Model Configuration And Combination - Daikin VRV R-407C PLUS Series Service Manual

SiE 00-07
1.3

Model Configuration and Combination

Number of units and capacity of connectable indoor units
Standard Equivalent output
series
R-407C VRV PLUS series system model
Outdoor unit combination
Total number of connectable indoor units
Total capacity of connectable indoor units
Standard Equivalent output
series
R-407C VRV PLUS series system model
Outdoor unit combination
Total number of connectable indoor units
Total capacity of connectable indoor units
Connectable indoor unit
Indoor unit
Ceiling Multi-flow type
mounted
Double flow type
cassette type
Corner type
Ceiling mounted built-in type
Ceiling mounted duct type
Ceiling suspended type
Wall mounted type
Floor standing type
Concealed floor standing type
Indoor unit capacity
New refrigerant model code
Selecting model capacity
Equivalent output
Use the above tables to determine the capacities of indoor units to be connected. Make sure the total
capacity of indoor units connected to each outdoor unit is within the specified value (kW).
Combination
example
General Information R-407C PLUS Series
Main unit
Sub unit
Main unit
Sub unit
FXYFP32KVE·40KVE·50KVE·63KVE·80KVE·100KVE·125KVE
FXYCP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·125KV1
FXYKP25KV1·32KV1·40KV1·63KV1
FXYSP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·100KV1·125KV1
FXYMP40KV1·50KV1·63KV1·80KV1·100KV1·125KV1·200KV1·250KV1
FXYHP32KV1·63KV1·100KV1
FXYAP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
FXYLP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
FXYLMP20KV1·25KV1·32KV1·40KV1·50KV1·63KV1
P20 P25 P32
type type type
2.2kW 2.8kW 3.5kW
0.8HP 1HP 1.25HP
The total capacity of connected indoor units must be within a range of 50 to 130% of the rated capacity
of the outdoor unit.
In some models, it is not possible to connect the maximum number of connectable indoor units. Select
models so the total capacity of connected indoor units conforms to the specification.
RSXYP20KJ / 20-unit system
16HP 18HP
RSXYP16KJ RSXYP18KJ
RXYP8KJ RXYP10KJ
RXEP8KJ RXEP8KJ
Up to 20 units
200~520 225~585
26HP
RSXYP26KJ
RXYP16KJ
RXEP10KJ
Up to 32 units
325~845
Model name
P40 P50 P63
type type type
4.5kW 5.6kW 7.0kW 9.0kW
1.6HP 2.0HP 2.5HP 3.2HP
Product Outline
20HP
RSXYP20KJ RSXYP24KJ
RXYP10KJ
RXEP10KJ
Up to 32 units
250~650
28HP 30HP
RSXYP28KJ RSXYP30KJ
RXYP20KJ RXYP20KJ
RXEP8KJ RXEP10KJ
350~910 375~975
P80 P100 P125 P200
type type type type
11.2kW 14.0kW 22.4kW 28.0kW
4HP 5HP 8HP
Indoor unit / FXYCP25K × 20 units
24HP
RXYP16KJ
RXEP8KJ
300~780
P250
type
10HP
(V0806)
5
