Communication protocol for automated processes (32 pages)
Summary of Contents for jbc DI
Page 1
1 TOOL CONTROL UNIT Reference Guide www.jbctools.com...
Page 2
Connectable modules: MS, MV and MN. HEAT MANAGEMENT JBC stations intelligently manage the tool temperature: Work mode: When the tool is used, pre-set work temperature is 350º C. Sleep mode: When the tool is in the stand, the temperature goes down to 220º C.
Page 3
WORKING Tool D R Working tool model Selected temperature Tip temperature Sleep Status P o w e r 1 0 % % Instant power supplied to the tool Decrease & move down Increase & move up Selection SELECT key 2 seconds to enter Menu SETTINGS M a i n m e n u...
Temperature selection from 90 to 450°C (±5%). Power: 75W. Safety transformer, mains separator and double isolation, with temperature protection fuse. DI-2A 230V control unit. Input: 230V 50Hz. Output: 24V. DI-1A 120V control unit. Input: 120V 60Hz. Output: 24V. Total weight of unit: 2 Kg.
