  • Page 1 DCS Series Deep Cycle Solar Battery Technical Manual SHANDONG SACRED SUN POWER SOURCES CO.,LTD...
  • Page 2: Table Of Contents

    Contents Chapter I: Product Introduction 1. Product Characteristics ....................01 2. Main Applications ......................02 3. General Specification ....................02 4. VRLA Technology ......................03 Chapter II: Electrical Characteristics 1. Discharge Characteristic Curve ...................04 Charging Characteristic Curve ..................05 Cycle Performance Curve ..................05 4. Performance Data ......................06 Chapter III: Operation and Maintenance 1.
  • Page 3: Chapter I: Product Introduction

    Chapter I: Product Introduction Product Characteristics Advantages  Design life: 15 years at 25℃  EUROBAT Classification: Very long life  More than 3000 cycles at 70% DOD  Special negative active material formula, improve the charge acceptance ability, reduce the negative plate sulphation, more suitable for the partial state of charge (PSOC) application ...
  • Page 4: Main Applications

    Main Applications  Household energy storage system  Solar and wind energy system  Emergency system  Other cycling systems Standards  IEC60896-21/22:2004  BS6290-4  Eurobat guide  Installation compliant with EN50272-2 General Specifications Table 1-1 General specification Nominal Dimensions (mm) Capacity Nominal...
  • Page 5: Vrla Technology

    VRLA Technology The electrochemical reaction of batteries in charge and discharge process is as follows: Discharge + Pb PbSO + 2H O + PbSO Charge In the final stage of charge process, active substance in positive plate fully transformed to lead dioxide, negative plate has not reached fully charged stage, the process of active substance in negative plate transformed to spongy lead is not finished, oxygen gas generated in positive plate reaches the negative plate through separator pores and then reacts with active substance in...
  • Page 6: Chapter Ii: Electrical Characteristics

    In general, the smaller discharge current, the lower end voltage, the higher temperature will cause larger discharge capacity. Figure 2-1 describes the discharge curves of DCS Series at different discharge rate at ambient temperature 25℃. Table 2-1 describes the end voltage at different discharge rate.
  • Page 7: Charging Characteristic Curve

    Charging Characteristic Curve Figure 2-2 describes the battery charge characteristic curves with constant voltage of 2.35V / cell and limited current of 0.1C A. When charging the battery for 24 hours after fully discharged, the charge capacity can be as high as the 104% of the discharged capacity. Figure 2-2 Charge characteristic curve Cycle Performance Curve At different depth of discharge, the battery cycle life is different, in general, the more shallow depth...
  • Page 8: Performance Data

    Performance Data Constant current discharge data Table 2-2 DCS Series Battery Constant Current Discharge Data Sheet (Amperes, 25 ℃) Constant Current Discharge Data Sheet (25℃)-------Amperes(A) Discharge Time End Voltage Battery Type (V/cell) 10 h 20 h 50 h 100 h...
  • Page 9: Chapter Iii: Operation And Maintenance

    Chapter III: Operation and Maintenance Safety Instructions Please read these instructions carefully in order to ensure correct, safe and effective operation. This manual provides you very important guidance for installation and operation, which will guarantee your equipment with optimal performance and longer service life. For your safety, please do not open the batteries;...
  • Page 10: Operation Parameters

    Operation Parameters Floating/equalizing charge voltage  Floating (25℃): 2.25V/cell  Equalizing (25℃): 2.40V/cell  Temperature compensation coefficient: -3.5mv/cell/℃ Charge current-limiting valve: charge current-limiting valve range is 0.1C -0.4C According to the grid condition of the BTS, we divided the grid conditions into five types, see the table 3-1 below: Table 3-1 Grid conditions definition Type I: Total power failure time per month <10 hours...
  • Page 11: Temperature Effect On Battery Capacity

    25℃ to 35℃, capacity will be approximately 105% of the nominal capacity. From 35℃ to 45℃, the capacity increase is very low and if temperature rises beyond 45℃, there is no increase in battery capacity. Figure 3-1 DCS series temperature effect on battery capacity curve...
  • Page 12: Temperature And Floating/Equalizing Charge Voltage

    Temperature Effect on Battery Design Life Temperature range of the DCS series is -20℃~+75℃. The battery can be used in 15℃~40 ℃ environment for a long time. Corrective measures should be taken in case the temperature deviates from the optimum temperature range.
  • Page 13: Storage

    Storage Storage Interval:  Battery should be stored in fully charged state. It is strictly prohibited to storage after discharge.  Battery storage location must be away from heat, sparks and smoke.  Battery must be stored in an upright position, avoiding impacts of external force or abrupt loads. Safety valve should be tightened.
  • Page 14: Maintenance

    Maintenance 1. Cleaning Notes:  Battery appearance, terminal area and working environment must be kept clean and dry.  In battery cleaning process, avoid use of electrostatic cleaning tools.  Clean the battery with damp cloth. Do not use of gasoline, alcohol or other organic solvents; also do not use cloth containing these substances.
  • Page 15 Item Content Standard Maintenance Use hex or torque Securely connected If found bolt loosened, tighten it wrench to tighten loose bolts. 1-Battery cables, No evidence of If slight corrosion found after connecting terminals clean / corrosion bar removed, clean it with cloth. If severe 4- Joints non-corrosive.
  • Page 16 2.3 Annual Maintenance Inspection Items In addition to the quarterly maintenance items above, inspect the following items: Item Content Standard Maintenance Disconnect the AC, take At the end of If the battery voltage is lower load discharge discharge, battery than a voltage reference value or the discharge online method voltage should be differential pressure is greater than the...
  • Page 17 No.1,Shengyang Road, Qufu City, Shandong Province,273100,P.R.China Tel:0086-537-4422313 Fax:0086-537-4411980 E-mail:sales@sacredsun.cn...
