Omcan BE-IT-0337 Instruction Manual page 15

Model BE-IT-0400
Item No. Description
RM 42 A Release 2012 Rear Guard
63551
for M42A
79651 Black Corner Foot Rivet 18mm for M42A
63552 Steel Enclosure for M42A
63553 Steel Slide for M42A
63554 10x37 RM Upper Spacer for M42A
Item No. Description
63563 Lower Cylindrical Roller 1 for M42A
63564 Lower Eccentric Roller 1 for M42A
63565 Lower Cylindrical Shaft 1 for M42A
63566 Lower Eccentric Shaft 1 for M42A
63567 5x438 RM 42 Steel Rod 1 for M42A
63568 RM Lower Small Support 1 for M42A
40640
Position Item No. Description
Motor 110V-60HZ 0, 37kW-0, 5HP B5
03 63556
for M42A
09 63557 Plastic Motor Pulley for M42A
10 63558 Plastic Reduction Pulley for M42A
11 79653 8x680 Belt for M42A
15 63560 Feed Cable SJT3x14AWG for M42A
Position Item No. Description
RM Pizza Dough Scrapper Spring 2
1 79650
for M42A
RM42A-42TA Front Aluminum Pizza
2 63569
Dough Scraper 1 for M42A
RM 42A-42TA Back Aluminum Pizza
3 63570
Dough Scraper 1 for M42A
4 79646 RM Male/Female Group Joint 1 for M42A
5 63571 RM Red RAL 3020 Cap 1 for M42A
6 63572 6200 ZZ Bearing 1 for M42A
Parts Breakdown
Position Item No.
43 63561
44 63562
45 49502
46
52
Position Item No.
7 63573
8 63574
9 63575
10 79647
11 79648
12 79649
15
Complete Unit
Description
Motor Casing Assembly for M42A
KLD-28A Start/Stop Green/Red Button
for M42A
Lower Roller Unit for M42A
Lower Rolling Unit
Description
6202 ZZ Bearing 1 for M42A
RM Cylindrical Screw (Rolls Center
Distance of 50) 1 for M42A
RM Lower Reduction Gear Support 1
for M42A
RM Cylindrical Gear 1 for M42A
RM Eccentric Gear 1 for M42A
Pizza Dough Roll Mach Thickness
Adjustment Group (Red Color) for M42A
Position
54
65
100
Position
13
14
15
16
17
18
