cautioN
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this man-
ual
for future reference.
USERʼS MANUAL
Visit our website
www.iconsupport.eu
Advertisement
Table of Contents
Related Manuals for Weslo WLEVEL71710.0
Summary of Contents for Weslo WLEVEL71710.0
- Page 1 USERʼS MANUAL Model No. WLEVEL71710.0 Serial No. ___________ Write the serial number in the space above for reference. QuEStioNS ? If you have questions, or if there are missing parts, please contact us: UK Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu...
-
Page 2: Table Of Contents
taBLE oF coNtENtS WARNING DECAL PLACEMENT ......1 IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . -
Page 3: Important Precautions
iMPoRtaNt PREcautioNS WaRNiNG : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. icoN assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFoRE You BEGiN Thank you for purchasing the WESLO . The el- number and serial number before contacting us. liptical provides an array of features designed to The model number is WLIVEL86110.0 and the lo- make your workouts at home more effective and cation of the serial number decal are shown on the enjoyable. -
Page 5: Assembly
aSSEMBLY STEP1 Rear stabilizer : Insert the M10*94 carriage screws (16) through rear stabilzier (2) and rear metal plate of the main frame (1), then use M10 nylon cap (18) and M10 arc washer (11) to lock it up. STEP 2 : Front stabilizer Insert M10*94 carriage screw (16) through the front stabilizer (3) and front metal plate of the main frame (1), then use M10 nylon cap (18) and M10 arch washer (11) to lock it tight. -
Page 6: When You Connect The Tcd Upper And Lower Segment
STEP 3 Pedals : Attach the right pedal (10R) on the right pedal tube (5R). Insert the outer hexagon screw M10*40 (26) through the pedal and pedal tube. Use M10 flat washer (31) and M10 nylon cap (18) to lock them tight. Attach the left pedal (10L) on the left pedal tube (5L). - Page 7 STEP 6 Upper and lower swing bars Take the left upper swing bar (7L) close to the left lower swing bar (6L) and then connect the hand pulse wire1 (96) and the hand pulse wire 2(28) Insert the left upper swing bar (7L) into the left lower swing bar (6L);...
-
Page 8: Features Of The Console
FEatuRES oF tHE coNSoLE HoW to uSE tHE coNSoLE Make sure that the console has batteries (see assembly step 5 on page 7). If there is a sheet of clear plastic on the face of the console, remove it. 1. turn on the console To turn on the console, press any button on the console or simply begin pedaling. -
Page 9: How To Operate The Elliptical
HoW to uSE tHE ELLiPticaL HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER To mount the elliptical exerciser, hold the upper body arms and step onto the pedal that is in the lowest position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous motion. -
Page 10: How To Measure Your Pulse
HoW to MEaSuRE YouR PuLSE Measure your heart rate if desired. When you are finished exercising, the console will turn off automatically. You can measure you heart rate using either the If the pedals do not move for several seconds, a handgrip pulse sensor or the optional chest pulse tone will sound and the console will pause. -
Page 11: Maintenance And Troubleshooting
MaiNtENaNcE aND tRouBLESHootiNG BattERY REPLacEMENt IInspect and tighten all parts of the exercise cycle regularly. If the console display becomes dim, the batteries Replace any worn parts immediately. should be replaced; most console problems are the To clean the exercise cycle, use a damp cloth and a result of low batteries. -
Page 12: Exercise Guidelines
EXERciSE GuiDELiNES Burning Fat—To burn fat effectively, you must exer- WaRNiNG: cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician. -
Page 13: Suggested Stretches
SuGGEStED StREtcHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. toe touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible. - Page 14 EXPLoDED DRaWiNG—Model No. WLEVEL71710.0 75 76...
-
Page 15: Exploded Drawings
PaRt LiSt—Model No. WLEVEL71710.0 Item Description Qty. Item Description Qty. Main frame Crank (L&R) Rear stabilzier Right body cover Front stabilizer R12 bearing Meter post Crank axle Pedal support tube Crank semi circle button Lower swing bar (L&R) Belt plate Right swing bar (L&R) -
Page 16: Ordering Replacement Parts
oRDERiNG REPLacEMENt PaRtS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
