  • Page 1 Network Bullet Camera Quick Start Guide...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be "Hikvision"). This user manual (hereinafter referred to be "the Manual") cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network Bullet Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 5 Network Bullet Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 Network Bullet Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into "Warnings" and "Cautions" Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 7 Network Bullet Camera·Quick Start Guide the restrictions applied to the location and about any precautions that shall be taken. ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
  • Page 8 Network Bullet Camera·Quick Start Guide ● Do not touch sensor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period, please replace the lens cap to protect the sensor from dirt.
  • Page 9 Network Bullet Camera·Quick Start Guide ● Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. ●...

  • Page 10: Table Of Contents

    Network Bullet Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 2 Installation ..................13 Memory Card Installation ..........13 Camera Mounting ............14 Camera Mounting with Junction Box......17 Waterproof Measures ........... 20 2.4.1 Install Network Cable Waterproof Jacket .... 21 2.4.2 Waterproof Other Cables ........

  • Page 11: Appearance Description

    Network Bullet Camera·Quick Start Guide 1 Appearance Description Type I: Type I Bullet Camera Overview Description Description Lens Front Cover Back Cover Fix Ring Power Cord Network Cable...
  • Page 12 Network Bullet Camera·Quick Start Guide Type II: Type II Bullet Camera Overview Description Description Lens Front Cover Back Cover Mounting Base Power Cord Network Cable...
  • Page 13 Network Bullet Camera·Quick Start Guide Type III: Type III Bullet Camera Overview Description Description Lens Front Cover Memory Card Slot Cover Back Cover Mounting Base Power Cord Network Cable Note: For cameras support power over Ethernet (PoE), the power is passed along with data on Ethernet cabling.

  • Page 14: Installation

    Network Bullet Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera.

  • Page 15: Camera Mounting

    Network Bullet Camera·Quick Start Guide Unscrew the Cover and Insert Memory Card 2. Insert the memory card into the memory card slot. 3. (Optional) To unmount the memory card, push to get it ejected. 4. Screw the cover back to the camera. Camera Mounting Before you start: Both wall mounting and ceiling mounting are suitable for the bullet...
  • Page 16 Network Bullet Camera·Quick Start Guide Note: Drill the cable hole, if adopting ceiling outlet to route the cable. 3-Φ 4 mm Screw Hole Φ 55 mm Φ 68 mm Cable Hole Φ 18 mm template Side Opening Figure 2-2 The Drill Template 3.
  • Page 17 Network Bullet Camera·Quick Start Guide Figure 2-3 Fix the Camera on the Ceiling/Wall Note: In the supplied screw package, both self-tapping screws, and  expansion bolts are contained. If the ceiling is cement, expansion bolts are required to fix the ...

  • Page 18: Camera Mounting With Junction Box

    Network Bullet Camera·Quick Start Guide 5) Loosen the No.3 fix ring to adjust the pan position [0° to 360°]. 6) Tighten the No.3 fix ring. Figure 2-4 3-aix Adjustment 7. (Optional) Install the waterproof jacket. Refer to 2.4 Waterproof Measures for details. Camera Mounting with Junction Box Before you start: Both wall mounting and ceiling mounting are suitable for the...
  • Page 19 Network Bullet Camera·Quick Start Guide 2. Drill the screw holes and the cable hole (optional) in the wall/ceiling according to the drill template. Note: Drill the cable hole, if adopting ceiling outlet to route the cable. Screw 3 - Φ 4 mm Hole Φ...
  • Page 20 Network Bullet Camera·Quick Start Guide Waterproof Cover Cable Gland Figure 2-7 Fix the Junction Box on the Wall 6. Route the cables through the cable hole. Here we take bottom cable hole as the example to describe the installation. 1). Separate the waterproof cover and the cable gland from the junction box.

  • Page 21: Waterproof Measures

    Network Bullet Camera·Quick Start Guide Figure 2-8 Combine Junction Box's Cover with its Body 8. Repeat steps 5 to 7 of 2.2 Camera Mounting to complete the installation. Waterproof Measures If the camera is installed outdoor, you should use the waterproof accessory or tapes to waterproof the cables.

  • Page 22: Install Network Cable Waterproof Jacket

    Network Bullet Camera·Quick Start Guide 2.4.1 Install Network Cable Waterproof Jacket Align Install Waterproof Jacket Figure 2-9 Steps: 1. Feed the network cable through ① and ③ in order. 2. Fix ② on the network cable between ① and ③. 3.
  • Page 23 Network Bullet Camera·Quick Start Guide Waterproof Cables...

  • Page 24: Set The Network Camera Over The Lan

    Network Bullet Camera·Quick Start Guide 3 Set the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 25: Activate The Camera

    Network Bullet Camera·Quick Start Guide Activate the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via web browser, activation via SADP, and activation via client software are all supported. We will take activation via SADP software and activation via web browser as examples to introduce the camera activation.
  • Page 26 Network Bullet Camera·Quick Start Guide Activation Interface (Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 27: Activation Via Sadp Software

    Network Bullet Camera·Quick Start Guide 5. Click OK to save the password and enter the live view interface. Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts.

  • Page 28: Modify The Ip Address

    Network Bullet Camera·Quick Start Guide 3. Create and input the new password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 29 Network Bullet Camera·Quick Start Guide 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address Note: You can enable the HiLookVision service for the device during...
  • Page 30 Network Bullet Camera·Quick Start Guide 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 31: Access Via Web Browser

    Network Bullet Camera·Quick Start Guide 4 Access via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 32 Network Bullet Camera·Quick Start Guide 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 33: Operate Via Hilookvision App

    Network Bullet Camera·Quick Start Guide 5 Operate via HiLookVision App Purpose: HiLookVision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: HiLookVision service is not supported by certain camera models. Enable HiLookVision Service on Camera Purpose: HiLookVision service should be enabled on your camera before using...

  • Page 34: Enable Hilookvision Service Via Web Browser

    Network Bullet Camera·Quick Start Guide Verification Code Setting (SADP) Note: The verification code is required when you add the camera to HiLookVision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. Enable HiLookVision Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 35 Network Bullet Camera·Quick Start Guide 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access. Platform Access Configuration (Web) 3. Select Platform Access Mode as HiLookVision. 4. Check the checkbox of Enable. 5. Click and read "Terms of Service" and "Privacy Policy" in pop-up window.

  • Page 36: Hilookvision Setup

    Network Bullet Camera·Quick Start Guide HiLookVision Setup Steps: 1. Download and install the HiLookVision app by searching "HiLookVision" in App Store or Google Play 2. Launch the app and register for a HiLookVision user account. 3. Log in HiLookVision app after registration. Add Camera to HiLookVision Before you start: You need to enable the HiLookVision service on camera before...
  • Page 37 Network Bullet Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 38: Initialize The Memory Card

    Network Bullet Camera·Quick Start Guide Initialize the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
  • Page 39 UD14160B...
