aSSEMBLY
STEP1 Rear stabilizer :
Insert the M10*94 carriage screws (16) through rear stabilzier (2) and rear metal plate of the main frame (1),
then use M10 nylon cap (18) and M10 arc washer (11) to lock it up.
STEP 2 : Front stabilizer
Insert M10*94 carriage screw (16) through the front stabilizer (3) and front metal plate of the main frame (1),
then use M10 nylon cap (18) and M10 arch washer (11) to lock it tight.
16
16
3
1
18
11
11
18
11
18
5L
4
18
11
2
16
16
5R
1
