To disconnect the tethered bar code reader from the PDT 3200,
press the sides of the squeeze connector and pull it away from
the PDT 3200's connector.

Setting Up for Communications

The PDT 3200 has a port for serial communications with a PC.
The port is located in the base of the PDT 3200 unit. Designated
as COM1, it is an RJ-45 connector providing a standard RS-232
connection. With a serial cable connected to it, the port allows
communications with a host computer or any serial device, such
as a printer or modem. The serial port also provides a
connection inside the cradle for battery recharging.
Installing and Removing a PCMCIA Card
The PDT 3200 has a slot for plugging in PC cards, and each unit
is factory-equipped with PhoenixCARD Manager Plus PC card
drivers. PC cards provide such features as network connectivity,
modem connectivity, and wireless capability. Their primary
purpose in the PDT 3200 is to provide additional memory
storage by functioning as a disk drive. (See the PDT 3200 Product
Reference Guide for information about the PDT 3200's drives.)
Quick Reference
Serial
Port
