Opening the PC Card Slot Cover

The PC card slot is located near the bottom on the back of the

PDT 3200 . Detach the elastic hand strap on the back of the PDT

3200 by pulling its hook out of the holder near the base. The slot

is protected by a cover. Loosen the screw that secures the slot

cover. Then, while pressing the round button above the slot

cover, slide the cover out and away from the PDT 3200, as

shown in the following illustration.

Inserting a PC Card

All PC cards have two rows of small sockets on one end. The

cards also have face-up and face-down sides. The card

manufacturer's label is usually on the face-up side.

Note:

Power the PDT 3200 unit off before inserting or re-

moving a PC card.
