3.10 Oil Return Operation

Activates the oil return operation to collect refrigerant oil from the field pipes when the following conditions
are met.
[Start conditions]
1. When cumulative compressor operating time from power ON exceeds 2 hours
2. When cumulative compressor operating time from completion of previous return operation exceeds 8
∗1) When defrost control operation for more than 4 minutes with inverter compressor frequency of "A"Hz or
2) When condition 1. or 2. is satisfied during heating operation, the electric heaters of indoor units are
3) The oil return operation is not activated for 28 minutes after the completion of the previous defrosting

[Oil return operation]

[Ending conditions]
RSXYP16KJ
RSXYP18KJ
RSXYP20KJ
RSXYP24KJ
RSXYP26·28·30KJ
Function R-407C PLUS Series
hours.
However, when the upper-limit frequency is limited to less than "A" Hz during the previous oil return
operation, the above time period of 8 hours is changed to 4 hours.
higher, oil return time reset to 8 hours.
turned off 2 minutes prior in order to prepare for the oil return operation.
operation.
The compressor operating frequency is set to "B" Hz shown in the following table.
The oil return operation ends after 1~8 minutes of operation. However, when the compressor stop
conditions are met during an oil return operation, the compressor stops after the completion of the oil
return operation.
When the compressor stops during an oil return preparation operation, the oil return operation is
activated at the next startup.
INV
33Hz
41Hz
41Hz
75Hz
75Hz
When the defrost control needs more than 4 minutes above "A" condition, the timer of oil return is reset
to 8 hours
A
STD1 STD2 INV
ON — 52Hz
ON — 71Hz
ON — 71Hz
ON OFF 52Hz
ON OFF 52Hz
Outline of Control (Outdoor Unit)
B
STD1 STD2
ON —
ON —
ON —
ON ON
ON ON
