Instructions
™
GH
200, EH
™
EH
200 DI DutyMax, EH
Electric Motor Kit
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this
manual. Save these instructions.
3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure
288473: 120 Vac, 60 Hz, 15A
GH130 Sprayer Electric Motor Kit
288474: 120 Vac, 60 Hz, 20A
Same as 288473 except with ETL approval to CSA and UL standards
248949: 120 Vac, 60 Hz, 15A
GH200/GH230 Sprayer Electric Motor Kit
248950: 120 Vac, 60 Hz, 20A
Same as 248949 except with ETL approval to CSA and UL standards
248946: 220 Vac, 50 Hz, 13.4A
EH200/EH200HDI Sprayer Electric Motor Kit
24M668: 220 Vac, 50 Hz, 15.0A
EH200DI Sprayer DutyMax
24M669: 400 Vac, 50 Hz, 11.0A
EH300DI Sprayer DutyMax
™
™
200, EH
200 HDI,
™
- For use with architectural coatings and paints -
300 DI DutyMax
310812K
EN

Advertisement

loading

Related Manuals for Graco GH 200

Summary of Contents for Graco GH 200

  • Page 1 Instructions ™ ™ ™ 200, EH 200, EH 200 HDI, ™ ™ 200 DI DutyMax, EH 300 DI DutyMax 310812K Electric Motor Kit - For use with architectural coatings and paints - IMPORTANT SAFETY INSTRUCTIONS. Read all warnings and instructions in this manual.

  • Page 2: Fire And Explosion Hazard

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 3: Power Requirements

    Grounding Grounding Pulley Placement Sprayer Models: 248559, 248560, 248561,248565, 248566, 248568, 253709, 253957, 253959, 253980, 253960, 253962, 253963, 253981, 253964, 253965, 253966, 253982 Improper installation or alteration of the grounding plug Align pulley (4) approximately 0.20 in. from end of electric will result in a risk of electric shock, fire or explosion that motor shaft.

  • Page 4: Electric Motor

    Parts - 288473, 288474, 248949, 248950 Parts - 288473, 288474, 248949, 248950 • • • • † Ref. Part Description Qty. Ref. Part Description Qty. 111192 SCREW, cap, flange hd 1† ELECTRIC MOTOR 15B562 BRACKET, guard, motor 246129 NON-CSA, 2.0 HP, includes 19 176347 LABEL, identification 246125 CSA, 2.0 HP, includes 19 287145 SWITCH, breaker...
  • Page 5 Wiring Diagram for 196836 Power Cord Wiring Diagram for 196836 Power Cord AirPax NETZ IEG2-28495-2-V Switch FAGOR 4100+ FB5006 B250/220-50 AC Power Supply Black White Motor Thermal Switch ti12480a Wiring Diagram for 24M669 (400 Vac) GREY GREY GREY GREY BLACK BLACK BLACK BLACK...
  • Page 6 8▲ 187975 LABEL, warning (Model 248946) (Model 24M668) 189930 LABEL, warning (Model 24M668) 15B804 LABEL, Graco, logo ▲ Warning labels, tags, and cards are free. 290228 LABEL, caution (Model 248946) 15K616 LABEL, caution (Model 24M668) Breaker Switch Repair Kit 287744 is available.
  • Page 7 Parts - 24M669 Parts - 24M669 ti18618a Ref. Part Description Qty. Ref. Part Description Qty. 112958 NUT, hex, flanged 111193 SCREW, cap flange hd 16M473 TUBE, handle, conversion 116780 SCREW, hex, hd, flanged 113817 BUMPER 125811 PULLEY, cast iron, 8.75 in 100057 SCREW, cap, hex hd 88▲...

  • Page 8: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.

This manual is also suitable for:

Eh 200Eh 200 hdiEh 200 di dutymaxEh 300 di dutymax
