- Page 4 Part List A)Top Panel 1 pc B)Middle Panel 1 pc C) Left&Right Back Panels 2pcs D)Left&Right Panels 2pcs E)Left&Right Small Panels 2pcs F)Upper Left&Right Small Panels 2pcs G)Middle Left&Right Small Panels 2pcs H)Lower Left&Right Small Panels 2pcs I)Middle Small Front Panels 2pcs J)Left&Right Small Front Panels 2pcs...
- Page 5 Attached 8pcs Connectors (M) to The panels(,F) as show in Fig A Step 1. Left&Right Small Panels Step 2,Attached 16 wood connectors (S ) to the Left&Right Panels and (D.E) as show in Fig B...
- Page 6 Left&Right Small Step 3.Attached 20 pcs wood connectors to the Middle Panel, Left&Right Panels and Panels (B.D.E) as show in Fig C Step 4,Attached Left&Right Small panels(E) to the Base Panel (K ) using 4 Screws(P) by Six-angles wrench(R),Attached the Middle Panel (B) to the Left&Right Small panels(E) using 4 Screws(P) by Six-angles wrench(R).See Fig E.D,F,G...
- Page 8 Step 5 Put the Left&Right Back Panels (C) to the Left&Right Small Panels(E).See Fig H...
- Page 9 Step 6.Attached the Left&Right Panels(D) to the Base Panel(K) using 4 Screws(P) by Six-angles wrench(R) as shown in Fig I.J...
- Page 11 Step 7,Put the Middle Left&Right Small Panels(G) and Lower Left&Right Small Panels(H) in place as show on Fig K...
- Page 12 Insert 8Locking Nuts(N) into each of Step 8,Put the Upper Left&Right Small Panels(F) into the Body, these holes keeping the screw head (+) facing out to enable tightening with screwdriver. See Fig...
- Page 13 Step 9,Attached the Top Panel(A) to the Upper Left&Right Small Panels(F) by 4 Set Locking Nuts and...
- Page 14 Screws(U) as show on Fig N,O Left&Right Small Front Panels Step 10.Connect the (J) to the Left&Right samll Panels(E) by 4 KD Screws(O) as shown on Fig P...
- Page 15 Step 11.Connect the Middle Small Front Panel(I) to the Middle Panel(B) by 2 KD Screws as shown on Fig...
- Page 16 Step 12.Put the insert in place and install the insert to the mantle with 2 Mounting heaters(Q) and 2 Mounting Brackets(R) See Fig.R.S.T...
- Page 17 Step 13. Tighten all KD Screws ON/OFF 750W 1500W...
- Page 21 Blower/Moter Heater Assembly NDF-100NR/51/81 Fireplace Cabinet NDF-100NR/37/18/12 Electric Wire NDF-100NR/89 Switch NDF-100NR/53 Knob NDF-100NR/78 Thermostat NDF-100NR/60 Screen NDF-100NR/41 Flame Generator Motor/Reflector NDF-100NR/42/43/44/68/69 Blub NDF-100NR95/96/97 Log sets NDF-100NR/02/03...
