Application Notes for Jabra BIZ 2300 QD Headset with
Avaya 96x1 Series IP Deskphone (H.323 and SIP) - Issue 1.0
These Application Notes describe the configuration steps required to integrate the Jabra BIZ
2300 QD Headset with Avaya 96x1 Series IP Deskphones.
Information in these Application Notes has been obtained through DevConnect compliance
testing and additional technical discussions. Testing was conducted via the DevConnect
Program at the Avaya Solution and Interoperability Test Lab.
LYM; Reviewed:
SPOC 8/24/2014
Abstract
Solution & Interoperability Test Lab Application Notes
©2014 Avaya Inc. All Rights Reserved.
1 of 9
Biz2300QD-96x1
