Buckingham 2139 Assembly & Attachment Instructions

Overview of parts (shown is only
Split Ring
Chafe
1) Insert 1 tall rivet through
chafe as shown.
4) Fold buckle strap over rivet
and into next hole.
7) Correctly seated burr shown
below.
2139.doc PN 230307
Rev. 8-19-16
PN 2139 – FOOT STRAPS FOR RING TYPE CLIMBERS
ASSEMBLY & ATTACHMENT INSTRUCTIONS
½
of the supplied materials, or enough to make 1 strap, for 1 side):
1" Buckle
Foot Strap
Optional: Burr Seating & Rivet Flattening Tool (not included)
2) Place buckle strap over rivet
as shown.
5) Place a copper burr over rivet. 6) Seat the burr onto the rivet shaft.
8) Do not seat burr too hard
such that it tears the back
side of the chafe leather.
Short Rivets
1" Loop
Burrs
Strap Retainer
3) Place buckle on buckle strap
(Use tool/method appropriate to seat burr)
9) Carefully peen the rivet tip until
(Use tool/method appropriate to peen rivet)
Buckle Strap
Tall Rivets
with tongue through slot.
flattened over the burr.
