SETUP GUIDE FOR THE
SUPERBAY™
Golf Simulator Screen Systems
This guide applies to SuperBay's shipped prior to November 7, 2019.
If your SuperBay was shipped o n or after November 7, 2019 , download
the latest installation guide from the
S uperBay product page
.
Advertisement
Table of Contents
Related Manuals for AllSportSystems SUPERBAY
Summary of Contents for AllSportSystems SUPERBAY
- Page 1 Golf Simulator Screen Systems This guide applies to SuperBay’s shipped prior to November 7, 2019. If your SuperBay was shipped o n or after November 7, 2019 , download the latest installation guide from the S uperBay product page...
-
Page 2: All S Portsystems, Inc
All S portSystems, Inc. © 2019. Page 2 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 3: Table Of Contents
Depth Poles ITEMS PROVIDED BY ALLSPORTSYSTEMS BUILDING THE ENCLOSURE FRAME Frame Diagram Step 1 - Add Extender Poles (Applies to SuperBay™ only) Low Ceilings (See Appendix A) Step 2 - Build Bottom Step 3 - Add Rear Height Poles Step 4 - Insert Rear Top Width Pole... - Page 4 All S portSystems, Inc. © 2019. BLACKOUT™ WRAPPER INSTALLATION - What’s Included Step 21 - Install BlackOut™ Bottom Pole Pockets Step 22 - Install BlackOut™ Main Panel Step 23 - Install BlackOut™ Back Panel SAFETY PRECAUTIONS APPENDIX A - BUILDING THE FRAME (For Low Ceilings) Step 1 - Top Rear Width Pole Step 2 - Two Rear Height Poles Step 3 - Stand Rear Height Poles...
-
Page 5: Items You Will Need
Metallic EMT 10-ft Conduit (1” diameter) Hanging SuperBay™: I f you ordered the hanging SuperBay™ please see separate installation guide. You will find our installation guides at the following links. -
Page 6: Measuring And Cutting Emt Poles
Number of Hitting Bay Size 10’ long poles Cut poles as follows: Height: 4 poles c ut to 8’9” ea. SuperBay™ 8 poles Width: 4 poles c ut to 9’9” ea. 10W x 9H Extender: none needed Height: ... -
Page 7: Items Provided By Allsportsystems
All S portSystems, Inc. © 2019. ITEMS PROVIDED BY ALLSPORTSYSTEMS ITEM DESCRIPTION Cable ties 6 ea 3-Way Corners 2 ea Tee Connectors 2 ea L Corner 4 ea Inline Coupler 1 ea Enclosure Netting 1 ea Baffle Back Stop Net, single net same size as screen... -
Page 8: Building The Enclosure Frame
Refer to this diagram often to identify connectors and poles needed for the step by step instructions on the following pages. N ote t hat the 10 Wide SuperBay™ does not use inline couplers to extend the length of the width poles. -
Page 9: Step 1 - Add Extender Poles (Applies To Superbay™ Only)
All S portSystems, Inc. © 2019. Step 1 - Add Extender Poles (Applies to SuperBay™ only) a) For SuperBay™ only, add I nline Couplers a nd Extender poles to each of the four Width poles. Low Ceilings (See A ppendix A... -
Page 10: Step 2 - Build Bottom
Place the bottom rear width pole in the location where you desire the rear of your ● hitting bay to be located. SuperBay™ enclosures should have extender poles already attached to the width pole from previous step. T ip: Always position the eye bolts facing down and toward the inside of the enclosure. -
Page 11: Step 3 - Add Rear Height Poles
All S portSystems, Inc. © 2019. Step 3 - Add Rear Height Poles ● Place 3-way corner connectors on top of two height poles. ● Insert Height poles into each rear 3-Way corner connectors. ● Tighten the connectors. Page 11 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 12: Step 4 - Insert Rear Top Width Pole
All S portSystems, Inc. © 2019. Step 4 - Insert Rear Top Width Pole S uperBay™ enclosures ● With an assistant, and a step ladder, insert rear top width pole. should have extender poles already attached to the width pole from step two. ●... -
Page 13: Step 5 - Build Top Sides
All S portSystems, Inc. © 2019. Step 5 - Build Top Sides ● Insert the Top Depth poles into respective Top Rear 3-way connectors and tighten. ● Slide the TEE connectors onto the Right and Left Top Depth poles, leaving the tees loose (position the TEE connectors so that the eye bolts face the ground). -
Page 14: Step 6 - Install Front Height Poles
All S portSystems, Inc. © 2019. Step 6 - Install Front Height Poles ● Insert two three-way corners to one end of the last two height poles ● Install the front height poles by inserting the bottom into the front L Corner brackets and the top three-way corner into the end of the top depth poles. -
Page 15: Step 7 - Install Tee Pole(S)
All S portSystems, Inc. © 2019. Step 7 - Install Tee Pole(s) S uperBay™ enclosures should ● With an assistant, insert a width pole into the tee brackets. have extender poles already attached to the width pole from step two. Y ou may need to carefully expand the top of the enclosure to fit the tee pole into the tee connectors. -
Page 16: Step 8 - Install Skyrailplus™ Cage Mount (Optional Upgrade)
Note: There is a separate ASSEMBLY GUIDE for the SkyRailPlus, you can download the guide from our website at w ww.allsportsystems.net/user-and-installation-guides/ ● If you have not purchased SkyRailPLUS™ proceed to Step 9. ● The SkyRailPLUS™ mount is installed at the same time as the Front Width Pole. -
Page 17: All S Portsystems, Inc
All S portSystems, Inc. © 2019. Tighten all connectors on the front of the enclosure. Rotate SkyRailPLUS™ into position lining up the hooks with the TEE pole. NOTE: T he HOOKS on the SkyRailPlus™ can slide upto 2” so that TEE pole can be positioned properly. -
Page 18: Step 9 - Install Front Width Pole
All S portSystems, Inc. © 2019. Step 9 - Install Front Width Pole S uperBay™ enclosures should have extender poles ● Insert the TOP FRONT Width pole. already attached to the width pole from step two. Y ou may need to carefully expand the top of the enclosure to fit the top front width pole into its connectors. -
Page 19: Step 10 - Position Tee Pole
All S portSystems, Inc. © 2019. Step 10 - Position Tee Pole ● Loosen the Tee Connectors and slide the Tee Pole forward until it sits approximately 12” from the back of the enclosure. ● Tighten the tee connectors. Page 19 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 20: Step 11 - Check All Connections And Verify Dimensions
Step 11 - Check All Connections and Verify Dimensions ● Proper position of the poles and brackets for the SuperBay™ frame are shown below. N ote that the 10 Wide SuperBay™ does not need extender poles. The tee pole (used to hang the screen) should be 9”... -
Page 21: Install Netting
All S portSystems, Inc. © 2019. INSTALL NETTING Step 12 - Install BlackOut™ Upper Pole Sleeves If you have purchased the BlackOut Wrapper (see B LACKOUT™ WRAPPER INSTALLATION - What’s Included ) install upper pole sleeves at this time. ●... -
Page 22: Step 13 - Install Netting
All S portSystems, Inc. © 2019. Step 13 - Install Netting Place Netting Over Enclosure ● Layout netting locating the TOP REAR CORNERS ● With your assistant walk the netting to the rear of the enclosure ● Using step ladders pull the netting over the outside of the enclosure, covering the back top and sides of the enclosure. -
Page 23: Step 14 - Tighten Netting
All S portSystems, Inc. © 2019. Step 14 - Tighten Netting ● Pull the top and sides of your netting as tightly as possible. ● Tight netting will stop stray golf balls with minimal flexing. Handling Excess Netting ● Any extra netting along the bottom can be “bundled”along the bottom and zip tied in place along the bottom frame. -
Page 24: Step 15 - Install Baffle Net
All S portSystems, Inc. © 2019. Step 15 - Install Baffle Net ● Attach the baffle net to the top tee pole, which should be located about 12” from the back of the enclosure. Using Cable Tites, connect the sides of the baffle net to the outside netting in several places along each side. -
Page 25: Projection Screen Installation
All S portSystems, Inc. © 2019. PROJECTION SCREEN INSTALLATION Step 16 - Install SideRite™ tension kit (optional upgrade) Note: The SideRite™ tension kit comes standard with BlackOut™ Wrapper upgrade. When installed your screen will hang flatter and smoother than the standard method of hanging. (1) On each side of the (2) Cable should be positioned (3) Open turn turnbuckle as fas... -
Page 26: Enclosure Showing Sideright Cables, Netting And Blackout Sleeves Installed
All S portSystems, Inc. © 2019. Enclosure showing SideRight Cables, netting and Blackout Sleeves installed. Page 26 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 27: Step 17 - Attach Screen To Tee Pole
All S portSystems, Inc. © 2019. Step 17 - Attach Screen to Tee Pole Your screen will attach to the tee pole. Tee pole should be approximately 9 to 12 inches from the back of the enclosure and the baffle net should already be installed. ●... -
Page 28: Step 18 - Attach Screen To Sideright Tensioning Kit
All S portSystems, Inc. © 2019. Step 18 - Attach Screen to SideRight tensioning kit The following instructions are for screens with the SideRite™ tension kit upgrade. If you have this upgrade your screen will have grommets down both sides, velcro on the front and BlackOut™ trim flaps sewn to the back. - Page 29 All S portSystems, Inc. © 2019. ● BlackOut™ trim sewn to the back of the screen will wrap from behind and velcro to the front of the screen covering the ties, grommets and cabling. Page 29 of 47 Return to Table of Contents Rev June 6, 2019...
-
Page 30: Step 19 - Standard Screen Installation (No Tensioning Kit)
All S portSystems, Inc. © 2019. Step 19 - Standard Screen Installation (no tensioning kit) Note: T his step is only if you have not recieved the SideRight™ tensioning kit. ● Attach screen to the tee pole in same manner as outlined under S tep 17 - Attach Screen to Tee Pole... -
Page 31: Shotdefender™ Safety Guard (Optional Upgrade)
BlackOut™ upgrade. The ShotDefender™ hangs via a tension cable about 6 inches in front of the screen mounting pole (this is the only pole that is in play in the SuperBay™ enclosures.) Any shots hit toward the screen pole will be defated by the ShotDefender™ Safety Guard and will not return toward the golfer. -
Page 32: All S Portsystems, Inc
All S portSystems, Inc. © 2019. (1) Wrap the ShotDefender™ (2) Open turn turnbuckle as far (3) If there is too much slack in cabling around the upper depth as possible without coming the cable, lossen wire clip nuts poles, approximately 6” in front apart. -
Page 33: Blackout™ Wrapper Installation - What's Included
All S portSystems, Inc. © 2019. BLACKOUT™ WRAPPER INSTALLATION - What’s Included (A) Pole s leeves (2 ea) , to cover the top right and left depth poles and in the case of the SkyRailPlus™, one to cover the SkyRailPlus™... -
Page 34: Step 21 - Install Blackout™ Bottom Pole Pockets
All S portSystems, Inc. © 2019. Step 21 - Install BlackOut™ Bottom Pole Pockets Note: Screen, netting, shot defender, screen tensioner, etc., should already be installed. ● There are two pole pockets. The pockets are large enough to wrap around the bottom depth poles and velcro to itself through the netting. -
Page 35: Step 22 - Install Blackout™ Main Panel
All S portSystems, Inc. © 2019. Step 22 - Install BlackOut™ Main Panel ● With the grommets facing the back of the enclosure, lay the Main Panel across the top and allow each side to drape evenly over the right and left side of the enclosure. ●... - Page 36 All S portSystems, Inc. © 2019. Next, using grommets and cable ties, attached Main Panel to rear of enclosure. Pull BlackOut™ toward the rear as needed so that it pulls evenly along the front of the enclosure. Page 36 of 47 Return to Table of Contents Rev June 6, 2019...
-
Page 37: Step 23 - Install Blackout™ Back Panel
All S portSystems, Inc. © 2019. Step 23 - Install BlackOut™ Back Panel ● Using grommets and cable ties, attached to top rear pole, the sides will velcro to the main panel. Page 37 of 47 Return to Table of Contents Rev June 6, 2019... - Page 38 All S portSystems, Inc. © 2019. ● Blackout Rear Panel Installed Page 38 of 47 Return to Table of Contents Rev June 6, 2019...
-
Page 39: Safety Precautions
All S portSystems, Inc. © 2019. SAFETY PRECAUTIONS We recommend that you position the sides of your enclosure no closer than 12” away from side walls or other objects. We also strongly recommend using “Almost Golf Balls”, or foam balls rather than real golf balls when hitting indoors. -
Page 40: Appendix A - Building The Frame (For Low Ceilings)
2 ea L Corners 2 ea Tee Connectors 6 ea 3-Way Cornesr 4 ea Inline Couplesr (SuperBay™ only) *Poles purchased separately from local hardware store. SEE FOLLOWING PAGES FOR STEP BY STEP INSTRUCTIONS. Page 40 of 47 Return to Table of Contents... -
Page 41: Step 1 - Top Rear Width Pole
Step 1 - Top Rear Width Pole For SuperBay™ only, add In-line Couplers and Extender poles to each of the four Width poles. Position a Width pole on the ground near your back wall. This will become your top rear width pole. -
Page 42: Step 2 - Two Rear Height Poles
All S portSystems, Inc. © 2019. Step 2 - Two Rear Height Poles ● Leaving the pole on the ground, connect two Height poles to the 3-way Corners. Tighten connectors ● Add two more 3-way Corners to the other end of the Height Poles, but do not fully tighten these. -
Page 43: Step 3 - Stand Rear Height Poles
All S portSystems, Inc. © 2019. Step 3 - Stand Rear Height Poles Tip: L eaving the bottom 3-Way Corners loose will allow you to spin them when tilting the rear structure into place. Once it is in place you can then spin them into their proper orientation so as to install the bottom Width Pole. -
Page 44: Step 4 - Add Bottom Rear Width Pole
All S portSystems, Inc. © 2019. Step 4 - Add Bottom Rear Width Pole Next add the Bottom Width Pole and tighten the connectors. Continue to have assistant steady the frame against the wall. Page 44 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 45: Step 5 - Add Bottom Depth Poles
All S portSystems, Inc. © 2019. Step 5 - Add Bottom Depth Poles Insert two Depth poles into the Bottom Rear 3-way Corners and tighten these connectors. The structure will now stand on its own. Page 45 of 47 Return to Table of Contents Rev June 6, 2019... -
Page 46: Step 6 - Add Top Depth Poles And Tee Pole
All S portSystems, Inc. © 2019. Step 6 - Add Top Depth Poles and Tee Pole ● Insert the two remaining Depth poles into the Top Rear 3-way corners and tighten these connectors. ● Slide a Tee connector onto the front of each top Depth pole. ●... -
Page 47: Step 7 - Add Front Height Poles
All S portSystems, Inc. © 2019. Step 7 - Add Front Height Poles ● Place 3-way corners on one end of the two remaining front Height poles. ● Next, attach L Corners onto the other end of the front Height Poles. Tighten connectors. ●...
