24" INTEGRATED
REFRIGERATOR/FREEZER
RB2470BRV model
INSTALLATION GUIDE
US CA
849695B
10.18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB2470BRV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fisher & Paykel RB2470BRV

  • Page 1 24” INTEGRATED REFRIGERATOR/FREEZER RB2470BRV model INSTALLATION GUIDE US CA 849695B 10.18...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS  SAFETY AND WARNINGS  COMPONENTS LIST  COMPONENTS LIST — DOOR PANELS AND HANDLES  PRODUCT DIMENSIONS  CABINETRY DIMENSIONS  DOOR OPENING ROTATION  ELECTRICAL SPECIFICATIONS  BEFORE INSTALLATION  UNPACKING AND MOVING YOUR PRODUCT  INSTALLATION OVERVIEW  CHANGING OVER DOOR HINGE (OPTIONAL)  INSTALL TRIM CLIPS  INSTALL CABINETRY ATTACHMENT BRACKETS  INSTALL CLEARANCE ADJUSTMENT PLATES  POSITION YOUR PRODUCT INSIDE THE CABINETRY  FIX YOUR PRODUCT INSIDE THE CABINETRY...
  • Page 4: Safety And Warnings

    Read and follow the safety and warnings outlined in this installation guide before operating this product. INTEGRATED REFRIGERATOR 24” INTEGRATED Failure to do so can result in death, electric shock, fire or injury REFRIGERATOR/FREEZER RB2470BRV model RB2470BRV model to persons. RÉFRIGÉRATEUR ENCASTRABLE Modèle RB2470BRV SERVICE & WARRANTY SERVICE ET GARANTIE ΣΈΡΒΙΣ...
  • Page 5  COMPONENTS LIST Pre-installed parts — included with the product. Fasteners — included in the product. Cabinetry attachment Hinge screws (8) Bottom attachment screws (2) screws (4) Top hanging Top hanging Top attachment Door gasket baffle* bracket (2x) bracket cover (2x) ruler (4x) (2x) Wood screws (52) Hinge hole plugs (8) * Used only when transporting the product.
  • Page 6: Components List - Door Panels And Handles

     COMPONENTS LIST — DOOR PANELS AND HANDLES Door handle kits — not included with the product Stainless Steel door panels — Fisher & Paykel (Stainless steel) Custom door panels — Customers can supply their own and must be purchased separately. door panel is not included with the product and must be Custom door panel to match their cabinetry.
  • Page 7: Product Dimensions

     PRODUCT DIMENSIONS  CABINETRY DIMENSIONS Door panel flush with side of cabinetry PLAN VIEW FRONT VIEW SIDE VIEW PRODUCT DIMENSIONS in (mm) Overall height of product 69 3/4” (1773) Overall width of product 21 7/8” (555) Overall depth of product 21 1/4” (540) (excluding door panels) CABINETRY DIMENSIONS in (mm)
  • Page 8: Door Opening Rotation

     DOOR OPENING ROTATION WARNING! Ensure that the product is stable before opening the doors. ● ● Ensure that you follow the instructions to avoid risks that can cause serious injury or death. ● ● Wall Wall 115° DOOR OPENING 90° DOOR OPENING (FULL ROTATION) DOOR OPENING AND CLEARANCE DIMENSIONS in (mm)
  • Page 9: Electrical Specifications

     ELECTRICAL SPECIFICATIONS WARNING! Electric shock hazard! Assume all parts are live. ● ● Disconnect supply before servicing and installation. Alternative area for electrical connection should be on the wall above the cabinetry. Left side of cavity Power cord (excl. plug) — 41 3/8” (1050mm) from top edge of product Electrical Electrical...
  • Page 10: Before Installation

     BEFORE INSTALLATION IMPORTANT! Ensure your product is not exposed to any heat generating products eg cooktop, oven or dishwasher. ● ● The product must be installed by a qualified installer, or Fisher & Paykel trained and supported service technician to avoid faulty electrical connection. ●...
  • Page 11: Unpacking And Moving Your Product

     UNPACKING AND MOVING YOUR PRODUCT IMPORTANT! WARNING! Be careful when unpacking to prevent damage to the surface of your product. Follow these instructions to avoid risks that can cause serious injury or death. ● ● ● ● Ensure that the product is stable to prevent from tipping over when unpacking. Keep doors closed until the product has been moved to its installation location.
  • Page 12: Installation Overview

     INSTALLATION OVERVIEW Clearance adjustment plate Bottom attachment bracket Hanging bracket cover Sensor magnet Bottom attachment bracket cover (Custom door only) Top attachment ruler Cabinetry attachment bracket cover Cabinetry attachment bracket Position adjustment plate Door gasket baffle Wood screw Bottom attachment bracket screw Top hanging bracket...
  • Page 13: Changing Over Door Hinge (Optional)

     CHANGING OVER DOOR HINGE (OPTIONAL) This model is right hinged with a left-opening door. If required, you can change this model to left hinged with a right-opening door. Right hand cover Hinge cover Left hand cover Remove the right hand cover by levering from the outer edge.
  • Page 14: Install Trim Clips

     INSTALL TRIM CLIPS Cabinetry top inside surface 5 1/8” (130mm) 5 1/8” (130mm) Installing trim clips to the cabinetry Install top trim clips (A) to the top inside surface of the cabinetry at a minimum clearance of 5 1/8” (130mm) from the top Installation location side edge of the cabinetry.
  • Page 15: Install Cabinetry Attachment Brackets

     INSTALL CABINETRY ATTACHMENT BRACKETS Install cabinetry attachment bracket to the product Adjust the air flow stops Adjust the air flow stops located on the back cover of the compressor. Ensure the air flow Remove the pre-existing screw/plastic stops make contact with the cabinetry. washer (A) and plastic plugs (B) on the non-hinge side bottom corner of IMPORTANT!
  • Page 16: Install Clearance Adjustment Plates

     INSTALL CLEARANCE ADJUSTMENT PLATES IMPORTANT! Clearance adjustment plates are installed depending on the overall dimensions of your cabinetry (see table for more information). Attach clearance adjustment plates to the door hinges of the refrigerator and freezer doors. – Ensure the correct orientation when attaching the plates. Clearance adjustment plate CABINETRY OUTSIDE WIDTH OF CABINETRY...
  • Page 17: Position Your Product Inside The Cabinetry

     POSITION YOUR PRODUCT INSIDE THE CABINETRY Connecting the product to the power supply Aligning the product inside the cabinetry Move the product in front of the cabinetry close enough that you can access behind to Push the product all the way into the cabinetry and adjust its position. connect the power supply.
  • Page 18: Fix Your Product Inside The Cabinetry

     FIX YOUR PRODUCT INSIDE THE CABINETRY Fix the product to the cabinetry by Slide the cabinetry attachment bracket screwing in all door hinges. towards the cabinetry wall so that the position adjustment plate is pressed against the cabinetry wall, and then fix with a wood screw (A). Tighten the attachment bracket screws (B).
  • Page 19: Install The Trims

     INSTALL THE TRIMS Top trim Slide the LH and RH top corners (A) into the ends of the top trim (B). Fix the top trim to the trim clips (C). Note: You may need to cut the top trim depending on the overall dimensions of your cabinetry.
  • Page 20  INSTALL DOOR PANELS (STAINLESS STEEL) IMPORTANT! Ensure to protect the finish of the Fisher & Paykel Stainless steel door panels. ● ● Leave the protective film on the panels when hanging and remove the film only when the installation is complete. ●...
  • Page 21  INSTALL DOOR PANELS (STAINLESS STEEL) Installing the hanging and attachment brackets Hanging the door panel Open the refrigerator door. Remove the rulers (F) from the top hanging Hang the top door panel onto the height bracket and discard. adjustment nuts (J) at the top of the refrigerator door.
  • Page 22  INSTALL DOOR PANELS (STAINLESS STEEL) Fixing the top door panel Adjusting the door panel Once you are satisfied with the adjustment, fully tighten the screws of the bottom attachment brackets (P) to secure the door panel. Height adjustment of the door panel Turn the height adjustment nuts (M) with a hex key.
  • Page 23  INSTALL TOP DOOR PANEL (CUSTOM) Removing the hanging bracket Top of cabinetry Open the refrigerator door and Push the rulers down so that remove the top hanging bracket the underside of the overhang Flush cover by drawing out upwards. of the ruler is flush with the top of the cabinetry (A).
  • Page 24  INSTALL TOP DOOR PANEL (CUSTOM) Loosening the height adjustment nut Installing the hanging and attachment brackets Before installing the top door panel, you must Lay the top custom door panel remove the door magnet from the refrigerator (face down) onto the floor and door to enable you to access and loosen the place the top hanging bracket on height adjustment nut.
  • Page 25  INSTALL TOP DOOR PANEL (CUSTOM) Hanging the door panel Adjusting the door panel Open the refrigerator door. Hang the top door panel onto the height adjustment nuts (I) at the top of the refrigerator door. Height adjustment of the door panel Turn the height adjustment nuts (N) with a hex key.
  • Page 26  INSTALL BOTTOM DOOR PANEL (CUSTOM) Removing the hanging brackets Open the freezer door and remove the Push the rulers down and close top hanging bracket cover by drawing out the freezer door. Adjust the upwards. rulers so that the top side of the overhang of each ruler contacts the bottom of the top door panel.
  • Page 27  INSTALL BOTTOM DOOR PANEL (CUSTOM) Installing the hanging and attachment brackets Hanging the door panel Lay the bottom custom door panel Open the freezer door. (face down) onto the floor and place Hang the bottom door panel onto the the top hanging bracket on the door height adjustment nuts (D) at the top panel.
  • Page 28  INSTALL BOTTOM DOOR PANEL (CUSTOM) Fixing the bottom door panel Adjusting the door panel Once you are satisfied with the adjustment, fully tighten the screws of the bottom attachment brackets (L) to secure the door panel. Place the bracket covers on the bottom attachment brackets (M).
  • Page 29   INSTALL COVERS AND INLET VENT GRILLE Reinstall the hanging bracket covers Installing the (optional) inlet vent grille Re-insert the hanging bracket covers onto the top hanging brackets. Install the inlet vent grille to the inlet vent at the toe kick section of the cabinetry. –...
  • Page 30  FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER All models Check all parts are installed. Ensure the product is level. Ensure the product is securely fastened to the cabinetry with the supplied fittings. Ensure the doors can open and close freely with no resistance from surrounding cabinetry. Ensure all internal and external packaging is removed from the product before use.
