERFACE SPECIFICATIONS ..........Page 5 6. POWER SUPPLY SPECIFICATIONS ............Page 6 7. ENVIRONMENTAL SPECIFICATIONS............Page 8 8. APPROVALS ....................Page 8 BOARD LAYOUT DRAWING APPENDIX A: CONNECTOR PIN DEFINITIONS..........Page A-1 APPENDIX B: AT COMMAND SET..............Page B-1... -
Page 3: Product Overview
DC (battery) or unregulated 9.5 to 18.0 volt power inputs. The unregulated power inputs are also suitable for use with 6.0 volt and 12.0 volt solar power systems. 2.4 Mechanical The BBI-14.4 consists of two printed circuit boards: A single two sided baseboard and a four layer modem board (Telenetics PE14.4) 0049-0001-000 Rev.B... -
Page 4: Modem Specifications
3. MODEM SPECIFICATIONS The BBI-14.4 modem capabilities are based upon the Rockwell RC144ACL modem chipset. Modem control is through the industry standard 'AT' command set. The BBI-14.4 provides all popular error correction and data compression capabilities. The BBI-14.4 provides the following modem features. -
Page 5: Serial Connector Specifications
(3) connectors: the TTL levels are present on two (2) connectors; The BBI-14.4 RS-232E and TTL signals interfaces are independent. All RS-232E signals are internally connected together; likewise, all TTL signals are internally connected together. The RS-232E signals, though, are not internally connected to the TTL signals. - Page 6 232E DTR signal will power up the BBI-14.4 and its RS-232E line drivers. Communication to and from the BBI-14.4 will be through the RS-232 E serial interface only. The TTL serial interface signals will be clamped at inactive signal levels. Also in this configuration, when incoming ring has been detected, the RS-232E interface will become active.
-
Page 7: Telephone Interface Specifications
The BBI-14.4 contains telephone circuitry for connection to the public switched telephone network. The circuitry is suitable for loop start telephone lines. The BBI-14.4 has both primary and alternate telephone connectors. The primary connector is used for connecting RJ-11 terminated cabling. The alternate telephone connectors provide terminal strip wiring of telephone cabling. -
Page 8: Power Supply Specifications
6. POWER SUPPLY SPECIFICATIONS The BBI-14.4 contains a low quiescent power regulator. The BBI-14.4 also has a "low power" standby mode which minimizes overall power requirements when the BBI-14.4 is used intermittently. 6.1 Power Supply Selection ~ The power supplies are selected through the use of a multi-pin ganged header (JP1A, B &... - Page 9 Active Supply Current: 125 mA In-Rush Current: <250 mA Reverse Protection Method: TransZorb TVS and I.C. Internal Protection Over-Voltage Clamp limit: Zener diode Serial Data Interface Supported: RS-232 only 0049-0001-000 Rev.B BBI-144B Installation, Operation & Diagnostics Page 7...
- Page 10 If the BBI-14.4 determines the ring invalid, it returns to standby mode after 30 seconds. If the ring is valid, the BBI-14.4 will answer the call. (Note that the BBI-14.4B must be in the auto-answer mode, i.e.: S0=1 or greater, see Appendix B) 0049-0001-000 Rev.B...
-
Page 11: Environmental Specifications
7. ENVIRONMENTAL SPECIFICATIONS The BBI-14.4 meets the following environmental specifications. Operating Temperatures -40 to 85 Storage Temperature -55 to 100 Relative Humidity 0 to 95% non-condensing. Altitude 20,000 ft (operating), 40,000 ft (shipping). Vibration Effect Withstand 10 to 500 Hz at 1 g on any axis per SAMA PMC-31-1 without damage or impairment. -
Page 12: Appendix A: Connector Pin Definitions
BBI-14.4 transmit data BBI-14.4 data terminal ready BBI-14.4 ground data set ready from BBI-14.4 request to send BBI-14.4 clear to send from BBI-14.4 ring indication from BBI-14.4 PGND shield protective ground BBI-14.4 Installation, Operation & Diagnostics Page A-1... - Page 13 Definition Dial Leased Line Tip or Ring 2-Wire: Tx/Rx 4-Wire:Tx Tip or Ring 2-Wire: Tx/Rx 4-Wire:Tx 2-Wire: Not Used 4-Wire:Rx 2-Wire: Not Used 4-Wire:Rx K-GND key ground (not used) key output (not used) BBI-14.4 Installation, Operation & Diagnostics Page A-2...
- Page 14 Unregulated 9.5 - 18VDC Jumper Position JP1C, Pins 1-2 Battery/Solar Power (5.5 to 7VDC) JUMPER RS-232 / TTL Data Interface Selector Jumper Position 1-2 RS-232 only Jumper Position 2-3 TTL with RS232 override BBI-14.4 Installation, Operation & Diagnostics Page A-3...
-
Page 15: Appendix B: At Command Set
A summary of the Rockwell command set is provided on the following pages B-3 through B-6. The revision of the Rockwell firmware within the BBI-14.4 is Telenetics Version 1.4T. BBI-14.4 Command Set Modifications The BBI-14.4 contains a modified version of the standard Rockwell AT command set. These modifications are as follows: &DN Modification The &Dn command is configure in active profile 0 during Final System test, for &D0 so... - Page 16 &Z0 (up to 45 digits). Command \D0 (default) will disable the Auto Dial feature. IDENTIFICATION PARAMETER Command I3 will report the firmware version V2.41_T1442. BBI-14.4 Installation, Operation & Diagnostics Page B-2...
- Page 17 Wait for Dial Tone For Period Set by S7 register Quiet Answer: Wait for 5 seconds of Silence Before Dialing Hookflash: Commonly Used PBX Systems Reverse Answer Mode Dial Stored Number n=0 - 3 BBI-14.4 Installation, Operation & Diagnostics Page B-3...
- Page 18 Modem Goes on HOOK and Return to Command Mode when DTR Goes OFF &D3 Modem Initializes when DTR Goes OFF &F Fetch S Register from EPROM for Factory Default &G0 No Guard Tone -DEFAULT BBI-14.4 Installation, Operation & Diagnostics ge B-4...
- Page 19 Report the line signal quality. Selects AutoDial mode DTR is switched from OFF to ON the number in Z0 location will be dial Auto Dial disable (default) Disable modem to modem flow control. BBI-14.4 Installation, Operation & Diagnostics Page B-5...
-
Page 20: Ecc Commands
Set maximum block size in MNP to 64. Set maximum block size in MNP to 128. Set maximum block size in MNP to 192. Set maximum block size in MNP to 256. Send break of n x 100 ms. BBI-14.4 Installation, Operation & Diagnostics Page B-6... -
Page 21: Appendix C: Factory Configuration
APPENDIX C: The BBI-14.4B is factory configured with the following changes to the standard Rockwell AT default settings... &C1 &G0 &K0 &Q6 &R1 &T5 S0=1 S11=95 &W0 (Stores the above in Profile 0) BBI-14.4 Installation, Operation & Diagnostics Page C-1... -
Page 22: Appendix D: Diagnostics
The modem is configured for local digital loopback, DSR is turned off (if &S1 is in effect), the test timer is started with the value in S18, and an OK result code is BBI-14.4 Installation, Operation & Diagnostics Page D-1... - Page 23 ERROR result code to the DTE and returns to the command state. The local modem sends the signal to release the remote digital loopback when the test is terminated. BBI-14.4 Installation, Operation & Diagnostics Page D-2...
- Page 24 When command executed is started. After error count is sent to DTE (&T1, &T3, &T6, &T7 or &T8). ERROR If not in on-line command state. ERROR If the RDL signal is not acknowledged. BBI-14.4 Installation, Operation & Diagnostics Page D-3...
- Page 25 (Eye Quality Monitor is the filter squared magnitude of the error vector). Typical value should be below 10. The lower the number, the better the performance from the modem. ERROR response if NO connection to remote modem. In &T1, modem %Q will be 0. BBI-14.4 Installation, Operation & Diagnostics Page D-4...
- Page 26 Other modem did not respond after many transmissions of the same message. Modem made 10 attempts then hung up. Protocol violation occurred. Compression failure. Note: Multiple occurrences may contribute to a NO CARRIER message; S86 records the first event that occurred. BBI-14.4 Installation, Operation & Diagnostics Page D-5...
