Read carefully, understand, and heed these and all included cautions, instructions and warnings before using
this equipment. Failure to do so could result in your serious injury or death.
The Buck Hook™ is a safety device used to provide a
structure from ground to elevated heights back to ground. The system can be used in conjunction with a rope lifeline
(7/16" min) and compatible rope grab or a retractable lanyard. The Buck Hook™ is to be connected to a standard
fiberglass stick with universal head.
The configuration of the Buck Hook™ will fit around a 5 7/8" x 5 7/8"
section of angle steel (see Fig. 1). When installed, the major axis position
of the Buck Hook™ shall be aligned within +
Buckingham's Buck Hook™ System allows the user to ascend and
descend the structure while remaining 100% fall protected.
To properly assemble the Buck Hook™ System requires either option 1 (Fig. 2) or option 2 (Fig. 16)
components.
Note: Hardware and components, although BMC supplied is recommended, may differ from
that shown in Fig. 2 and Fig. 16.

OPTION 1

Buck Hook™
1 – 50371U
1 – 5004L Fall Arrester
1 – 39S2Q2-16 Lifeline
( with 16-20O attached )
1 – Fiberglass Pole
1 – 5005T Steel Carabiner
HOW TO ASSEMBLE THE BUCK HOOK™ SYSTEM OPTION 1
A. Attach the
50371U
degrees when attached to the Buck Hook™ which is positioned over a section of angle
B. Attach the 39S2Q2-16 lifeline to the
C. Attach the 5004L Fall Arrester to the lifeline (Fig. 5-9)
HOW TO ASCEND WITH THE BUCK HOOK™ SYSTEM USING OPTION 1
1. Extend Fiberglass pole all the way out.
2. Place Buck Hook™ over the lattice of the structure in a place suitable for anchorage. (Fig. 11 - 12). Note,
bottom of fiberglass pole must remain below the user's feet to eliminate the possibility of the Buck Hook™ being
inadvertently lifted off the anchorage point
3. Connect the 5004L fall arrester that is already attached to the lifeline to the sternal attachment of your harness
using the attached carabiner (Fig. 13). Note only use the oval TRIACT Lock Carabiner provided with the fall
arrester.
4. Climb structure until you reach the top of the lifeline (Fig. 14)
PN 230316 – Buck Hook™ System Inst / Warn (Rev. 1/21/15)
Buckingham Mfg Co.
Buck Hook™ System
Instructions / Warnings
45°
from vertical.
Fig. 2

50371U

to the end of the fiberglass pole (Fig. 3). The fiberglass pole shall hang vertically within +5
50371U

temporary,
portable anchorage point of a fall protection system to
5004L


5005T
39S2Q2-16
Buck Hook™ using the 5005T carabiner (Fig. 4)
Fig. 3
Fig. 1
45˚
Fiberglass Pole
With Universal
Head

steel.
Fig. 4
1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Buck Hook and is the answer not in the manual?

Questions and answers

Summary of Contents for Buckingham Buck Hook

  • Page 1 1. Extend Fiberglass pole all the way out. 2. Place Buck Hook™ over the lattice of the structure in a place suitable for anchorage. (Fig. 11 - 12). Note, bottom of fiberglass pole must remain below the user’s feet to eliminate the possibility of the Buck Hook™ being inadvertently lifted off the anchorage point 3.
  • Page 2 5. Secure your secondary positioning lanyard (not to exceed a 2’ fall) around tower leg (Fig.15) 6. Once secure, reposition the Buck Hook™ to the next highest point ensuring the bottom of the fiberglass pole is below the feet at all times while ascending.
  • Page 3 2. Connect the locking snap hook of the retractable lanyard to either the dorsal (Fig.22) or sternal (Fig.23) attachment point of your harness. 3. Place the Buck Hook™ over the lattice of the structure in a place suitable for anchorage (2” angle and above) (Fig. 20-21).
  • Page 4 Fig. 25 Note: When attaching the Buck Hook™ to a vertical member always attach as close to or around the vertical member as possible. If attaching to a horizontal member always attach as close to an intersection of two members as possible. Never attach in the middle of a long unsupported horizontal member.
  • Page 5 BINGHAMTON, NY www.buckinghammfg.com 1-800-937-2825 Information contained in these written instructions supersedes all other information (written, audio, video etc.) produced by Buckingham Mfg. prior to the   revision date of this document. PN 230316 – Buck Hook™ System Inst / Warn (Rev. 1/21/15) 5 of 5                                                                             ...
