CLUB SERIES LEG CURL

ASSEMBLY INSTRUCTIONS

Part # 7154701
1
Revision:7/10/01
Rev A.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LEG CURL CLUB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Life Fitness LEG CURL CLUB

Summary of Contents for Life Fitness LEG CURL CLUB

  • Page 1: Assembly Instructions

    CLUB SERIES LEG CURL ASSEMBLY INSTRUCTIONS Part # 7154701 Revision:7/10/01 Rev A.
  • Page 2 PARTS LIST PART # DESCRIPTION PART # DESCRIPTION 69767xx TOWER 3102942 3/8 X 3-1/2” BOLT 6968201 CABLE 3102905 3/8 X 3-3/4” BOLT 6692601 3 X 2 END CAP 3202404 3/8 X 3” BUTTON HEAD BOLT 6714901 GUIDE ROD BUSHING 3102807 3/8”...
  • Page 3 3"...
  • Page 4 3/8 X 2-3/4” 15 3/8 X 3-3/4” 17 FIGURE 1 STEP 1: • LOOSELY assemble the top of the LEG CURL SUPPORT (2) to the TOWER (1) using four RH CAPS (38), two 3/8 X 2-3/4” BOLTS (15), four 3/8” SAE WASHERS (21), four 3/8” RH WASHERS (22) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 1. •...
  • Page 5 3/8 X 3-3/4” 17 FIGURE 2 STEP 2: • LOOSELY assemble the FRONT BRACE (3) to the SEAT FRAME (9) and the TOWER (1) using eight RH CAPS (38), four 3/8 X 3-3/4” BOLTS (17), eight 3/8” SAE WASHERS (21), eight 3/8” RH WASHERS (22), and four 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 2.
  • Page 6 15 3/8 X 2-3/4” 3/8 X 2-3/4” 15 FIGURE 3 STEP 3 • LOOSELY assemble the CROSS SUPPORT (8) to the TOWER (1) and SEAT FRAME (9) using eight RH CAPS (38), four 3/8 X 2-3/4” BOLTS (15), eight 3/8” SAE WASHERS (21), eight 3/8” RH WASHERS (22) and four 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 3.
  • Page 7 18 3/8 X 3” BUTTON HEAD FIGURE 4 STEP 4: • Slide two 2” ACCORDION SLEEVES (30) and two PILLOW BLOCKS (23) over the shaft of the PIVOT ARM (4) as shown in FIGURE 4. • Assemble four 3/8 X 3” BUTTON HEAD BOLTS (18) and four STARLOCK WASHERS (20) to the PILLOW BLOCKS (23) as shown in FIGURE 4.
  • Page 8 CABLE FIGURE 6 STEP 6: • Slide the end of the CABLE into the bushing on the PIVOT ARM (4) as shown in FIGURE 6. • Assemble one 1-1/4” RUBBER BUMPER (28) to the LEG CURL SUPPORT (2) as shown in FIGURE 6. FIGURE 7 15 3/8 X 2-3/4”...

  • Page 9: Pivot Arm Counter Balance

    FIGURE 8 15 3/8 X 2-3/4” STEP 8: • SECURELY assemble the CHEST PAD (37) to the SEAT FRAME (9) using two RH CAPS (38), two 3/8 X 2-3/4” BOLTS (15) and two 3/8” RH WASHERS (22) as shown in FIGURE 8. FIGURE 9 3/8 X 2-1/2”...
  • Page 10 13 3/8 X 2-1/4” FIGURE 10 STEP 10: • SECURELY assemble the CAM COUNTER BALANCE (10) to the PIVOT ARM (4) using four RH CAPS (38), two 3/8 X 2-1/4” BOLTS (13), four 3/8” SAE WASHERS (21), four 3/8” RH WASHERS (22) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 3/8 X 3-1/2”...
  • Page 11 FIGURE 12 HEAVY WEIGHT OPTION STEP 12: • Insert the two GUIDE RODS (12) (found in the SHROUD KIT) into the base of the TOWER (1) as shown in FIGURE 12. Lubricate the GUIDE RODS (12) with a slicon or teflon spray that is available at most hardware stores. •...

  • Page 12: Low Height Lock Nut

    FIGURE 14 14 3/8 X 2-1/2” TIGHTEN! STEP 13: • SECURELY assemble the GUIDE ROD SUPPORT (5) to the TOWER (1) using four RH CAPS (38), two 3/8 X 2-1/2” BOLTS (14), four 3/8” RH WASHERS (22) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 14. (NOTE: Be sure to route cable through the hole of the GUIDE ROD SUPPORT (5) before tightening.) •...
  • Page 13 FIGURE 14 STEP 14: • The WEIGHT STACK LABEL sheet (33) includes labels for both lbs. and kgs. for both the standard and optional weight stacks. • Peel the backing off the WEIGHT STACK LABEL (33), line up sheet to the right of the selector opening and apply labels to the WEIGHT PLATES (34 or 35), starting with the HEAD PLATE (11) as shown in FIGURE 14.
  • Page 14 3/8 X 3-1/2” 39 FIGURE 16 STEP 16: (NOTE: If the PARTIAL SHROUD KIT is being used follow STEP 16. If the FULL SHROUD KIT is being used follow STEP 17) • SECURELY assemble the FRONT PARTIAL SHROUD (41) and the REAR PARTIAL SHROUD (42) to the TOWER (1) using ten 3/8 X 3-1/2”...
  • Page 15 3/8 X 3-1/2” 39 FIGURE 17 STEP 17: • SECURELY assemble the FRONT FULL SHROUD (43) and the REAR FULL SHROUD (44) to the TOWER (1) using eight 3/8 X 3-1/2” BUTTON HEAD BOLTS (39), eight STARLOCK WASHERS (38), and eight 3/8” ACORN NUTS (20) as shown in FIGURE 17.

  • Page 16: Pillow Block

    CAUTION-PLEASE READ There is a risk assumed by individuals who use this type of equipment. To minimize risk, please follow these rules: 1. Inspect equipment daily. Tighten all loose connections and replace worn parts immediately. Failure to do so may result in serious injury. 2.
