SHAKER DRESSER & STOOL
ASSEMBLY INSTRUCTIONS
Thank you for purchasing the SHAKER DRESSER & STOOL. Please
read the instructions carefully to ensure safe operation of the product.
W710 x D405 x H1285 mm/BLACK,WHITE
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of
construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do
not destroy any of the packaging until you are certain that you have all the necessary parts for the
assembly.
CAUTION: There are small components used in the construction of this unit. These loose items
should be kept away from young children whilst assembling your unit to avoid the danger of choking
hazards.
Tools Required
Batch No.: WMI 14930
Page 1 of 6
