- Page 1 877-847-1280 www.allsportsystems.com SETUP GUIDE FOR THE SUPERBAY™ Golf Simulator Screen Systems...
-
Page 2: Table Of Contents
Tools/Equipment Building Materials Not Included MEASURING AND CUTTING EMT POLES Width And Height Poles Depth Poles ITEMS PROVIDED BY ALLSPORTSYSTEMS BUILDING THE ENCLOSURE FRAME Frame Diagram Step 1 - Add Extender Poles Low Ceilings (See Appendix B) Step 2 - Build Bottom... - Page 3 All S portSystems, Inc. © 2020. BLACKOUT™ - What’s Included… Step 22 - Identify A, B and C panels… Step 23 - Install Cascading A & B Panels Step 24 - Install Cascading C Panel Step 25 - Install Ridge Caps Step 26 - Install Rear Panel SAFETY PRECAUTIONS APPENDIX A - SideRite™...
-
Page 4: Items You Will Need
(1” diameter) SkyBay™: I f you ordered the SkyBay™ please see a separate installation guide. All Installation guides can be found on our website www.allsportsystems.com , see ‘ S etup Guides ’ link at the bottom of any page or use the link below…... -
Page 5: Measuring And Cutting Emt Poles
All S portSystems, Inc. © 2020. MEASURING AND CUTTING EMT POLES To calculate total poles needed a dd the number of poles needed from Width and Height chart and poles needed from the Depth chart. Width And Height Poles Number of poles needed varies according to width of enclosure as follows: Number of Hitting Bay Size... -
Page 6: Items Provided By Allsportsystems
All S portSystems, Inc. © 2020. ITEMS PROVIDED BY ALLSPORTSYSTEMS ITEM DESCRIPTION Cable ties 6 ea 3-Way Corners 2 ea T-Connectors 2 ea L-Corners 4 ea Couplers 1 ea Enclosure Netting 1 ea Baffle Back Stop Net, single net same size as screen... -
Page 7: Building The Enclosure Frame
All S portSystems, Inc. © 2020. BUILDING THE ENCLOSURE FRAME Frame Diagram Refer to this diagram often to identify connectors and poles needed for the step by step instructions on the following pages. N ote t hat the 10 Wide SuperBay™ does not use couplers to extend the length of the width poles. -
Page 8: Step 1 - Add Extender Poles
All S portSystems, Inc. © 2020. Step 1 - Add Extender Poles Note: A pplies only to SuperBays™ greater than 10 feet wide. ● Add C ouplers a nd Extender poles to each of the four Width poles. Low Ceilings (See ... -
Page 9: Step 2 - Build Bottom
All S portSystems, Inc. © 2020. Step 2 - Build Bottom Place the bottom rear width pole in the location where you desire the rear of your ● hitting bay to be located. SuperBay™ enclosures should have extender poles already attached to the width pole from the previous step. -
Page 10: Step 3 - Add Rear Height Poles
All S portSystems, Inc. © 2020. Step 3 - Add Rear Height Poles ● Place 3-Way corner connectors on top of two height poles. ● Insert Height poles into each rear 3-Way corner connectors. Verify Dimensions: U se a tape measure to verify correct height and then tighten all ●... -
Page 11: Step 4 - Insert Rear Top Width Pole
All S portSystems, Inc. © 2020. Step 4 - Insert Rear Top Width Pole S uperBay™ enclosures ● With an assistant, and a step ladder, insert the rear top width pole. should have extender poles already attached to the width pole from step two. Verify Dimensions: ... -
Page 12: Step 5 - Build Top Sides
All S portSystems, Inc. © 2020. Step 5 - Build Top Sides ● Insert the Top Depth poles into respective Top Rear 3-Way connectors and tighten. ● Slide the T-connectors onto the Right and Left Top Depth poles, leaving the T connectors loose (position the T-connectors so that the eye bolts face the ground). -
Page 13: Step 6 - Install Front Height Poles
All S portSystems, Inc. © 2020. Step 6 - Install Front Height Poles ● Insert two three-way corners to one end of the last two height poles ● Install the front height poles by inserting the bottom into the front L Corner brackets and the top three-way corner into the end of the top depth poles. -
Page 14: Step 7 - Install Screen Pole
All S portSystems, Inc. © 2020. Step 7 - Install Screen Pole ● With an assistant, insert a width pole into the T-connectors. SuperBay™ enclosures should have extender poles already attached to the width pole from step two. You may need to carefully expand the top of the enclosure to fit the Screen pole into the T-connectors. -
Page 15: Step 8 - Install Skyrailplus™ Cage Mount (Optional Add-On)
Installation guides found website www.allsportsystems.com , see ‘ S etup Guides ’ link at the bottom of any page or use the link below… https://www.allsportsystems.com/setupguides.php The SkyRailPLUS™ mount is installed at the same time as the Front Width Pole... - Page 16 All S portSystems, Inc. © 2020. Rotate SkyRailPLUS™ into position lining up the hooks with the Screen pole which can now slide forward approximately 12 inches from the rear of the enclosure. NOTE: T he HOOKS on the SkyRailPlus™ will slide up to 2” so that the Screen pole can be positioned properly.
-
Page 17: Step 9 - Install Front Width Pole
All S portSystems, Inc. © 2020. Step 9 - Install Front Width Pole ● Insert the TOP FRONT Width pole. SuperBay™ enclosures should have extender poles already attached to the width pole from step two. You may need to carefully expand the top of the enclosure to fit the top front width pole into its connectors. -
Page 18: Step 10 - Position Screen Pole
All S portSystems, Inc. © 2020. Step 10 - Position Screen Pole ● Now slide the Screen Pole forward until it sits approximately 12” from the back of the enclosure and tighten the T-Connectors. Page 18 of 48 Return to Table of Contents February 3, 2020... -
Page 19: Step 11 - Check All Connections And Verify Dimensions
All S portSystems, Inc. © 2020. Step 11 - Check All Connections and Verify Dimensions ● Proper positions of the poles and brackets for the SuperBay™ frame are shown below. ● Note: T he 10 Wide SuperBay™ does not need extender poles. ●... -
Page 20: Step 12 - Install Blackout™ Pole Sleeves
All S portSystems, Inc. © 2020. Step 12 - Install BlackOut™ Pole Sleeves NOTE: I n rare cases you may not receive the BlackOut Wrapper Kit at the same time as your screen and enclosure. In those cases you can continue with the rest of the installation and add the pole sleeves later once they arrive. -
Page 21: Install Netting
All S portSystems, Inc. © 2020. INSTALL NETTING Step 13 - Place Netting Over Enclosure ● Layout netting locating the TOP REAR CORNERS ● With your assistant walk the netting to the rear of the enclosure ● Using step ladders pull the netting over the outside of the enclosure, covering the back top and sides of the enclosure. -
Page 22: Step 14 - Tighten Netting
All S portSystems, Inc. © 2020. Step 14 - Tighten Netting ● Pull the top and sides of your netting as tightly as possible. ● Tight netting will stop stray golf balls with minimal flexing. Step 15 - Handling Excess Netting ●... -
Page 23: Step 16 - Install Baffle Net
All S portSystems, Inc. © 2020. Step 16 - Install Baffle Net ● Hang the baffle net from the Screen pole, which should be located about 12” from the back of the enclosure. Connect the sides of the baffle net to the outside netting with cable ties in several places along each side. -
Page 24: Projection Screen Installation
All S portSystems, Inc. © 2020. PROJECTION SCREEN INSTALLATION Step 17 - Install SideRite™ tension kit Note: The SideRite™ tension kit comes standard and will keep tension on your screen and waves to a minimum. Cables first need to be assembled, See A PPENDIX A - SideRite™... - Page 25 All S portSystems, Inc. © 2020. Enclosure showing SideRite™ Cables, netting and Blackout™ Sleeves installed. Page 25 of 48 Return to Table of Contents February 3, 2020...
-
Page 26: Step 18 - Before Hanging The Screen
All S portSystems, Inc. © 2020. Step 18 - Before hanging the screen: Creases: S creen may have creases from being folded during shipment. These creases will lighten over time. If you wish, you can steam and/or iron the screen prior to hanging. Cleaning: ... -
Page 27: Step 19 - Hang Screen
All S portSystems, Inc. © 2020. Step 19 - Hang Screen Your screen will attach to the Screen pole positioned approximately 12 inches from the back of the enclosure. The baffle net should already be installed on the screen pole. ●... -
Page 28: Step 20 - Attach Screen To Siderite™ Tensioning Kit
All S portSystems, Inc. © 2020. Step 20 - Attach Screen to SideRite tensioning kit ™ The screen will have grommets down both sides and velcro attached to the front. The SideRite™ cables should have been installed at S tep 17 - Install SideRite™... - Page 29 All S portSystems, Inc. © 2020. ● BlackOut™ trim, sewn to the back of the screen, will wrap around cables and velcro to the front of the screen‒covering the side grommets and cabling. Page 29 of 48 Return to Table of Contents February 3, 2020...
-
Page 30: Step 21 - Install Shotdefender™ Cabling
All S portSystems, Inc. © 2020. Step 21 - Install ShotDefender™ cabling NOTE: I n rare cases you may not receive the BlackOut™ Wrapper Kit (which includes the ShotDefender Valance) at the same time as your screen and enclosure. In those cases you can continue with the rest of the installation and add the ShotDefender™... -
Page 31: Blackout™ - What's Included
All S portSystems, Inc. © 2020. BLACKOUT™ - What’s Included… Pole Sleeves (4 ea): Four pole sleeves are used to cover the depth poles along the top and bottom on each side. These are installed prior to netting, screen, SideRite™, and ShotDefender see S tep 12 - Install BlackOut™... -
Page 32: Step 22 - Identify A, B And C Panels
All S portSystems, Inc. © 2020. Step 22 - Identify A, B and C panels… Use the diagrams below to identify each of the panel types (as viewed from underside of panel... A Panel (3 ea) - H as two velcro strips on inside along left edge, a notched corner (lower-left) and grommets along the bottom and back edges. -
Page 33: Step 23 - Install Cascading A & B Panels
All S portSystems, Inc. © 2020. Step 23 - Install Cascading A & B Panels ● How to install panels: ○ First attach the velcro edge by wrapping the panel around the front pole to the velcro strip on the back side of the panel. ○... -
Page 34: Step 24 - Install Cascading C Panel
All S portSystems, Inc. © 2020. Step 24 - Install Cascading C Panel The last cascading panel to be installed is the C Panel. It will be installed on the top center, overlapping the other panels already installed. It will attach in a similar manner as the previous panels by wrapping the velcro edge around the front pole. -
Page 35: Step 25 - Install Ridge Caps
All S portSystems, Inc. © 2020. Step 25 - Install Ridge Caps The Ridge Caps will cover the top right and top left corners of the enclosure. ● First attach the velcro edge by wrapping the Ridge Caps around the front 3-Way corner to the velcro on the back side. -
Page 36: Step 26 - Install Rear Panel
All S portSystems, Inc. © 2020. Step 26 - Install Rear Panel The Rear Panel will attach with cable ties to the upper rear width pole. The left and right side will velcro to the side panels. Page 36 of 48 Return to Table of Contents February 3, 2020... -
Page 37: Safety Precautions
All S portSystems, Inc. © 2020. SAFETY PRECAUTIONS The SuperBay™ is designed for the b ack of the enclosure to sit directly against a wall. However, we recommend positioning the s ides of the enclosure no closer than 12” away from walls or other objects. -
Page 38: Appendix A - Siderite™ And Shotdefender™ Cable Assembly
All S portSystems, Inc. © 2020. APPENDIX A - SideRite™ and ShotDefender™ Cable Assembly When installing the SideRite™ Screen Tension Kit and/or the ShotDefender™ Safety Valance the cabling must first be assembled. SideRite™ Tension Kit: R equires two cables; two turnbuckles and 8 wire clips. ShotDefender: ... -
Page 39: Step 1 - Attach Cable To Turnbuckle
All S portSystems, Inc. © 2020. Step 1 - Attach Cable to Turnbuckle Follow the steps below to attach one end of the cable to eye of turnbuckle: (1) If the end is frayed or unraveled, tape cable (2) Cut the cable at the tape so that cable end is as shown with electrical tape. -
Page 40: Step 2 - Add Eye And Trim Cable To Proper Length
All S portSystems, Inc. © 2020. Step 2 - Add eye and trim cable to proper length Complete cable assembly by first determining the proper length of the cable, forming the eye and then trimming off extra cable. Follow the steps below … (1) ... -
Page 41: Appendix B - Building The Frame (For Low Ceilings)
All S portSystems, Inc. © 2020. APPENDIX B - BUILDING THE FRAME (For Low Ceilings) NOTE: T his method is recommended for situations where the enclosure height is very close to your ceiling height. For safety reasons, we recommend two persons for assembly. Refer to this diagram to identify connectors and poles needed for the step by step instructions on the following pages. -
Page 42: Step 1 - Top Rear Width Pole
All S portSystems, Inc. © 2020. Step 1 - Top Rear Width Pole For SuperBay™ greater than 10 feet wide, add Couplers to extend each of the four Width poles. Position a Width pole on the ground near your back wall. This will become your top rear width pole. Add two 3-Way Corners on each end. -
Page 43: Step 2 - Two Rear Height Poles
All S portSystems, Inc. © 2020. Step 2 - Two Rear Height Poles ● Leaving the pole on the ground, connect two Height poles to the 3-Way Corners. ● Add two more 3-Way Corners to the other end of the Height Poles, but do not fully tighten these. -
Page 44: Step 3 - Stand Rear Height Poles
All S portSystems, Inc. © 2020. Step 3 - Stand Rear Height Poles Tip: L eaving the bottom 3-Way Corners loose will allow you to spin them when tilting the rear structure into place. Once it is in place you can then spin them into their proper orientation so as to install the bottom Width Pole. -
Page 45: Step 4 - Add Bottom Rear Width Pole
All S portSystems, Inc. © 2020. Step 4 - Add Bottom Rear Width Pole Next add the Bottom Width Pole. Verify Dimensions : U se a tape measure to verify correct width dimension and then tighten connectors. You may need to back the poles slightly out of the connectors to reach the correct dimension. -
Page 46: Step 5 - Add Bottom Depth Poles
All S portSystems, Inc. © 2020. Step 5 - Add Bottom Depth Poles Insert two Depth poles into the Bottom Rear 3-Way Corners and tighten these connectors. The structure will now stand on its own. Page 46 of 48 Return to Table of Contents February 3, 2020... -
Page 47: Step 6 - Add Top Depth Poles And Screen Pole
All S portSystems, Inc. © 2020. Step 6 - Add Top Depth Poles and Screen Pole ● Insert the two remaining Depth poles into the Top Rear 3-Way corners and tighten these connectors. ● Slide a T-connector onto the front of each top Depth pole. ●... -
Page 48: Step 7 - Add Front Height Poles
All S portSystems, Inc. © 2020. Step 7 - Add Front Height Poles ● Place 3-Way corners on one end of the two remaining front Height poles. ● Next, attach L-Corners onto the other end of the front Height Poles. Tighten connectors. ●...
