Infinity S601 Profile Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MANUAL
ENGLISH
Infinity S601 Profile
V1
Ordercode: 41507
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S601 Profile and is the answer not in the manual?

Questions and answers

Related Manuals for Infinity S601 Profile

Summary of Contents for Infinity S601 Profile

  • Page 1 MANUAL ENGLISH Infinity S601 Profile Ordercode: 41507 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...

  • Page 2: Table Of Contents

    One Infinity (Manual) ..............................11 Multiple Infinitys (DMX control) ..........................12 Multiple Infinitys (Wireless DMX Control) ......................13 Connect the Infinity to the Wireless DMX Signal Transmitter ................14 Disconnect the Infinity from the Wireless DMX Signal Transmitter ..............14 Multiple Infinitys (ArtNet Control) ..........................15 Connecting to a Network ............................16...
  • Page 3 Infinity S601 Profile 5. Stand-Alone ................................34 6. Information ................................34 6.1. Fixture Information ............................35 6.2. Fan Information ..............................35 6.3. Error Information ...............................35 DMX Channels ................................36 57 channels (Advanced) ............................41 37 Channels (Basic) ..............................47 Maintenance ..................................52 Replacing the Fuse ..............................52 Gobo Size ..................................52 Replacing a Gobo From the Rotating Gobo Wheel ...................53...

  • Page 4: Warning

    Infinity S601 Profile Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling.
  • Page 5 ● If your Infinity device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Infinity dealer for service.

  • Page 6: Operating Determinations

    Always have the inspections carried out by an authorized dealer! Procedure: ● If the Infinity is lowered from the ceiling or high joists, professional trussing systems have to be used. ● Use a clamp to mount the Infinity, with the mounting bracket, to the trussing system.

  • Page 7: Connection With The Mains

    Infinity S601 Profile The Infinity can be placed on a flat stage floor or mounted to any kind of truss with a mounting bracket and a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug.

  • Page 8: Return Procedure

    Infinity S601 Profile Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

  • Page 9: Description Of The Device

    Infinity S601 Profile Description of the device Features The Infinity S601 Profile is a moving-head with high output and great effects. Output ● Lux @ 5m 6,5°: 29712 ● Lux @ 5m 45°: 1124 ● Beam angle: 6,5° - 45°...

  • Page 10: Physical

    Infinity S601 Profile Physical ● Color: Black ● Housing: Metal & flame-retardant plastic ● Data connection: 5-pin Neutrik XLR & RJ-45 IN/OUT ● Power connection: Neutrik PowerCON True1 IN/OUT ● Fuse: F13AL/250V ● Dimensions: 284 x 420 x 748 mm (LxWxH) ●...

  • Page 11: Backside

    11) Neutrik PowerCON True1 power connector OUT Installation Remove all packing materials from the Infinity S601 Profile. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly.

  • Page 12: Set Up And Operation

    03) Plug the end of the electric mains power cord into a proper electric power supply socket. 04) When the Infinity is not connected with a DMX cable, it functions as a stand-alone device. 05) Please see pages 34 for more information about Stand-alone mode.

  • Page 13: Multiple Infinitys (Dmx Control)

    02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 5-pin XLR cable to connect the Infinity and other devices. 04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"...

  • Page 14: Multiple Infinitys (Wireless Dmx Control)

    Infinity S601 Profile Multiple Infinitys (Wireless DMX Control) 01) Install multiple Infinitys at the desired positions (maximum Wi-Fi distance: 250 m). 02) In order for the Infinitys to receive a wireless DMX signal properly, activate W-DMX on all Infinitys (see pages 26 for more information).

  • Page 15: Connect The Infinity To The Wireless Dmx Signal Transmitter

    When the wireless DMX communication is normal, the W-DMX indicator on the display is always green. The Infinity cannot receive a wireless DMX signal and a DMX cable signal at the same time. Connect the Infinity to the Wireless DMX Signal Transmitter The Infinity cannot actively match a random wireless signal transmitter.

  • Page 16: Multiple Infinitys (Artnet Control)

    01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a CAT-5/CAT-6 cable to connect the Infinity and other devices. 04) Connect your PC with installed ArtNet software to the first device’s RJ45 "in" socket.

  • Page 17: Connecting To A Network

    04) Set the IP address of your software/light controller to 2.x.x.x or 10.x.x.x, depending on the ArtNet settings. 05) Set the subnet mask to 255.0.0.0. on both – the Infinity and your software/light controller. Make sure that all the fixtures in the network have a unique IP address.

  • Page 18: How To Make A Data Cable

    Infinity S601 Profile How to Make a Data Cable A standard ETHERNET cable can be used to replace the data cable required to transmit the data for the S601. Please follow the instructions below in order to create an extra net cable.

  • Page 19: Fixture Linking

    Infinity S601 Profile Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.

  • Page 20: Control Panel

    When using multiple Infinitys, make sure you set the DMX addresses right. Therefore, the DMX address of the first Infinity should be 1(001); the DMX address of the second Infinity should be 1+57=58 (058); the DMX address of the third Infinity should be 58+57=115 (115), etc.

  • Page 21: Menu Overview

    Infinity S601 Profile Menu Overview Ordercode: 41507...
  • Page 22 Infinity S601 Profile Ordercode: 41507...
  • Page 23 Infinity S601 Profile Ordercode: 41507...
  • Page 24 Infinity S601 Profile Ordercode: 41507...

  • Page 25: Start-Up

    05) The display will now show the main menu. Please see the next page. No Reset Start-Up It is not required to turn the Infinity on, in order to adjust the device’s settings. It is possible to activate only the display. There are 2 possibilities: ●...

  • Page 26: Main Menu Options

    Infinity S601 Profile Main Menu Options DMX Addressing Control Mode Settings Menu Manual Control Stand-Alone Information Return one step back Home Down 1. DMX Addressing With this menu you can set the DMX address. 01) In main menu, select and enter the menu. The display will show: 02) Turn the control or type in the desired DMX address.

  • Page 27: Control Mode

    PERSONALITY: BASIC (37 channels), ADVANCE (57 channels), USER (up to 57 channels) ● USER PERSONALITY: In this mode it is possible to customize your Infinity by changing the order of the 57 DMX channels and/or leaving some channels out. Please, see below for more information.

  • Page 28: Settings Menu

    Infinity S601 Profile 3. Settings Menu With this menu you can set your desired mode. 01) In main menu, select and enter the menu. The display will show: 02) Use the control or the UP/DOWN buttons to toggle through the 23 submenus.
  • Page 29 WIRELESS UNLINK: Terminate the connection between the Infinity and the transmitter (YES/NO). ● DMX FAIL: The Infinity’s behavior in case of a DMX error. There are 2 options: OFF (output blackout) and HOLD (the Infinity will use the latest properly working DMX signal which ensures undisrupted performance).

  • Page 30: Network Settings

    Infinity S601 Profile 3.1. Network Settings With this menu you can set the network settings. 01) If you have selected NETWORK SETTINGS, the display will show: 02) Use the control or the UP/DOWN buttons to toggle through the 4 submenus.

  • Page 31: Lock Code

    Infinity S601 Profile 3.2. Lock Code With this menu you can set the safety code. 01) If you have selected LOCK CODE, the display will show: 02) Turn and press the control in order to insert the master code: 6468.

  • Page 32: Touch Calibration

    Infinity S601 Profile 3.3. Touch Calibration With this menu you can calibrate the touch screen. 01) If you have selected TOUCH CALIBRATION, the display will show: 02) Follow the instructions on the display until the touch screen calibration is complete.

  • Page 33: Reset Function

    Infinity S601 Profile ● GOBO2 ● GOBO2 ROTATE ● FOCUS-GOBO2 ● FOCUS-GOBO ● ZOOM ● PRISM1 ● PRISM2 ● PRISM2 ROT ● IRIS ● FROST ● CYAN ● MAGENTA ● YELLOW ● ● ANIMATION ● BLADE1-1 ● BLADE1-2 ● BLADE2-1 ●...

  • Page 34: Manual Control

    Infinity S601 Profile 03) Once you have selected the desired function, press the control to confirm your choice. 04) Turn the control in order to select YES or NO. 05) Press the control to confirm your choice. 06) If you have selected YES, the function in question will be reset.

  • Page 35: Stand-Alone

    Infinity S601 Profile 10) Use the control or the UP/DOWN buttons to toggle through the 57 functions. The functions correspond with the functions listed in the DMX section, 57 Channels. See page 27 for more information. 11) Once you have selected the desired function, press the control to confirm your choice.

  • Page 36: Fixture Information

    Infinity S601 Profile 6.1. Fixture Information With this menu you can view the currently installed software version, operation mode, DMX address and many other crucial parameters. 01) If you have selected FIXTURE INFORMATION, the display will show: 02) Use the control or the UP/DOWN buttons to toggle through 2 screens, in order to see all pieces of information.

  • Page 37: Dmx Channels

    Infinity S601 Profile DMX Channels Infinity Furion S601 Firmware Version V6.0 Basic Advanced Function Default Highlight Snap 0-255 0-540 Pan 16bit 0-255 16bit adjustable Tilt 0-255 0-270 Tilt 16bit 0-255 16bit adjustable Pan/tilt speed 0-255 Decreasing speed Dimmer 0-255 0-100%...
  • Page 38 Infinity S601 Profile Infinity Furion S601 Firmware Version V6.0 Basic Advanced Function Default Highlight Snap Rotating Open gobo wheel 1 9-17 Gobo 1 (Astroids) 18-26 Gobo 2 (Psycho) 27-35 Gobo 3 (Brushed) 36-44 Gobo 4 (Triangles) 45-53 Gobo 5 (Baroc)
  • Page 39 Infinity S601 Profile Infinity Furion S601 Firmware Version V6.0 Basic Advanced Function Default Highlight Snap Gobo rotating 2 0-255 16bit adjustable Index 16bit Prism No function 5-127 Prism 1 effect 128-255 Prism 2 effect Prism rotating 0-45 Prism index 46-126...
  • Page 40 Infinity S601 Profile Infinity Furion S601 Firmware Version V6.0 Basic Advanced Function Default Highlight Snap Animation No function Wheel 2-126 Positive rotating, decreasing speed 127-130 Stop Negative rotating, increasing 131-255 speed Digital motion FX No function 2-128 Step mode, increasing speed...
  • Page 41 Infinity S601 Profile Infinity Furion S601 Firmware Version V6.0 Basic Advanced Function Default Highlight Snap 84-89 Fans Full 90-95 Fans Silent 96-101 DMX Fail: Hold 102-107 DMX Fail: Off 108-113 Dimmer Linear 114-119 Dimmer Square 120-125 Dimmer I-Square 126-131 Dimmer - Scurve...

  • Page 42: Channels (Advanced)

    Infinity S601 Profile 57 channels (Advanced) Channel 1 – Horizontal movement (Pan) Push the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540° and stopped at any position you wish.
  • Page 43 Infinity S601 Profile Channel 14 – Yellow Dimmer intensity CH6 and CH8 must be open 0-255 Gradual adjustment Yellow from 0-100% Channel 15 – Yellow Dimmer intensity 16 bit CH6 and CH8 must be open Channel 16 – CTO Dimmer intensity...
  • Page 44 Infinity S601 Profile Channel 22 – Rotating Gobo wheel 2 CH6 and CH8 must be open Open 9-17 Gobo 1 (Circle) 18-26 Gobo 2 (Radial Lines) 27-35 Gobo 3 (Spokes) 36-44 Gobo 4 (Branches) 45-53 Gobo 5 (Stones) 54-73 Gobo 6 (Aperture)
  • Page 45 Infinity S601 Profile Channel 33 – Focus 0-255 Focus adjustment Channel 34 – Focus 16 bit Channel 35 – Auto focus Not functional 1-11 0-5 meters, auto focus gobo 1 12-22 6 meters, auto focus gobo 1 23-33 7 meters, auto focus gobo 1...
  • Page 46 Infinity S601 Profile Channel 41 – Angle Frame 1 0-255 Angle adjustment, 0-100% Channel 42 – Angle Frame 1, 16 bit Channel 43 – Position Frame 2 0-255 Position adjustment, 0-100% Channel 44 – Position Frame 2, 16 bit Channel 45 – Angle Frame 2...
  • Page 47 Infinity S601 Profile 90-95 Fans: Silent 96-101 DMX fail: Hold 102-107 DMX fail: OFF 108-113 Linear dimmer mode 114-119 Square dimmer mode 120-125 I-Square dimmer mode 126-131 S-curve dimmer mode 132-137 PWM 600Hz 138-143 PWM 1200Hz 144-149 PWM 2000Hz 150-155...

  • Page 48: Channels (Basic)

    Infinity S601 Profile 37 Channels (Basic) Channel 1 – Horizontal movement (Pan) Push the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540° and stopped at any position you wish.
  • Page 49 Infinity S601 Profile Channel 12 – CMY macros CH5 and CH6 must be open Not functional 10-127 CMY colors 128-255 CMY macro, from fast to slow Channel 13 – Rotating Gobo wheel 1 CH6 and CH8 must be open Open...
  • Page 50 Infinity S601 Profile Channel 16 – Gobo rotation (gobo wheel 2) 0-45 Gobo indexing 46-126 Clockwise gobo rotation, from fast to slow 127-130 Stop 131-211 Counterclockwise gobo rotation, from slow to fast 212-255 Gobo wheel bounce effect, from small to big amplitude Channel 17 –...
  • Page 51 Infinity S601 Profile Channel 24 – Frost 0-255 Frost effect, 0-100% Channel 25 – Animation wheel CH6 and CH8 must be open Not functional 2-126 Clockwise rotation, from fast to slow 127-130 Stop 131-255 Counterclockwise rotation, from slow to fast Channel 26 –...
  • Page 52 Infinity S601 Profile Channel 37 – Functions Not functional 6-11 Pan reverse 12-17 Pan normal 18-23 Tilt reverse 24-29 Tilt normal 30-35 Pan/Tilt swop 36-41 Pan/Tilt normal 42-47 P/T blackout ON 48-53 P/T blackout OFF 54-59 Color wheel blackout ON...

  • Page 53: Maintenance

    04) The electric power supply cables must not show any damages or material fatigue. The Infinity S601 Profile requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth.

  • Page 54: Replacing A Gobo From The Rotating Gobo Wheel

    Infinity S601 Profile Replacing a Gobo From the Rotating Gobo Wheel Fig. 10 01) Before removing the top part of the housing, make sure that the moving head is in the horizontal position. The lens position should be on the bottom, symmetrically speaking.

  • Page 55: Glass Gobo Orientation

    Infinity S601 Profile Glass Gobo Orientation Coated glass gobos are inserted with the coating against the rim of the holder (away from the spring). Textured gobos are inserted with the smooth side against the spring. This provides the best results when combining rotating gobos.

  • Page 56: Rotating Gobo Wheels, Color Wheel And Animation Wheel

    Infinity S601 Profile Rotating Gobo Wheels, Color Wheel and Animation Wheel Gobo wheel 1 Gobo wheel 2 Color wheel Animation Wheel Ordercode: 41507...

  • Page 57: Framing Shutter Position

    Infinity S601 Profile Framing Shutter Position Ordercode: 41507...

  • Page 58: Troubleshooting

    04) If all of the above appears to be O.K., plug the unit in again. 05) If you are unable to determine the cause of the problem, do not open the Infinity, as this may damage the unit and the warranty will become void.
  • Page 59 Infinity S601 Profile Problem Probable cause(s) Solution ● Check if power is switched on One or more No power to the fixture and cables are plugged in fixtures do not function at all Primary fuse blown ● Replace fuse Fixtures reset The controller is not connected ●...

  • Page 60: Product Specifications

    Infinity S601 Profile Product Specifications Model: Infinity S601 Profile Input voltage: 100-240V AC, 50/60Hz Power consumption: 750W (full output) DMX linking: 30pcs Fuse: F13AL/250V Dimensions: Dimensions: 284 x 420 x 748 mm (LxWxH) Weight: 35,6 kg Operating and Programming: Signal pin OUT:...

  • Page 61: Dimensions

    Infinity S601 Profile Dimensions Ordercode: 41507...

  • Page 62: Moving Head Position / Dmx Values

    Infinity S601 Profile Moving head Position / DMX Values Ordercode: 41507...

  • Page 63: Notes

    Infinity S601 Profile Notes Ordercode: 41507...
  • Page 64 ©2019 Infinity...
