MULTICLEAN
PREMIUM
A80400600.
1
EU
A80400700.
2
UK
A80400800.
EN
ES
DE
FR
IT
PT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTICLEAN PREMIUM A80400600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roca MULTICLEAN PREMIUM A80400600

Summary of Contents for Roca MULTICLEAN PREMIUM A80400600

  • Page 1 MULTICLEAN PREMIUM A80400600. A80400700. A80400800.

  • Page 2: Important Safeguards

    Important safeguards When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: Please read this manual carefully before product installation and use. DANGER- For reducing the possibility of electric shock 1. Do not place or store the remote control at where it can fall or be pulled into the bathtub, sink or tank. 2.
  • Page 3 For your safety, be sure to obey the followings: Please read this manual before use and keep this manual at where you can refer easily. Neglect or misuse followings might lead to the injury or serious damage. WARNING : “It might cause serious damage or death.” Please install plug properly.

  • Page 4: Parts List

    Parts list User’s Manual T-valve with Bidet Hose Mounting Plate with Guarantee card Remote unit Hardware kits (60cm) Installation guide Battery x4 Specification Power Source 220-240V~, 50/60Hz Maximum Power Consumption 1300W Tap water pressure (connect cold to water) 0.1~0.7 PMa (1~7bar) Rear spray volume 0.2~0.8 l/min Front spray volume...

  • Page 5: Remote Control

    Configuration Power outlet * Power plug Body housing Nozzle Heated seat Multiclean water hose T-valve Toilet bowl * *Water shut off valve *Items not supplied with the product. Remote control...

  • Page 6: Clean Function

    Clean function Please occupy the toilet seat in order to activated the sensor installed onto the seat. Rear cleaning 1. Cleaning Press rear cleaning button to activate. 2. Stop cleaning Press stop button. Front cleaning 1. Cleaning Press front cleaning button to activate. 2.

  • Page 7: Water Pressure

    Water pressure Water volume adjustment Press to increase or to decrease set water volume while cleaning function activated. There 5 level adjustment Cleaning massage Oscillating cleaning With activating the oscillating cleaning function, the nozzle will be moved back and forth for widening the cleaning range. With clean function activated, press to activate or deactivate oscillating cleaning mode.

  • Page 8: Seat Heating

    Seat heating 1. Seat temperature Press seat heater button to activate. 2. Temperature adjustment Press seat heater button again to adjust temperature until desired setting. There are 4 temperature levels. Temperature:OFF 35˚C 37˚C 39˚C Note:It will take a few minutes to heat the seat. The setting of desired temperature will be saved and locked in memory. User setting User setting function allow to store 6 user profiles on memory for quickly access.

  • Page 9: Power Saving Mode

    Power saving mode Main power functions will turn off automatically when you set power saving ON for saving the power. The main power will resume once the toilet seat is occupied again by user. Press power saving button to activated and deactivate. Setting time MULTICLEAN stores data about using time and automatically set power saving.

  • Page 10: Cleaning Function

    Auxiliary control panel operation In case that power of remote control batteries is insufficient, user can use auxiliary panel to operate main functions. Cleaning function 1. Select cleaning Press cleaning button to activate rear cleaning. Repeatedly press the same button for adjusting water pressure. (It is exclusively used for rear cleaning function.

  • Page 11: Remote Control Battery

    Remote control battery If during normal use, display indication it's blinking, indicates low battery level. Please use 4×AA alkaline battery. Do not mix the new and used batteries or different brands. Cleaning & maintenance Nozzle cleaning Press oscillating button for 3 sec to activate that nozzle would automatically oscillated back and front during 1 minute. To stop this function in advance, please press stop button.
  • Page 12 Cleaning and removal Use a soft and damp cloth or sponge to wipe off the body gently. 1. Do not scrub or use harsh or abrasive chemical cleansers to clean the product. Only use neutral product for cleaning. 2. For a thorough cleaning, you may need to detach the product. 3.

  • Page 13: Filter Cleaning

    Filter cleaning Turn tap water shutoff valve off Flush the toilet to empty the water tank Unscrew the filter from the T-Valve. completely. Note: Failure to do so could result in leaking or flooding. Gently brush and clean the filter with Reconnect the filter to the T-Valve Turn the tap water shutoff valve back water to remove the clog.

  • Page 14: Troubleshooting

    Troubleshooting Issue Possible 1. Connect the product 1. Disconnected/ no power supply 2. Check there’s a 220-240V~ signal with another No working 2. No electrical power supply product (such us hairdryer) 3. Product is power off. 3. Push the power button (on/off auxiliary control). 1.

  • Page 15: Medidas De Seguridad Importantes

    Medidas de seguridad importantes Cuando utilice aparatos eléctricos, especialmente si hay niños cerca, debe tomar siempre unas precauciones básicas de seguridad, incluidas las siguientes: Por favor, lea atentamente este manual antes de instalar y utilizar el producto. PELIGRO- Para reducir el riesgo de descarga eléctrica 1.
