Assembly; Using The Tool; Adjusting For Tonearm Length (1" = 2,54Cm); Cartridge Alignment - Pro-Ject Audio Systems Align it Instructions For Use

Assembly

Slide the beam into the groove in the base
screw is loosened far enough to allow the beam to move easily.

Using the tool

Loosen the rod's fixing screw
platter so that the hole in the base
By sliding the beam to and fro adjust the cup on the end of the rod
bearing.
After making sure that the base
By reversing the rod so that the pointed end is downward the tool may be used to establish the
vertical axis of other manufacturer's tonearms.

Adjusting for tonearm length (1" = 2,54cm)

Make sure that the beam adjustment mark
Now adjust the beam and its guide using the adjustment screw
.
line of the scale
Adjust the scale (1/3 – 5) to the mark given in the following table appropriate to the Pro-Ject turntable type:
1 For 0.5, 1, 1.2, 1.2 E, 1.2 Comfort, 1.9, Essential, Debut, Debut Esprit, Juke Box, Juke Box Esprit,
Xpression, Xpression Comfort and models equipped with a 8,6" tonearm
2 For 6, 6.1, 6.9, Xperience, 2.9 Wood, 2.9 Classic, Perspective, PerspeX, RPM 4, RPM 5, RPM 5.1,
RPM 6, RPM 6 SB, RPM 6.1 SB, RPM 9, RPM 9 Acryl (X), RPM 9.1, RPM 9.1 Acryl (X),
RPM 9.2 Evolution, Studie, Xtension and models equipped with a 9" tonearm
3 For 2 and models equipped with a 9.35" tonearm
4 For RPM 10, RPM 10.1 Evolution and models equipped with a 10" tonearm
5 For Studie and models equipped with a 12" tonearm
After adjusting the scale, fix the beam's

Cartridge alignment

Mount the cartridge under the headshell. Tighten the screws only enough to just fix the cartridge. Now adjust
the downforce approximately to the manufacturer's recommendation. Check the tonearm height adjustment
and adjust if necessary. Both tasks are described in the instructions supplied with your Pro-Ject record player.
Adjust the cartridge fore and aft using the elongated holes in the headshell so that the needle rests on the
correct overhang mark
Now align the front edge of the cartridge to make it parallel to the lines which run the length of the base.
This adjustment is easier to perform if a thin propelling pencil lead is attached with sticky tape to the front of
the cartridge (provided that this has a flat front edge). Please remember to fasten the cartridge mounting
bolts tightly after completing adjustment. Check the adjustment again after tightening the bolts.

Adjusting azimuth

Loosen the grub screw which fixes the tonearm tube in position as explained in the instructions for use
accompanying your Pro-Ject record player. Lower the arm with the lift so that the needle comes to rest in the
middle of the tool's mirror
surface or until the cartridge's bottom edge is parallel to it. Re-tighten the grub screw. Re-check all
adjustments and repeat the procedures if necessary.
