Summary of Contents for Promac JD-32120
- Page 1 Drill Press Säulenbohrmaschinen JD-32120 Perceuses à colonne Schweiz / Suisse France JPW (TOOL) AG TOOL FRANCE SARL Tämperlistrasse 5 9 Rue des Pyrénées, 91090 CH-8117 LISSES, France Fällanden Switzerland www.promac.fr www.promac.ch...
- Page 2 CE-Konformitätserklärung Déclaration de Conformité CE Product / Produkt / Produit: Drill Press Säulenbohrmaschinen Perceuses à colonne JD-32120 Brand / Marke / Marque: PROMAC Manufacturer / Hersteller / Fabricant: TOOL FRANCE SARL 9 Rue des Pyrénées, 91090 LISSES, France We hereby declare that this product complies with the regulations Wir erklären hiermit, dass dieses Produkt der folgenden Richtlinie entspricht...
-
Page 3: Special Safety Rules For Drill Press
EN – ENGLISH NOTE: 1.0 Special Safety Rules For Drill Press: 1. Caution : This drill press is intended for use only with drill bits. This use of other accessories may be hazardous. 2. Correct drilling speeds : Factors which determine the best speed to use in any drill press operation are : Kind of material being worked, size of hold, type of drill or other cutter, and quality of cut desired. -
Page 4: Electric
VII Electric ELECTRICAL CONNECTION/DISCONNECTION & OPERATION For three phase : 1. Electrical connection: A cable with four wires is equipped to connect your machine into the 3 phase power supply. Please connect your machine into the power supply with hand-operated disconnecting device, which is in compliance with subclause 5.3 of EN 60204-1, such as on fuse breaker or plug/socket combination. -
Page 5: Table Of Contents
13.0 REPLACEMENT PARTS .......................... 15 13.1.1 JD-32120 D – E ........................16 RILL RESS XPLODED 13.1.2 JD-32120 D – P ..........................17 RILL RESS ARTS 14.0 ELECTRICAL CONNECTIONS FOR JD-32120 ..................19 ENVIRONMENTAL PROTECTION ..........................20 WARRANTY / GARANTIE ..........................21... -
Page 6: Specifications
4.0 Specifications Model number ................................JD-32120 Stock number ................................JD_32120 Motor and electricals: Motor type ..........…………………………………………………….totally enclosed fan cooled, induction Horsepower ................................1-1/2 HP Phase ....................................1 Voltage ................................... 230V Cycle ....................................50Hz Listed FLA (full load amps) ............................8.7 A Starting amps .................................. - Page 7 L = length; W = width; H= height; D= depth The specifications in this manual were current at time of publication, but because of our policy of continuous improvement, PROMAC reserves the right to change specifications at any time and without prior notice, without incurring...
-
Page 8: Base Mounting Hole Dimensions
Base mounting hole dimensions 3212 Figure 5-1: Base hole patterns... -
Page 9: Setup And Assembly
5.4.1 Chuck and arbor installation Read and understand the entire Thoroughly clean arbor (A, Figure 6-2), chuck (B) contents this manual before attempting and spindle (C). Any grease or residue in these assembly or operation. Failure to comply may areas can cause the pieces to separate and cause serious injury. -
Page 10: Electrical Connections
Failure to comply may result in serious injury. Recommended The JD-32120 Drill Presses are rated at 230V power, Table 1: Extension cord recommendations The drill press comes with a plug designed for use on a circuit with a grounded outlet . -
Page 11: Changing Spindle Speeds
JD-32120: Loosen two hex nuts (J) with 19mm or approximately 1/2-inch deflection. adjustable wrench. Tilt table to desired angle, referring to scale and pointer atop table bracket. Tighten screw or nuts (J). -
Page 12: Operating Controls
Periodically apply #2 tube grease to: Rack. Table elevating mechanism, including worm gear. Figure 8-5: table tilt (JD-32120 only) Splines (grooves) in spindle. Teeth of quill. 8.0 Operating controls Periodically apply light coat of machine tool oil to quill Press ON button to start spindle rotation. -
Page 13: Spindle Speed Charts
11.0 Spindle speed charts 11.1 Speed selection for JD-32120 Drill Press Figure 12-2: JD-32120 only... - Page 14 12.0 Troubleshooting JD-32120 Symptom Possible Cause Correction * Drill press unplugged from wall, or Check all plug connections. motor. Drill press will not Fuse blown, or circuit breaker tripped. Replace fuse, or reset circuit breaker. start. Cord damaged. Replace cord.
-
Page 15: Replacement Parts
Replacement parts are listed on the following pages. Some parts are shown for reference only, and may not be available individually. Non-proprietary parts, such as fasteners, can usually be found at local hardware stores, or may be ordered from PROMAC. -
Page 16: Jd-32120 Drill Press - Exploded View
13.1.1 JD-32120 Drill Press – Exploded View... -
Page 17: Jd-32120 Drill Press - Parts List
13.1.2 JD-32120 Drill Press – Parts List Index No Part No Description Size 1 ....IDP22-01 ....Base ............575 x 500 x 85 ........1 201 .... IDP22-201 ....Column Assembly (#2,5) ..................1 2 ....IDP22-02 ....Column Holder ......................1 3 .... - Page 18 56 ....TS-2172001....Phillips Flat Head Screw ......3/16" x 1/4" ..........2 57 ....PM-JD3212057 ..Pulley Cover Limit Switch ..................1 58 ....PROMAC 160.... Name Plate (PROMAC) ................... 1 59 ....PM-JD3212059 ..Power Cord ..........3G 1.0m/m2 250V/440V ......1 60 ....
-
Page 19: Electrical Connections For Jd-32120
14.0 Electrical Connections for JD-32120 Item Making of Description & function Maker Type Technical data designation conformity granted Plug for supply LIAN DUNG 10~16A , 250V LT-32 Single phase Supply cable TIEN TUNG H05W-F 3G 1.0m/m2 250V VDE/ROHS Single phase... -
Page 20: Environmental Protection
Environmental protection Protect the environment. Your appliance contains valuable materials which can be recovered or recycled. Please leave it at a specialized institution. This symbol indicates separate collection for electrical and electronic equipment required under the WEEE Directive (Directive 2012/19/EC) and is effective only within the European Union. -
Page 21: Warranty / Garantie
Les CG peuvent être envoyées sur demande par poste ou par e-mail . TOOL FRANCE SARL se réserve le droit d'effectuer des changements sur le produit et les accessoires à tout moment. TOOL FRANCE SARL 9 Rue des Pyrénées, 91090 LISSES, France w www.promac.fr...
