Daikin VRV R-407C PLUS Series Service Manual page 91

Test Operation
RSXYP16KJ
RSXYP18KJ
RSXYP20KJ
RSXYP24KJ
RSXYP26KJ
RSXYP28KJ
RSXYP30KJ
Note: Resetting of power supply switch is neccessary after capacity setting.
80
1 Transmission terminal
Indoor unit, Cool/Heat selector
Outdoor - Outdoor
2 Service monitor LED (Green)
3 Function setting mode switch
and LED
4 Function of setting between
cooling and heating
5 Outdoor unit
Capacity setting switch
SS2
A B
Capacity setting table
LED
C/H SELECT
IN/D
Switches for capacity setting when the outdoor unit PC board is replaced
to spare parts PC board.
SS2
A B
Refer table below.
SS3 SS4
C D E F
HAP
LED-A
SERV. MON.
(V0836)
SS1
OUT/D
(V0838)
SS3 SS4 SS5
C D E F G
(V0848)
SS5
G H
Test Operation R-407C PLUS Series
SiE 00-07
H
