- Page 1 MULTICLEAN A804001... A804002... A804004...
-
Page 2: Important Safeguards
Important safeguards When using electrical products, especially when children are present, basic safety precautions should always be followed, inclu- ding the following: Please read this manual carefully before product installation and use. DANGER- For reducing the possibility of electric shock 1. - Page 3 For your safety, be sure to obey the followings: Please read this manual before use and keep this manual at where you can refer easily. Neglect or misuse followings might lead to the injury or serious damage. WARNING : “It might cause serious damage or death.” Please install plug properly.
-
Page 4: Parts List
Parts list Mounting plate with User’s manual Installation guide Guarantee card T-valve with bidet hose hardware kits Specification Power source 220-240V~, 50/60Hz Maximum power consumption 1300W Tap water pressure (connect to cold water) 0.1~0.7 MPa (1~7bar) Rear spray volume 0.2~0.8 L/min Front spray volume 0.2~0.8 L/min Maximum heater capacity... -
Page 5: Parts Description
Parts description Power outlet * Power plug Body housing Seat Side control Nozzle T-Valve Water Shut off Valve* *Toilet bowl Bidet Hose * Items not supplied with the product. Side control Front cleaning Dryer Rear cleaning Oscillating cleaning Stop function Water/dryer temperature adjustment Power Water pressure adjustment... -
Page 6: Clean Function
Clean function Please occupy the toilet seat in order to activated the sensor installed onto the seat. Rear cleaning 1. Cleaning Press rear cleaning button to activate. 2. Stop cleaning Press stop button. Front cleaning 1. Cleaning Press front cleaning button to activate. 2. -
Page 7: Water Pressure
Water pressure Water volume adjustment Press button for adjusting the water pressure. 5-level adjustment:1 Cleaning massage Oscillating cleaning Press to activate or deactivate oscillating cleaning mode. With activating the oscillating cleaning function, the nozzle will be moved back and front for widening the cleaning range. -
Page 8: Cleaning And Maintenance
Cleaning & maintenance Nozzle cleaning Press oscillating button for 3 sec to activate that nozzle would automatically oscillated back and front during 1 minute. To stop this function in advance, please press stop button. Nozzle extension Press pulsating button for 3 seconds, nozzle reaches out automatically which will be remained for 1 minute. Warning! 1. - Page 9 Cleaning and removal Use a soft and damp cloth or sponge to wipe off the body gently. Disconnect the power 1. Unplug the product prior to clean. 2. Push the release button located on the back right of the seat and slide out main unit from mounting plate. Warning! 1.
-
Page 10: Troubleshooting
Troubleshooting Issue Possible Solution 1. Connect the product to main power supply 1. Disconnected/ no power supply 2. Check there’s a 220-240V~,50/60Hz signal with No working 2. No electrical power supply another product (such us hairdryer) 3. Product is power off 3.
