Changing the Scanner Orientation
Normally, the laser window faces the left side of the PDT 3200
for easy right-handed scanning. If you prefer to hold the PDT
3200 in your left hand while scanning, turn the laser module
around.
To rotate the laser module:
1. Unscrew the screw that secures the module to the main
part of the PDT 3200. The screw comes loose but does not
come out of the laser module. Do not try to force it out.
2. Gently lift the laser module away from the top of the main
part of the PDT 3200. The module does not completely
separate from the rest of the PDT 3200. Do not try to force
the units apart.
3. Swivel the module around until the laser window faces
the opposite direction. The module can rotate in only one
direction. Do not try to force it the other way.
