Infinity Furion W402 WashBeam User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
ENGLISH
V1.0
Furion W402 WashBeam
Product code: 41440
c
c
c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Furion W402 WashBeam and is the answer not in the manual?

Questions and answers

Related Manuals for Infinity Furion W402 WashBeam

Summary of Contents for Infinity Furion W402 WashBeam

  • Page 1 USER MANUAL ENGLISH V1.0 Furion W402 WashBeam Product code: 41440...
  • Page 2 Furion W402 WashBeam Preface Thank you for purchasing this Infinity product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.

  • Page 3: Table Of Contents

    Furion W402 WashBeam Table of contents 1. Introduction ............................
  • Page 4 Furion W402 WashBeam 6.7.2.1.1. Enter Lock Code ..................... . .

  • Page 5: Introduction

    After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: Figure 1 • • Infinity Furion W402 WashBeam • • Schuko to Power Pro True cable (1,5 m) • •...

  • Page 6: Symbols And Signal Words

    Furion W402 WashBeam 1.5. Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in death or DANGER serious injury.

  • Page 7: Safety

    Furion W402 WashBeam Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. 2.1. Warnings and Safety Instructions...
  • Page 8 Furion W402 WashBeam WARNING Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. WARNING Possible eye damage caused by high light intensity Possibly hazardous optical radiation emitted from this device.

  • Page 9: Requirements For The User

    Furion W402 WashBeam • • If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it on immediately. Let the device reach room temperature before switching it on, otherwise it may be damaged by the formed condensation.

  • Page 10: Description Of The Device

    Description of the Device The Infinity Furion W402 WashBeam is an IP65-rated moving head with 7 x 45 W RGBW LEDs. This device has a motorized zoom that enables seamless transitions between a narrow 3,1° beam and a wide 36,6° wash.

  • Page 11: Back View

    Furion W402 WashBeam 3.2. Back View Figure 3 Protective vent (M12x1,5) IP65-rated RJ45 connector IP65-rated RJ45 connector IP65-rated Seetronic power connector OUT IP65-rated Seetronic power connector IN Fuse (F8 AL, 250 V) IP65-rated 5-pin DMX signal connector IN IP65-rated 5-pin DMX signal connector OUT...

  • Page 12: Product Specifications

    Furion W402 WashBeam 3.4. Product Specifications Model: Furion W402 WashBeam Source: Light source type LED  Light source quantity 7  Light source power 45 W LED color type RGBW  Refresh rate 600 Hz Refresh rate (max.) 15 kHz Luminous flux (total) 3951 lm Luminous flux (red) 1112 lm...
  • Page 13 Furion W402 WashBeam Electrical Specifications and Connections: Power supply 100–240 V AC 50/60 Hz  Power consumption 375 W Fuse F8 AL, 250 V Power connector IN Power Pro True  Power connector OUT Power Pro True  DMX connector XLR 5P IN/OUT  DMX connector IN XLR 5P ...

  • Page 14: Dimensions

    Figure 5 3.6. Optional Accessories You can additionally purchase the following accessory: • • D7277 Case for 4x Furion W402 WashBeam • • 41549 Infinity IP Tester for Furion Contact your Highlite International dealer for more information. Product code: 41440...

  • Page 15: Installation

    Furion W402 WashBeam Installation 4.1. Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing.
  • Page 16 Furion W402 WashBeam Figure 7 Figure 8 04) Attach the device to the supporting structure. Make sure that the device cannot move freely. 05) Secure the device with a secondary suspension, for example a safety cable. Make sure that the secondary suspension can hold 10 times the weight of the device.

  • Page 17: Lock/Unlock The Device

    Furion W402 WashBeam 4.5. Lock/Unlock the Device The device has a locking mechanism on the yoke and on the base. • • To unlock the device, slide the base locking mechanism (15) to the the right or slide the yoke locking mechanism (02) downwards.

  • Page 18: Connecting To Power Supply

    Do not link more devices on one power link than the maximum recommended number. Maximum recommended number of devices: • • at 100–120 V: 4 devices Furion W402 WashBeam • • at 200–240 V: 8 devices Furion W402 WashBeam Product code: 41440...

  • Page 19: Setup

    5.2. Stand-alone Setup When the Furion W402 WashBeam is not connected to a controller or to other devices, it functions as a stand- alone device. It can be operated manually via the control panel or in auto mode. For more information refer to Control Modes (see 6.2.

  • Page 20: Dmx Linking

    Furion W402 WashBeam Figure 10 5.3.3. DMX Linking To connect multiple devices on one DMX data link, follow the steps below: 01) Use a 5-pin DMX cable to connect the DMX OUT connector of the lighting controller to the DMX IN connector of the 1 device.

  • Page 21: Dmx Addressing

    04) Continue assigning the starting addresses of the remaining devices by adding each time 22 to the previous number. Make sure that you do not have any overlapping channels in order to control each Furion W402 WashBeam correctly. If two or more devices are addressed similarly, they will work similarly.

  • Page 22: Ethernet Connection

    Furion W402 WashBeam 5.5. Ethernet Connection 5.5.1. Art-Net/sACN Protocol Art-Net is a protocol that uses TCP/IP to transfer a large amount of DMX-512 data over an Ethernet network. Art- Net 4 can support up to 32768 universes. Art-Net™ is designed by and copyright of Artistic Licence Holdings Ltd.

  • Page 23: Art-Net/Sacn Linking

    Furion W402 WashBeam 5.5.3. Art-Net/sACN Linking To connect multiple devices on one Art-Net/sACN data link, follow the steps below: 01) Use a CAT-5/CAT-6 cable to connect the RJ45 connector of the computer/lighting controller to one of the RJ45 connectors of the 1 device.

  • Page 24: Operation

    Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device. 6.2. Control Modes The Furion W402 WashBeam supports the following control modes: • • Stand-alone: Stand-alone mode (built-in programs), manual control •...

  • Page 25: Control Panel

    After the device is connected to power supply, the device will perform a reset. During the reset the display shows a splash screen with the Infinity logo and the name of the device: During the reset procedure it is possible to enter the menu to change the DMX address.

  • Page 26: Display Lock

    Furion W402 WashBeam I. DMX starting address of the device. • • If the DMX connection is lost or the device is not connected, the DMX starting address is red. • • If the device is receiving DMX signal, the DMX starting address is white.

  • Page 27: Unlocking Without Password

    Furion W402 WashBeam 6.5.2. Unlocking without Password 6.5.2.1. Option 1 Press the ENTER button to unlock the device. The display shows: 6.5.2.2. Option 2 01) Press the MENU button. 02) Press the ENTER button to unlock the device. The display shows: 6.5.3.

  • Page 28: Menu Overview

    Furion W402 WashBeam 6.6. Menu Overview Level 1 Level 2 Level 3 Level 4 Address (see 6.7.1. DMX Address Address Setting 001–512 page 31) Screen Reverse AUTO Pan Reverse Tilt Reverse Zoom Reverse Pan Angle Tilt Angle BL.O.P/T Move Auto Pan Invert...
  • Page 29 Furion W402 WashBeam Level 1 Level 2 Level 3 Level 4 Studio RGBW C Mixing Mode Linear Square Dimmer Curve I Squa SCurve Smooth Dimmer Speed Fast 600 Hz 1200 Hz 2000 Hz PWM Option 4000 Hz 6000 Hz 15000Hz 100–255...
  • Page 30 Furion W402 WashBeam Level 1 Level 2 Level 3 Level 4 Factory Settings Stand Alone (see 6.7.3. Stand Alone Program Number 1–9 page 39) WDMX Control Mode ArtNet sACN Basic Personality Advance User NO/1~Advance Num Pan Fine NO/1~Advance Num Tilt...
  • Page 31 Furion W402 WashBeam Level 1 Level 2 Level 3 Level 4 Dimmer 000–255 Shutter 000–255 Zoom 000–255 Control 000–255 V2. XXXXXX Running Mode DMX Address Temperature Fixture Hours 00000 Fixture Info User Hours 00000 IP Address 002.080.008.070 SubMask 255.000.000.000 29B40E4XXXXX 34.29.8F.08.05.04...

  • Page 32: Main Menu Options

    Furion W402 WashBeam 6.7. Main Menu Options The main menu has the following 6 options: DMX Address Settings Menu Stand Alone Control Mode Manual Control Information 01) Press the UP/DOWN buttons to navigate through the main menu. 02) Press the ENTER button to open the submenus.

  • Page 33: Settings Menu

    Furion W402 WashBeam 6.7.2. Settings Menu In this menu you can adjust the settings of the device. 01) Press the UP/DOWN buttons to scroll through the 26 available options: • • Screen Reverse: Rotate the text on the display 180° when the device is mounted upside down (NO/YES/AUTO).

  • Page 34: Lock Code

    Furion W402 WashBeam • • Auto Pan Invert: Invert the pan direction automatically, depending on the position of the device (ON/OFF) • • Lock Code (see 6.7.2.1. Lock Code) • • WDMX: Activate/deactivate Wireless DMX (ON/OFF) • • Wireless Unlink: Terminate the connection between the device and the transmitter (NO/YES) •...

  • Page 35: Enter Lock Code

    Furion W402 WashBeam 6.7.2.1.1. Enter Lock Code In this menu you can set Enter Lock Code for the device. 01) Press the UP/DOWN buttons to increase/decrease the values in order to create your personal code. Set the lock code 0000–9999.

  • Page 36: Dimmer Curve

    Furion W402 WashBeam 6.7.2.4. Dimmer Curve In this submenu you can select the dimming curve. 01) Press the UP/DOWN buttons to select one of the 4 options: • • Linear • • Square • • Inverse Square • • S-Curve 02) Press the ENTER button to confirm.

  • Page 37: Color Balance

    Furion W402 WashBeam 6.7.2.6. Color Balance In this submenu you can adjust color brightness of the LEDs. 01) Press the UP/DOWN buttons to select one of the 4 options: • • • • Green • • Blue • • White 02) Press the ENTER button to confirm the selection 03) Press the UP/DOWN buttons to change the value.

  • Page 38: Service Menu

    Furion W402 WashBeam 6.7.2.9. Service Menu In this submenu you can make fine adjustments of the home position of all moving parts, change the MAC address and the RDM identification number of the device or change RGBW. There are 2 passwords to enter the service menu: •...

  • Page 39: Password 2322

    Furion W402 WashBeam 6.7.2.9.2. Password 2322 01) Press the UP/DOWN buttons to insert the master code: 2322. 02) Select ENTER to confirm. 03) Press the UP/DOWN buttons to scroll through the 4 available options: • • • • Green •...

  • Page 40: Stand Alone

    Furion W402 WashBeam 6.7.3. Stand Alone In this menu you can set the built-in program. Press the UP/DOWN buttons to start one of the 9 built-in programs. The display shows: 6.7.4. Control Mode In this menu you can set the control mode, personality and user personality.

  • Page 41: Manual Control

    Furion W402 WashBeam 6.7.5. Manual Control In this menu you can set Auto Test or Manual Test. 01) Press the UP/DOWN buttons to scroll through the 2 available options: • • Auto Test (see 6.7.5.1. Auto Test) • • Manual Test (see 6.7.5.2.

  • Page 42: Manual Test

    Furion W402 WashBeam 6.7.5.2. Manual Test In this submenu you can test each function of the device individually or as a group. It is possible to customize the device by changing the value of each function manually. These functions are the same as the 22 DMX channels in Advance personality.

  • Page 43: Fixture Info

    Furion W402 WashBeam 6.7.6.1. Fixture Info In this submenu you can view the currently installed firmware version, operation mode, DMX address and other parameters of the device. Press the UP/DOWN buttons to see all available parameters. • • Ver: Shows the current software version •...

  • Page 44: Error Info

    Furion W402 WashBeam 6.7.6.3. Error Info In this submenu you can view whether there are any system errors. If you have selected Error Info and there are no errors the display shows: Note: In case of an error message, discontinue the use of the device and contact your Highlite International dealer for more information.

  • Page 45: Dmx Channels

    Furion W402 WashBeam 6.8. DMX Channels 6.8.1. DMX Channels Overview Basic Advance Function Setting Default Highlight 14 CH 22 CH Value 000–255 0°–540° 000–255 Pan Fine 16-bit Fine positioning 000–255 Tilt 0°–260° 000–255 Tilt Fine 16-bit Fine positioning 000–255 Pan/Tilt Speed From fast to slow 000–255...

  • Page 46: Basic (14 Channels), Advance (22 Channels)

    Furion W402 WashBeam 6.8.2. Basic (14 Channels), Advance (22 Channels) Basic Advance Function Value Setting Control Type 14 CH 22 CH 000–255 Pan adjustment 0°–540° 000–255 Pan adjustment, 16-bit Pan Fine 000–255 Tilt adjustment 0°–260° Tilt 000–255 Tilt adjustment, 16-bit Tilt Fine 000–255 From fast to slow...
  • Page 47 Furion W402 WashBeam Basic Advance Function Value Setting Control Type 14 CH 22 CH No function 001–255 Color temp from output mode to 2700 K proportional 000–255 Fine adjustment CTC 16-bit 000–255 Wide to narrow Zoom 000–255 Fine adjustment Zoom 16-bit 000–004 No function...
  • Page 48 Furion W402 WashBeam Basic Advance Function Value Setting Control Type 14 CH 22 CH 220–224 Reset Zoom/Focus step 225–234 Reserved 235–239 Reset All step 240–244 Full mode step 245–249 White mode (7500 K) step 250–255 Reserved Product code: 41440...

  • Page 49: Rdm Information

    Furion W402 WashBeam 6.9. RDM Information This device supports RDM (see 6.9.2. Supported RDM PIDs (Parameter IDs)). 6.9.1. RDM Details • • Responder ID: 29B4:0E4XXXXX • • Manufacturer's ID: Infinity (Highlite International B.V.) • • Manufacturer Label: Infinity • •...

  • Page 50: Troubleshooting

    Furion W402 WashBeam Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage.

  • Page 51: Error Messages

    Furion W402 WashBeam 7.1. Error Messages In case one of the error messages below appears on the error information screen, discontinue the use of the device and contact your local dealer. For more information, refer to Error Info (see 6.7.6.3. Error Info on page 43).

  • Page 52: Maintenance

    Furion W402 WashBeam Maintenance 8.1. Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. 8.2. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: •...

  • Page 53: Replacing The Fuse

    06) Replace the fuse holder in the opening and tighten the fuse cover. 8.3.2. Draining Condensation Water The Furion W402 WashBeam is IP65 rated. The device can resist water jets. If the device is exposed to extreme humid conditions during use, condensation may collect inside the device. This can happen also during transportation, if the device is exposed to extreme temperature variations.

  • Page 54: Deinstallation, Transportation And Storage

    Approval Hereby, Highlite International declares that the device Furion W402 WashBeam, product code 41440, is in compliance with Directive 2014/53/EU (RED – Radio Equipment Directive). The full text of the EU declaration of conformity is available on the respective product page on the website of Highlite International (www.highlite.com).
  • Page 55 Furion W402 WashBeam Product code: 41440...
  • Page 56 Infinity is a brand of Highlite International B.V.
