User Manual
WDP-174LM / WDR-174DS
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
www.safemag.ru
www.safemag.ru
Advertisement
Table of Contents
Related Manuals for Commax WDP-174LM
Summary of Contents for Commax WDP-174LM
-
Page 1: User Manual
User Manual WDP-174LM / WDR-174DS • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product. -
Page 2: Table Of Contents
www.safemag.ru Contents 1. Introdution ..............2 2. Important Safeguard ..........3 3. Part names and Functions .........4 4. Configuration...............6 5. Wiring ................7 6. Pairing / Unpairing Method..........7 7. How to use ..............9 8. Installation ..............10 9. Specifications and Features ........12 10. Accessory..............13 www.safemag.ru... -
Page 3: Introdution
The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No. -
Page 4: Important Safeguard
www.safemag.ru 2. Important Safeguards ▲ Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service per- sonnel under the following conditions: ⓐ when the power is damaged. ⓑ if liquid has been spilled or objects have fallen into the unit ⓒ... -
Page 5: Part Names And Functions
www.safemag.ru 3. Part names and Functions Item Function ① Power ② Handset ③ Door Release Button ④ Cord ⑤ Power plug www.safemag.ru... - Page 6 www.safemag.ru Item Function ① Speaker ② Microphone ③ Paging button ④ Door release terminal Power terminal ⑤ (2-wire with non-polarity) www.safemag.ru...
-
Page 7: Configuration
www.safemag.ru 4. Configuration www.safemag.ru... -
Page 8: Wiring
Connect 2 wires from a door release to 4. 6. Pairing / Unpairing Method A. Paring 1) There are three devices, one is WDP-174LM (main unit) WDP-174LS(sub unit) and WDR- 174DS (sub unit). 2) There will be a sound of triple beep as powered on. - Page 9 4) pairing WDP-174LM & WDP-174LS First power on a main unit with the handset off the hook. Within 30 seconds, press the pag- ing button for duration of 5 seconds. With a sound of beep the main unit is in pairing mode for 60 seconds.
-
Page 10: How To Use
7. How to use 1) Press the paging button from the sub unit (WDR-174DS). 2) There will be a paging tone ringing at the main unit (WDP-174LM). and sun unit(WDP-174LS) 3) Pick up the handset to talk.(WDP-174LM/S) 4) Press the door release button while talking to release the door. -
Page 11: Installation
www.safemag.ru 8. Installation SCREW T4X18(2EA) www.safemag.ru... - Page 12 www.safemag.ru GH1T 4X 50 ZnY(2EA) SCREW M3 www.safemag.ru...
-
Page 13: Specifications And Features
Indoor : 40~50 meters Operating 0℃ ~ +40℃ Temperature WDP-174LM/S : except handset : 107 x 195 x 38mm Dimension including handset : 107 x 195 x 51mm WDR-174DS : 91 x 134 x 22mm ※ The effective range of wireless devices can vary depending on the environment, especially around elevator or high voltage cables. -
Page 14: Accessory
10. Accessory WDP-174LM WDR-174DS Screws for wall mount : 2 Ea. Screws for wall mount : 2 Ea Product fixing screw : 1 Ea. Bracket screw for powercord www.safemag.ru... - Page 15 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com PM14WPR17410 Printed In Korea / 2014.04.105 www.safemag.ru...
