User Manual

WDC-244L / WDR-244DS
WDC-244L
WDR-244DS
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

loading
Need help?

Need help?

Do you have a question about the WDC-244L and is the answer not in the manual?

Questions and answers

Summary of Contents for Commax WDC-244L

  • Page 1: User Manual

    WDC-244L / WDR-244DS WDC-244L WDR-244DS • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product.
  • Page 2: Table Of Contents

    Table of Contents 1. Introdution................ 3 2. Important Safeguard ............4 3. Overview................5 4. Instruction Manual ............6 5. Product Installation ............9 6. Specification ..............10 7. Accessory ...............11...
  • Page 3: Introdution

    The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No.
  • Page 4: Important Safeguard

    2. Important Safeguards ▲ Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service per- sonnel under the following conditions: ⓐ when the power is damaged. ⓑ if liquid has been spilled or objects have fallen into the unit ⓒ...
  • Page 5: Overview

    3. Overview WDC-244L ① Microphone ⑤ Power switch ② Speaker ⑥ Volume switch ③ Paging Button ⑦ Power(DC) Connector ④ Select Button...
  • Page 6 WDR-244DS ① Speaker ② Microphone ③ Paging button ④ Door Release terminal ⑤ Power terminal (2-wire, non-polarity)
  • Page 7: Instruction Manual

    After connecting an adaptor, slide 5power switch to turn on the device. Press the paging button For 5 seconds or longer until you hear the sound of a single beep. WDC-244L is now in pairing mode. WDC-244L and WDR-244DS will be paired as both devices are in pairing mode.
  • Page 8 0.1 second to indicate WDC-244L is now in initializing mode. Press 6Volume switch to set a factory default mode. WDC-244L with the sound of a triple beep to indicate it is now in facto- ry default setting.
  • Page 9 Paging Volume Adjustment In standby mode, press the 6Volume switch at the bottom of WDC-244L to adjust the paging volume. It can be adjusted by three levels (low-normal-high) by pressing the button consecutively. If no input for 3 seconds, the device goes back to standby mode.
  • Page 10: Product Installation

    5. Product Installation BH1T 4x38 Zny SCREW M3...
  • Page 11: Specification

    6. Specification Model WDC-244L WDR-244DS Call Method GFSK Power Source , 1A , 1A Standby 0.8W 0.3W Consumption Power 1.2W 1.8W Consumption Communication HANDS FREE (half duplex) Method Display LED(RED) LED(BLUE) Ring tone Chime Distance Open area : 200M, Indoor : 40~50M Temperature -10 ~+40℃(32℉...
  • Page 12: Accessory

    7. Accessory ● WDC-244L 5v / 1A adaptor : 1 ea. ● WDR-244DS Screws for wall mount : 2 ea. Product fixing screw : 1 ea. Power adaptor 12V / 1A : 1 ea. 2P*300(1EA)/ 4P*300(1EA) 켓 벽걸이설치스크류 본체설치스크류 사용설명서...
  • Page 13 MEMO...
  • Page 14 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2014.03.105 PM15WDR24410...
