Sacred Sun FAJ Series Technical Manual

Valve-regulated sealed lead acid battery

Advertisement

FAJ Series
Valve-regulated Sealed Lead Acid Battery
Technical Manual
山东圣阳电源股份有限公司
SHANDONG SACRED SUN POWER SOURCES CO.,LTD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAJ Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sacred Sun FAJ Series

  • Page 1 FAJ Series Valve-regulated Sealed Lead Acid Battery Technical Manual 山东圣阳电源股份有限公司 SHANDONG SACRED SUN POWER SOURCES CO.,LTD...
  • Page 2: Table Of Contents

    Contents Chapter I: Product Introduction Product Characteristics ....................01 Main Applications ......................02 Battery Construction ....................02 General Specifications ....................03 Working Principle ......................04 Chapter II: Electrical Characteristics Discharge Curve ......................05 Charge Curve ......................06 Chapter III: Operation and maintenance Safety Instructions..................07 Operating Conditions and parameters .................08 Factors Influencing Capacity .................1 0 Temperature Effect on Battery Capacity ........
  • Page 3: Chapter I: Product Introduction

    Chapter I: Product Introduction Product Characteristics Advantages Design life: 12 years (25℃) EUROBAT Classification: Long life High discharge performance High gas recombination efficiency Maximum charge efficiency Low self-discharge rate Easy installation and handling Centralized venting system Design Features Positive plates Thick flat pasted plate with lead-calcium-tin grid alloy;...
  • Page 4: Main Applications

    Main Applications Telecommunications Emergency power Power system Data center Standards IEC60896-21/22: 2004 BS 6290-4:1997 YD/T2343-2011 Eurobat guide Installation compliant with EN50272-2 Battery Construction...
  • Page 5: General Specifications

    General Specifications FAJ series Table 1-1 FAJ series battery general specifications Nominal Short Capacity Dimensions (mm) Nominal Internal Battery Weight Circuit Terminal Terminal Voltage (Ah,25℃) Resistance Model (kg) Current Type Layout (mΩ,25℃) Length Width Height 1.80V/cell FAJ12-80B 26.0 2300 FT-52 FAJ12-95B 28.5...
  • Page 6: Working Principle

    Working Principle The electrochemical reaction of batteries in charge and discharge process is as follows: Discharge + Pb PbSO + 2H O + PbSO Charge In the final stage of charge process, active substance in positive plate is fully transformed to lead dioxide, but negative plate has not reached fully charged stage, the process of active substance in negative plate transforming to spongy lead is not finished, oxygen gas generated in positive plate reaches the negative plate through separator pores and then reacts with active substance in...
  • Page 7: Chapter Ii: Electrical Characteristics

    The battery capacity is directly related to the discharge current, end voltage and discharge temperature. In general, the smaller discharge current, the lower end voltage, the higher temperature will cause larger discharge capacity. Figure 2-1 describes the discharge curves of FAJ Series at different discharge rate at ambient temperature 25℃.
  • Page 8: Charge Curve

    Charge Curve Figure 2-2 Charge curve under different depth of discharge (25℃)
  • Page 9: Chapter Iii: Operation And Maintenance

    Chapter III: Operation and Maintenance Safety Instructions Please read these instructions carefully in order to ensure correct, safe and effective operation. This manual provides you very important guidance for installation and operation, which will guarantee your equipment with optimal performance and longer service life. For your safety, please do not open the batteries;...
  • Page 10: Operating Conditions And Parameters

    Operation Conditions and Paramters Temperature range is -15℃~50℃, the optimal operation temperature is 20℃~30℃, max. ambient humidity is ≤95%, height above sea level less than 3000 Meter Charge current-limiting valve: charge current-limiting valve range is 0.1C -0.2C According to the grid condition of the BTS, we divided the grid conditions into five types, see the table 3-1 below: Table 3-1 Grid conditions definition Type I: Total power failure time per month <10 hours...
  • Page 11 Table 3-2 Recommended settings for rectifier parameters (48V system, 25℃) III Grid IV Grid Parameter type I Grid type II Grid type type type Floating charge voltage (V) 54.48 54.48 54.48 54.48 Equalizing charge voltage (V) 57.6 57.6 57.6 57.6 Charge current limitation (A/group) 0.10C 0.10C...
  • Page 12: Factors Influencing Capacity

    Battery capacity consists both of nominal capacity and actual capacity, for nominal capacities of the FAJ series battery please refer to Table 1-1. Actual capacity is the real quantity of electricity battery discharge under certain condition, it equals to discharge current multiplied by discharge time, the unit is Ah.
  • Page 13: Recharge

    Floating charge FAJ series batteries can be used in floating and cycle application. Floating operation is the best operation condition for the battery. In floating operation, if the battery is kept at fully charged state, the battery can reach the longest service life. At the ambient temperature of 25℃, recommended floating charge voltage setting value is 2.25V/ cell.
  • Page 14: Temperature Effect On Battery Design Life

    Table 3-4 Required charge time in different depth of discharge Charge current at Charge voltage at Depth of Constant current Constant voltage constant current constant voltage discharge(%) charge time (h) charge time(h) charge period (A) charge period (V/cell) 0.1C 2.35 0.15C 2.35 0.1C...
  • Page 15: Charge Requirement

    Charge Requirement Equalizing Charge Equalizing charge is needed in the following cases: When there are more than two batteries in a battery string with voltage of lower than 2.18V / cell. The battery has been in floating operation more than 3 months. Recommended charge method as follows: Charge the battery with constant current of no more than 0.15C (A), until the battery voltage...
  • Page 16 Storage Maximum storage times / Recommended refreshing charge method temperature Refreshing charge intervals -10~30℃ Every 6 months Using constant current 0.1C A~0.15C A to charge battery bank till battery average voltage rises to 31~45℃ Every 3 months equalizing charge voltage, then switch to constant voltage charging.
  • Page 17: Maintenance

    Maintenance 1. Cleaning Notes: Battery appearance, terminal area and working environment must be kept clean and dry. In battery cleaning process, avoid use of electrostatic cleaning tools. Clean the battery with damp cloth. Do not use of gasoline, alcohol or other organic solvents; also do not use cloth containing these substances.
  • Page 18 Item Content Standard Maintenance torque Securely connected If found bolt loosened, tighten it wrench to tighten loose bolts. 1-Battery cables, No evidence of If slight corrosion found after connecting terminals clean / corrosion bar removed, clean it with cloth. If severe 4- Joints non-corrosive.
  • Page 19 2.3 Annual Maintenance Inspection Items In addition to the quarterly maintenance items above, inspect the following items: Item Content Standard Maintenance Disconnect the AC, take At the end of If the battery voltage is lower load discharge discharge, battery than a voltage reference value or the discharge online method voltage should be differential pressure is greater than the...
  • Page 20 No.1,Shengyang Road, Qufu City, Shandong Province,273100,P.R.China Tel:0086-537-4422313 Fax:0086-537-4411980 E-mail:sales@sacredsun.cn...
