Mechanical adjustments

Assembling the components

For a left shoulder mobilisation
Kinetec Centura B&W™
7
46
• Install the shoulder depth adjustment bar (46).
• Tighten the knob (7).
9
8
• Install the motor (8).
• Tighten the knob (9).
• Connect the motor.
47
• Install the splint (47), using the colour code as guide:
- Blue for left arm.
- Red for right arm.
It is correctly installed when you hear a click.
13
• Install the arm splint (13).
It is correctly installed when you hear a click.
46
47
17/24
For a right shoulder mobilisation
7
9
8
13
