Install the car audio

These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
•
This unit is designed for negative ground
(earth) 12 V DC operation only.
•
Always install this unit in the car dashboard.
Other locations can be dangerous as the rear
of the unit heats up during use.
• To avoid short-circuit: before you connect,
ensure that the ignition is off.
•
Ensure that you connect the yellow and red
power supply leads after all other leads are
connected.
•
Ensure that all loose leads are insulated with
electrical tape.
•
Ensure that the leads do not get caught under
screws orin parts that will move (e.g. seat rail).
• Ensure that all ground (earth) leads are run to
a common ground (earth) point.
•
Use only the supplied mounting hardware for a
safe and secure installation.
•
Improper fuses can cause damage or fire.
When you need to change the fuse, consult a
professional.
Note on the power supply lead (yellow)
• When you connect other devices to this
system, ensure that the rating of the car
circuit is higher than the total fuse value
of all the connected devices.
Notes on speaker connection
• Never connect speaker wires to the
metal body or chassis of the car.
• Never connect speaker wires with stripes
to one another.
Connect wires
Caution
•
Make sure that all loose leads are insulated
with electrical tape.
Note
•
As different cars have different requirements,
you might need to connect CID3695
differently from the user manual's instructions.
Consult a professional mechanic to connect.
Connect parking brake cable and
reverse driving cable to a rear view
backup camera
Note
•
Check your local driving regulations on
whether it is legally required to install the
rear view backup camera. These connections
require a professional mechanic to install.
This car audio video system allows you to
connect to the rear view backup camera. You
can view the things that happens behind your
car in the display, especially you are driving a
big vehicle. This helps protecting your bumper
and anything it might contact.
EN 7
