215-1829 Rev. C; ECN 18-08-010A
© 2018 Bradley
Page 1 of 12
7/25/2018
Installation
LVSD2
Verge
Lavatory System - LVS-Series
®
with Evero
Natural Quartz Material
®
Table of Contents
Components ..................................................................3-4
Supplies Required .............................................................5
Dimensions ....................................................................5-6
Rough-Ins .......................................................................7-8
Bracket Mounting ...............................................................9
Drain Assembly .................................................................9
Faucets and Optional Soap Valve ...................................10
Bowl Mounting .................................................................10
Strainer and P-trap ..........................................................10
Adjust Temperature ..........................................................11
Trap Cover .......................................................................11
Cleaning and Maintenance ..............................................12
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
P.O. Box 309
bradleycorp.com
Advertisement
Table of Contents
Related Manuals for Bradley Verge LVSD2
Summary of Contents for Bradley Verge LVSD2
-
Page 1: Table Of Contents
Adjust Temperature ............11 Trap Cover ...............11 Cleaning and Maintenance ..........12 P.O. Box 309 215-1829 Rev. C; ECN 18-08-010A Menomonee Falls, WI 53052 USA © 2018 Bradley 800 BRADLEY (800 272 3539) +1 262 251 6000 Page 1 of 12 7/25/2018 bradleycorp.com... - Page 2 If any parts are missing, do not begin installation until you obtain the missing parts. For standard height mounting, do not exceed the recommended 33.5" distance from the fixture rim to the finished floor. Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018...
-
Page 3: Components
TMV Valve Tempered Supply TMV Supply (1/2" NPTM Connections Connections Outlet) Supply Fittings (S45-2701) Plastic Hose (S45-2511) Plastic Hose Plastic Hose Supply Hose Prepack Stainless Fittings (S45-2731) Steel (S45-2510) Hose Hose Prepack (S45-2730) Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... - Page 4 Battery Box for Plug-in transformer option (PT) CAP-DCR Faucets includes Transformer (S53-338), Adapter (S53-339), and Grounding Kit (S53-349) for CAP-DCR Faucets Optional Transformer 6315-KT0000 Soap Dispenser 6324-68 Soap Dispenser 6334 Soap Dispenser Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018...
-
Page 5: Supplies Required
Top View (shown with CAP-DCR faucet and 6315 soap as shared soap) 15" 15" (381mm) (381mm) 6" 6" (152mm) (152mm) 4-1/4" (165mm) 21" (533mm) 2" (51mm) A = Personal soap locations Front View 60" (1524mm) 1-7/8" (48mm) 12-7/8" (327mm) 38-3/8" (975mm) Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... - Page 6 31" (787mm) 33-1/2" (851mm) 33" (838mm) 32½" (826mm) Dim B 27" (686mm) 24" (610mm) 29-5/8" (752mm) 28-15/16" (735mm) 28-15/16" (735mm) Dim C 20-3/4" (527mm) 18-1/4" (464mm) 21-1/8" (536mm) 20-1/4" (514mm) 19-3/4" (502mm) Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018...
-
Page 7: Rough-Ins
Install wall anchor with a minimum pull-out force of 100 lbs. per local codes at locations shown RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FIXTURE STYLE 33-1/2" No Adjustment Standard Height, ADA, TAS and CSA 30-1/2" Subtract 3" Juvenile, ADA and TAS 32½" Subtract 1" AODA 33" Subtract 1/2" Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... - Page 8 1/2" Nominal (5/8" O.D. Comp.) Hot/Cold supplies, Stub-out 2" from wall 110V GFI protected electrical outlet (AC faucet and soap only) Outline of shared soap container (if selected) Outline of personal soap container (if selected) Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018...
-
Page 9: Bracket Mounting
Screw Assemble the remaining components as shown and thread the four screws through the drain adapter and into the basin inserts. Ensure the screws compress the drain adapter evenly onto the basin. Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... -
Page 10: Faucets And Optional Soap Valve
Strainer and P-Trap Ensure not to overtighten the strainer screw. Strainer Thread the strainer screw Install supplied p-trap to through the strainer and drain adapter. into the stand off on the drain adapter. Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... -
Page 11: Adjust Temperature
(2 locations). screws provided by screws and finishing washers installer (2 locations). provided (2 locations). Bradley • 215-1829 Rev. C; ECN 18-08-010A 7/25/2018... -
Page 12: Cleaning And Maintenance
Avoid contact with hot pans and objects. Repair Kits: Evero repair kits are available. Contact your Bradley representative or distributor for part numbers and pricing. Repair kits are made to order and have a shelf life of 30 days.
