Summary of Contents for Comfort Glow EF6021R
- Page 4 Part List A)Top Panel 1 pc B)Middle Back Panel 1 pc C)Middle Panel 1 pc D)Left&Right Back Panels 2pcs E)Left&Right Panels 2pcs F)Middle Front Panels 2pcs G)Left&Right Small Panels 2pcs H)Left&Right Small Front Panels 2pcs I)Middle Small Front Panels J)Mounting Heater 2pcs K)Mounting Brackets 2pcs...
- Page 5 Step 2 Put the Left & Right small panels(G) to the base panel(L) and Insert 4Locking Nuts(N) into each of these holes keeping the screw head (+) facing out to enable tightening with screwdriver.See Fig B,C,D...
- Page 6 Step 3 Put the Left&Right Back Panels(D) into the Base Panel(L).SeeFig E Insert 4Locking Nuts(N) into each of these holes keeping the screw Step 4 Put the Middle Panel(C) into the body and head (+) facing out to enable tightening with screwdriver.See Fig F,G...
- Page 7 Insert 4Locking Nuts(N) into each of Step 5 Put the Middle Front Panels (F)to Left&Right samll panels(G) and these holes keeping the screw head (+) facing out to enable tightening with screwdriver.Then put the Left &Right Panels(E) to the Base Panel(G) Insert 4Locking Nuts(N) into each of these holes keeping the screw head (+) facing out to enable tightening with screwdriver.See FigH.I,J,K,L...
- Page 9 Step 6 Put the Middle Back Panel(B) to Middle Panel(C) as show on Fig M Insert 4Locking Nuts(N) into each of these Step 7.Put the Top Panel(A) to the Left&Right Panels(E) and holes keeping the screw head (+) facing out to enable tightening with screwdriver.See Fig N.Q...
- Page 10 Step 8.Connect the Middle Small Front Panel(I) to the Middle Panel(C) by 3 KD Screws as shown on Fig P...
- Page 11 Left&Right Small Front Panels Step 9.Connect the (H) to the Left&Right samll Panels(G) by 6 KD Screws as shown on Fig Q Step 10.Put the insert in place and install the insert to the mantle with 2 Mounting heaters and 2 Mounting Brackets see Fig R.S...
- Page 12 Step 11. Tighten all KD Screws...
- Page 16 Blower/Moter Heater Assembly NDF-100NR/51/81 Fireplace Cabinet NDF-100NR/37/18/12 Electric Wire NDF-100NR/89 Switch NDF-100NR/53 Knob NDF-100NR/78 Thermostat NDF-100NR/60 Screen NDF-100NR/41 Flame Generator Motor/Reflector NDF-100NR/42/43/44/68/69 Blub NDF-100NR95/96/97 Log sets NDF-100NR/02/03...
