1. Product Introduction

The UHD44MXA-IP is a professional 4x4 HDMI 2.0 Matrix Switcher with Audio Matrix. It
includes 4 HDMI inputs, 4 HDMI outputs and the last two outputs with down-scaling
function, which is designed for switching two HDMI2.0 and HDCP2.3 compliant signals.
It also features 4 SPDIF and 4 analog audio outputs for audio matrix.
The matrix switcher features comprehensive EDID management and advanced HDCP
handing to ensure maximum functionality with a wide range of video sources.
IR, RS232, and TCP/IP control options for easy integration with control systems.

1.1 Features

4x4 HDMI 2.0 Matrix Switcher.
⚫
Supports 4K/60 4:4:4, HDR, HDCP2.3 compliant.
⚫
Audio Matrix, audio out can de-embedded from arbitrary input or output.
⚫
Individual volume adjustment on each L+R output.
⚫
Supports 4K to 1080p down-scaling up to 2 outputs.
⚫
HDMI out provides 2.5W to power Active Optical Cable (AoC).
⚫
Controllable by front panel, IR, RS232 and TCP/IP.
⚫

1.2 Package List

1 x UHD44MXA-IP
⚫
2 x Mounting Ears with 6 Screws
⚫
4 x Plastic Cushions
⚫
1 x IR Remote
⚫
1 x IR Receiver
⚫
1 x RS232 Cable (3-pin to DB9)
⚫
1 x Power Adaptor (24V DC 1.25A)
⚫
1 x User Manual
⚫
