Daikin VRV R-407C PLUS Series Service Manual page 30

SiE 00-07
Concealed ceiling unit
Model
Power Supply
1 Cooling Capacity
2 Heating Capacity
Casing
Dimensions: (H×W×D)
Rows×Stages×Fin Pitch
Coil (Cross
Fin Coil)
Face Area
Model
Type
Motor Output × Number
of Units
Fan
Air Flow Rate (H/L)
4 External Static
Pressure
Drive
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Liquid Pipes
Piping Gas Pipes
Connections
Drain Pipe
Weight
Safety Devices
Refrigerant Control
Model
Panel Color
Decoration
Panels
Dimensions: (H×W×D)
Weight
Standard Accessories
Notes:
1 Nominal cooling capacities are based on the following conditions:
2 Nominal heating capacities are based on the following conditions:
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
Specifications R-407C PLUS Series
FXYSP80KV1
1 phase 50Hz
220-240V
kW 9.0
kW 10.0
Galvanized Steel Plate
mm 300×1,400×800
mm 3×14×1.75
m² 0.338
V1 3D18H2AH1V1
Sirocco Fan
W 135×1
m³/min 27/20
Pa 88-49
Direct Drive
Microprocessor Thermostat for
Cooling and Heating
Glass Fiber
Resin Net (with Mold Resistant)
9.5mm (Flare Connection)
15.9mm (Flare Connection)
VP25 (External Dia. 32
(mm)
Internal Dia. 25)
kg 51
Fuse
Thermal Protector for Fan Motor
Electronic Expansion Valve
BYBS125DJW1
White (10Y9/0.5)
mm 55×1,500×500
kg 6.5
Operation Manual, Installation Manual,
Paper Pattern for Installation, Drain
Hose, Clamp Metal, Insulation for
Fitting, Sealing Pads, Clamps, Screws,
Washers.
Return air temperature : 27˚C DB, 19˚C WB, Outdoor temperature : 35˚C DB
Equivalent ref. piping : 5m (Horizontal)
Return air temperature : 20˚C DB, Outdoor temperature : 7˚C DB, 6˚C WB
Equivalent ref. piping : 5m (Horizontal)
means "High static pressure-Standard".
Daikin Europe model : FXYSP-KA7V1
More information can be found in the Technical Data book covering VRV systems
FXYSP100KV1
1 phase 50Hz
220-240V
11.2
12.5
Galvanized Steel Plate
300×1,400×800
3×14×1.75
0.338
3D18H2AH1V1
Sirocco Fan
135×1
28/20.5
98-69
Direct Drive
Microprocessor Thermostat for
Cooling and Heating
Glass Fiber
Resin Net (with Mold Resistant)
9.5mm (Flare Connection)
19.1mm (Flare Connection)
VP25 (External Dia. 32
Internal Dia. 25)
51
Fuse
Thermal Protector for Fan Motor
Electronic Expansion Valve
BYBS125DJW1
White (10Y9/0.5)
55×1,500×500
6.5
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Specifications
FXYSP125KV1
1 phase 50Hz
220-240V
14.0
16.0
Galvanized Steel Plate
300×1,400×800
3×14×1.75
0.338
3D18H2AG1V1
Sirocco Fan
225×1
38/28
78-39
Direct Drive
Microprocessor Thermostat for
Cooling and Heating
Glass Fiber
Resin Net (with Mold Resistant)
9.5mm (Flare Connection)
19.1mm (Flare Connection)
VP25 (External Dia. 32
Internal Dia. 25)
52
Fuse
Thermal Protector for Fan Motor
Electronic Expansion Valve
BYBS125DJW1
White (10Y9/0.5)
55×1,500×500
6.5
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
