- Page 1 MULTICLEAN A804006009 A804007009 A804008009...
-
Page 2: Important Safeguards
Important safeguards When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: Please read this manual carefully before product installation and use. DANGER- Risk of electric shock 1. Do not place or store the remote control where it can fall or be pulled into the bathtub, sink or tank. 2. - Page 3 NOTE: This symbol and recycling system is only applicable in the European Union. It does NOT apply to the rest of the world. At ROCA we are committed to protecting the environment. Please help us by discarding this product at the end of it life-cycle in a responsible manner, to prevent that certain substances contained in electrical or electronic equipment may cause harm to human health and the environment.
- Page 4 For your safety, be sure to obey the following instruction Please read this manual before use and keep this manual at where you can refer each to it easily. Please strictly follow the following cautions to prepare any malfunction an injury. Please fix plug properly.
-
Page 5: Parts List
Parts list User’s Manual T-valve with Bidet Hose Mounting Plate with Guarantee card Remote unit Hardware kits (60cm) Installation guide Battery x4 Specification Power Source 220-240V~, 50/60Hz Maximum Power Consumption 1300W IP Rating IPX4 Tap water pressure (connect to cold water) 0.1~0.7 MPa (100-700KPa) Rear spray volume 0.2~0.8 l/min... -
Page 6: Remote Control
Configuration Power outlet * Body housing Power plug Nozzle Multiclean water hose Heated seat T-valve Toilet bowl * *Water shut off valve *Items not supplied with the product. Remote control... -
Page 7: Cleaning Function
Cleaning function Please occupy the toilet seat in order to activate the sensor installed onto the seat. Rear cleaning 1. Cleaning Press rear cleaning button to activate. 2. Stop cleaning Press stop button. Front cleaning 1. Cleaning Press front cleaning button to activate. 2. -
Page 8: Water Pressure
Water pressure Water volume adjustment Press to increase or to decrease water volume while cleaning function is activated. There are 5 adjustment levels. Cleaning massage Oscillating cleaning When activating the oscillating cleaning function, the nozzle will be moved back and forth for widening the cleaning range. With cleaning function activated, press to activate or deactivate oscillating cleaning mode. -
Page 9: Seat Heating
Seat heating 1. Seat temperature Press seat heater button to activate. 2. Temperature adjustment Press seat heater button again to adjust temperature until desired setting. There are 4 temperature levels. Temperature:OFF 35˚C 37˚C 39˚C Note:It will take a few minutes to heat the seat. The setting of desired temperature will be saved and locked in memory. User setting The user setting function allows the storage of six user profiles in the quick access memory. -
Page 10: Power Saving Mode
Power saving mode Main power functions will turn off automatically when you set power saving ON for saving the power. The main power will resume once the toilet seat is occupied again by user. Press power saving button to activate and deactivate. Setting time Based on the daily use of the product, MULTICLEAN will automatically go into power saving mode. -
Page 11: Light Indication
Auxiliary control panel operation Should the remote control run out of batteries, user can use auxiliary panel to operate main functions. Cleaning function 1. Select cleaning Press cleaning button to activate rear cleaning. Repeatedly press the same button for adjusting water pressure. (It is exclusively used for rear cleaning function. - Page 12 Removal of batteries from the remote control If during use, the display indication blinks, this indicates low battery level. Please replace the batteries (4x alkaline AA). Do not mix used and new batteries or from different brands. Cleaning & maintenance Nozzle cleaning Press oscillating button for 3 sec to activate the nozzle.
- Page 13 Cleaning and removal Use a soft and damp cloth or sponge to wipe off the body gently. 1. Do not scrub or use harsh or abrasive chemical cleansers to clean the product. Use only neutral products for cleaning. 2. For a thorough cleaning, you may need to detach the product. 3.
-
Page 14: Filter Cleaning
Filter cleaning Turn tap water shutoff valve off Flush the toilet to empty the water tank Unscrew the filter from the T-Valve. completely. Note: Failure to do so could result in leaking or flooding. Gently brush and clean the filter with Reconnect the filter to the T-Valve Turn the tap water shutoff valve back water to remove the clog. -
Page 15: Troubleshooting
Troubleshooting Issue Possible cause Solution 1. Connect the product. 1. Disconnected/ no power supply 2. Check there’s a 220-240V~ signal with another Fails to operate 2. No electrical power supply product (such us hairdryer). 3. Product is switched off. 3. Push the power button (on/off auxiliary control). 1.
