CTEK 1087 Manual

MANUAL
CONGRATULATIONS
to the purchase of your new professional switch mode battery charger. This charger is
included in a series of professional chargers from CTEK SWEDEN AB and represents the
latest technology in battery charging.
Read safety instruction
HOW TO CHARGE
1. Connect the charger to the battery.
For batteries mounted inside a vehicle
1. Connect the charger according to the
vehicles manual.
2. Connect the charger to the wall socket.
1 2
3. Disconnect the charger from the wall socket
before disconnecting the battery.
4. Disconnect the black clamp before the red
clamp.
2. Connect the charger to the wall socket. The power lamp will indicate that the mains
cable is connected to the wall socket. The power lamp will blink if the battery clamps
are incorrectly connected. The reverse polarity protection will ensure that the battery or
charger will not be damaged.
3. Press the MODE-button to select charging program.
NORMAL BATTERY PROGRAM
Continue to press the MODE-button to combine charging program with charging options.
RECOND OPTION
Press the MODE-button several times until the desired combination of charging program
and options are lit.
4. Follow the display through the charging process.
The battery is fully charged when the CARE lamp is lit.
5. Stop charging at any time by disconnecting the mains cable from the wall socket.
MODE BUTTON
ERROR LAMP
NORMAL RECOND
POWER LAMP
NORMAL RECOND
BATTERY OPTION
PROGRAM
LITHIUM BATTERY PROGRAM
FULLY CHARGED
LITHIUM
LITHIUM
BATTERY
PROGRAM
EN • 3
