CUSTOMIZING SETTINGS
1
Press the desired button on the back of the Monitor set.
2
Change the value of the menu item by pressing the buttons on the back of the Monitor set.
To return to the upper menu or set other menu items, press SETTINGS button.
3
Press INPUT button to exit the main menu.
S
DC-IN(19 V
)
H
Button
Moves the menu.
H
Adjusts the menu option and moves the OSD menu.
H
(OK)
When adjusting your display settings, always press the OK button on the MONITOR
H
SETUP OSD. (Only supported in Analog Mode.)
The best display mode 1920 x 1080
(SETTINGS)
Accesses the main menus.
H/P
OSD Locked/OSD
Unlocked
HDMI IN
D-SUB
(INPUT)
You can choose the input signal.
• When two input signals are connected, you can select the input signal (D-SUB/
HDMI) you want.
• When only one signal is connected, it is automatically detected. The default setting is
D-SUB.
Turns the power on or off.
(Power Button)
Power Indicator
OK
SETTINGS
INPUT
Monitor set Buttons
Description
This function allows you to lock the current control settings, so
that they cannot be inadvertently changed.
Press and hold the SETTINGS button for several seconds.
The message "OSD LOCKED" should appear.
You can unlock the OSD controls at any time by pushing the
SETTINGS button for several seconds. The message "OSD
UNLOCKED" should appear.
The power indicator stays red if the display is running properly
(On Mode). If the display is in Sleep Mode, the power indicator
blinks red.
17
CUSTOMIZING SETTINGS
