- Page 1 Network Turret Camera Quick Start Guide...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be "Hikvision"). This user manual (hereinafter referred to be "the Manual") cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
-
Page 4: Regulatory Information
Network Turret Camera·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 5 Network Turret Camera·Quick Start Guide 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE"...
-
Page 6: Safety Instruction
Network Turret Camera·Quick Start Guide This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into "Warnings" and "Cautions" Warnings: Serious injury or death may occur if any of the warnings are neglected. - Page 7 Network Turret Camera·Quick Start Guide ● Input voltage should conform to IEC60950-1 standard: SELV (Safety Extra Low Voltage) and the Limited Power Source with. Please refer to the appropriate documentation for detailed information. ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.
- Page 8 Network Turret Camera·Quick Start Guide ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ● Do not touch sensor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.
- Page 9 Network Turret Camera·Quick Start Guide and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details. ● This equipment is not suitable for use in locations where children are likely to be present. ●...
- Page 10 Network Turret Camera·Quick Start Guide responsibility for problems caused by unauthorized repair or maintenance.)
-
Page 11: Table Of Contents
Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ............11 2 Installation ................16 Memory Card Installation ..........16 Ceiling Mounting ............... 17 Mounting with Junction Box ..........20 Mounting with Inclined Base ..........22 Wall Mounting ..............24 Install Network Cable Waterproof Jacket ...... -
Page 12: Appearance Description
Network Turret Camera·Quick Start Guide 1 Appearance Description Type I: Figure 1-1 Type I Turret Camera Overview Description Description Enclosure Camera Body Mounting Base Power Cord Network Cable... - Page 13 Network Turret Camera·Quick Start Guide Type II: Figure 1-2 Type II Turret Camera Overview Description Description Enclosure Lens Camera Body Mounting Base Network Cable...
- Page 14 Network Turret Camera·Quick Start Guide Description Power Cord Front Cover Type III: Figure 1-3 Type III Turret Camera Overview Description Description Enclosure...
- Page 15 Network Turret Camera·Quick Start Guide Description Lens Camera Body Mounting Base Network Cable Power Cord Memory Card Slot Cover Front Cover Type IV: DC12 V I N Figure 1-4 Turret Camera Overview Description...
- Page 16 Network Turret Camera·Quick Start Guide Description Enclosure Camera Body Mounting Base Power Cord Network Cable Note: For cameras support power over Ethernet (PoE), the power is passed along with data on Ethernet cabling. And a switch supports PoE function is required.
-
Page 17: Installation
Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is PoE or 12 VDC, make sure your power supply matches with your camera. -
Page 18: Ceiling Mounting
Network Turret Camera·Quick Start Guide Unscrew the Cover and Insert Memory Card 3. Insert the memory card into the memory card slot. 4. (Optional)To unmount the memory card, push to get it ejected. 5. Screw the cover back to the camera. Ceiling Mounting Note: This camera series shares the same installation method, and we take... - Page 19 Network Turret Camera·Quick Start Guide Note: Drill the cable hole, when adopting ceiling outlet to route the cable. Figure 2-2 The Drill Template 3. Disassemble the camera. 1). Rotate the camera to align the notch to one of the marks. 2).
- Page 20 Network Turret Camera·Quick Start Guide Notes: In the supplied screw package, both self-tapping screws, and expansion bolts are contained. If the ceiling is cement, expansion bolts are required to fix the camera. If the ceiling is wooden, self-tapping screws are required.
-
Page 21: Mounting With Junction Box
Network Turret Camera·Quick Start Guide whether the image is gotten from the optimum angle. If not, adjust the surveillance angle. Figure 2-6 Adjust Surveillance Angle 1). Hold the camera body and rotate the enclosure to adjust the pan angle [0° to 360°]. 2). - Page 22 Network Turret Camera·Quick Start Guide Steps: 1. Paste the drill template (supplied) to the desired mounting position on the wall. 2. Drill the screw holes and the cable hole in the wall according to the drill template. Figure 2-7 Drill Template 3.
-
Page 23: Mounting With Inclined Base
Network Turret Camera·Quick Start Guide Figure 2-9 Secure the Body of Junction Box on the Ceiling/Wall 5. Combine the cover of junction box with its body with supplied screws. 6. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the installation. - Page 24 Network Turret Camera·Quick Start Guide Figure 2-10 Drill Template 3. Disassemble the inclined base by the screw driver. 4. Install the mounting base of turret camera on the inclined base cover with three PM4 screws. Figure 2-11 Fix Mounting Base 5.
-
Page 25: Wall Mounting
Network Turret Camera·Quick Start Guide Figure 2-12 Fix the Body of Inclined Base on Ceiling/Wall 6. Combine the cover of inclined base with its body with supplied screws. 7. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the installation. -
Page 26: Install Network Cable Waterproof Jacket
Network Turret Camera·Quick Start Guide 3. Install the mounting base of the camera to the wall mounting bracket and secure them with supplied screws Figure 2-14 Install the Mounting Base on the Wall Mounting Bracket 4. Repeat steps 5 to 8 of 2.2 Ceiling Mounting to complete the installation. - Page 27 Network Turret Camera·Quick Start Guide Steps: 1. Feed the network cable through ① and ③ in order. 2. Fix ② on the network cable between ① and ③. 3. Place ⑤ onto the end of ⑥, and plug the RJ45 male connector into RJ45 female connector.
-
Page 28: Activate And Access Network Camera
Network Turret Camera·Quick Start Guide 3 Activate and Access Network Camera Scan the QR code to get Activate and Visit Network Camera. Note that mobile data charges may apply if Wi-Fi is unavailable. - Page 29 UD18026B-B...
